User Manual Roth EnergyLogic Touchline/Wireless
Installation
Close wireless room
thermostat
5.2.3

Wireless room thermostat without display

Open wireless room ther-
mostat
34
Fig. 17: Close the wireless room thermostat
You need to remove the rotary knob to open and address the wireless room
thermostat.
►
Remove the rotary knob.
►
Open the cover using the intended bore and a flat-tip screwdriver of 3 mm.
►
Remove the cover.
Fig. 18: Open the wireless room thermostat
1
click
20
5 30
2
P100011294 E
