REMOVAL OF WING FLAP. (Refer to Figure 57-2.)
1. Extend the flaps to their fullest degree and remove the bolt and bushing from the rod end bearing by
use of an angle or offset screwdriver.
2. Remove the nuts, washers, bushing and hinge bolts that hold the flap to the wing assembly.
3. Pull the flap straight back off the wing.
INSTALLATION OF WING FLAP. (Refer to Figure 57-2.)
1. Replace the wing flap by placing the flap onto its proper position and inserting the hinge bolts,
bushings, washers and nuts.
2. With the flap control in the full flap position, place the bushing on the outboard side of the rod end
bearing and insert and tighten the bolt.
3. Operate the flap several times to be certain it is operating freely.
