GENERAL.
The lighting system available for the Arrow IV is optional but enables the aircraft to fly at night and in
instrument weather conditions.
DESCRIPTION AND OPERATION.
External lighting attainable on the Arrow IV involves navigation lights, strobe lights, position lights, and a
landing/taxi light. The navigation light system is made up of the standard red and green wing tip lights, a white
taillight on the bottom of the rudder. Strobe lights can also be incorporated in the wing tips for better
recognition and are incorporated with the nav lights' installation. To aid in taxi and landing operations in low
visibility conditions a dual beam light (high-landing, low-taxi) is mounted in the cowl. The switches for these
lights are mounted to the switching panel located just above the power quadrant.
The interior lights involve instrument panel and instrument/radio lights, and an overhead cabin/map light.
PIPER AIRCRAFT
PA-28RT-201 / 201T
MAINTENANCE MANUAL
THIS SPACE INTENTIONALLY LEFT BLANK
2F21
33-00-02
Page 33-01
Revised: July 24, 1981
