CHAPTER
SECTION
SUBJECT
24-00-00 GENERAL
24-01-00 Description and Operation
24-02-00 Troubleshooting
24-30-00 D.C. GENERATOR
24-31-00 Description of Alternator System
24-31-01 Checking Alternator System
24-31-02 Service Precautions
24-31-03 Overhaul of Alternator
24-32-00 Alternator System (CHRYSLER)
24-32-01 Bench Testing Alternator
24-32-02
24-32-03
24-32-04 Inspection
24-32-05 Testing of Rectifier Assemblies
24-32-06 Testing of Positive Rectifiers Using C-3829 Tester
24-32-07 Testing of Negative Rectifiers Using C-3829 Tester
24-32-08 Testing of Rectifier Assemblies Using Test Lamp
24-32-09 Removal of Rectifier and Heat Sink Assembly
24-32-10 Testing of Stator
24-32-11 Removal of Pulley and Bearing
24-32-12 Testing of Rotor
24-32-13 Slip Rings
24-32-14 Assembly of Alternator
24-33-00 Alternator System (PRESTOLITE)
24-33-01 Alternator Nomenclature
24-33-02 Alternator Service Precautions
24-33-03 Description of Alternator
24-33-04 Overhaul of Alternator
24-33-05 Disassembly of Alternator
24-33-06 Inspection and Testing of Components
24-33-07 Assembly of Alternator
24-33-08 Testing of Alternator
24-33-09 Alternator Service Test Specification
24-33-10 Checking Alternator Belt Tension (PA-28R1-201)
PIPER AIRCRAFT
PA-28RT-201 / 201T
MAINTENANCE MANUAL
CHAPTER 24 - ELECTRICAL POWER
TABLE OF CONTENTS/EFFECTIVITY
Rotor Field Coil Current Draw
Testing Alternator Internal Field Circuit
SUBJECT
1H18
GRID
NO. EFFECTIVITY
1H20 8-82
1H20 2-79
1H20
1I6
1I6 8-82
1I7 A 8-82
1I8 A 8-82
1I8 A 8-82
1I9
1I9
1I9 8-82
1I9 8-82
1I11
1I11 A 8-82
1I11 8-82
1I13 8-82
1I13 A 8-82
1I15 A 8-82
1I15 8-82
1I15 8-82
1I17 A 8-82
1I17 A 8-82
1I17 2R 7-83
1I22
1I22
1I22
1I23
1J1
1J1
1J1
1J3
1J5
1J5
1J7
24 - Cont./Effec.
Page - 1
Revised: July 13, 1983
