Carpets; Application Of Oil - Piper Arrow IV Turbo Maintenance Manual

HEADLINER, SIDE PANELS AND SEATS.
1. Clean headliner, side panels and seats with a stiff bristle brush and vacuum where necessary.
2. Soiled upholstery, except leather, may be cleaned by using an approved air type cleaner or foam
upholstery cleaner. Carefully follow the manufacturer's instructions. Avoid soaking or harsh rubbing.
3. Leather material should be cleaned with saddle soap or mild soap and water.

CARPETS.

Use a small whisk broom or vacuum to remove dirt. For soiled spots, use a non-inflammable dry-cleaning
fluid.
LUBRICATION INSTRUCTIONS.
Proper lubrication procedures are of immeasurable value both as a means of prolonging the service life of
the airplane and as a means of reducing the frequency of extensive and expensive repairs. The periodic
application of recommended lubricants to their relevant bearing surfaces, as detailed in the following
paragraphs, together with the observance of cleanliness will insure the maximum efficiency and utmost service
of all moving parts. Lubrication instruction regarding the locations, time intervals, and type of lubricants used
may be found in the Lubrication Chart. To insure the best possible results from the application of lubricants,
the following precautions should be observed:
1. Use recommended lubricants. Where general purpose lubricating oil is specified, but unavailable,
clean engine oil may be used as a satisfactory substitute.
2. Check the components to be lubricated for evidence of excessive wear and replace them as necessary.
3. Remove all excess lubricants from components in order to prevent the collection of dirt and sand in
abrasive quantities capable of causing excessive wear or damage to bearing surfaces.
If the airplane is inactive for long periods of time, it should be
lubricated in accordance with Lubrication Chart every 90 days.

APPLICATION OF OIL.

Whenever specific instructions for lubrication of mechanisms requiring lubrication are not available,
observe the following precautions:
1. Apply oil sparingly, never more than enough to coat the bearing surfaces.
2. Since the control cables are sufficiently coated by the manufacturer, additional protection for the
prevention of corrosion is unnecessary.
PIPER AIRCRAFT
PA-28RT-201 / 201T
*MAINTENANCE MANUAL
—CAUTION—
Solvent cleaners require adequate ventilation.
—NOTE—
1D22
12-20-30
Page 12-15
December 1, 1978
