Piper Arrow IV Turbo Maintenance Manual page 96

COMPONENT
1. MAIN GEAR PIVOT POINTS
2. MAIN GEAR DOOR HINGE
3. MAIN GEAR TORQUE LINKS
4. EXPOSED OLEO STRUT MAIN
5. MAIN GEAR WHEEL BEARINGS
6. MAIN GEAR DOOR CONTROL ROD ENDS
7. MAIN GEAR SIDE BRACE LINK ASSEMBLY
8. UPPER SIDE BRACE SWIVEL FITTING
9. MAIN GEAR DOWNLOCK ASSEMBLY RETRACTION
FITTING AND CYLINDER ATTACHMENT POINTS
10. OLEO STRUT FILLER POINT (MAIN GEAR)
11. HYDRAULIC PUMP RESERVOIR
12. BRAKE RESERVOIR
1. Main Wheel Bearings - Disassemble and clean with a dry type solvent. Ascertain that grease is packed
between the roller and cone. Do not pack grease in wheel housing. Wheel bearings require cleaning and
repacking after exposure to an abnormal quantity of water.
2. Oleo Struts, Hydraulic Pump Reservoir and Brake Reservoir - Fill per instructions on unit or container or refer
to Maintenance Manual.
PIPER AIRCRAFT
PA-28RT-201 / 201T
*MAINTENANCE MANUAL
SPECIAL INSTRUCTIONS
THIS SPACE INTENTIONALLY LEFT BLANK
Figure 12-4. Lubrication Chart (Landing Gear, Main)
1D24
LUBRICANT
MIL-G-23827
MIL-L-7870
MIL-L-7870
MIL-L-60326
TEXACO MARFAX ALL
PURPOSE GREASE OR
MOBIL GREASE 77 (OR
MOBIL EP2 GREASE)
MIL-L-7870
MIL-G-23827
MIL-G-23827
MIL-L-7870
MIL-H-5606
MIL-H-5606
MIL-H-5606
FREQUENCY
100 HRS
100 HRS
100 HRS
100 HRS
100 HRS
100 HRS
100 HRS
100 HRS
100 HRS
AS REQUIRED
100 HRS
100 HRS
12-20-32
Page 12-17
Revised: December 21, 1981
