Piper Arrow IV Turbo Maintenance Manual page 32

Perform all inspections or operations at each of the inspection
intervals as indicated by a circle (O). (See Notes 1, 2 and 3.)
F. FUSELAGE AND EMPENNAGE GROUP (cont)
6. Inspect antenna mounts and electric wiring for security and
corrosion in plugs.....................................................................................
7. Check hydraulic pump fluid level (Fill as required)................................
8. Inspect hydraulic pump lines for damage and leaks ................................
9. Inspect for obstructions and contamination in inlet of backup
landing gear extender actuator inlet head.................................................
10. Inspect air conditioning system for freon leaks .......................................
11. Check freon level in sight gauge of receiver-dehydrator.........................
12. Inspect air conditioner condenser air scoop rigging ................................
13. Inspect fuel lines, valves, sender units, and gauges for damage and
operation...................................................................................................
14. Inspect security of all lines.......................................................................
15. Inspect vertical fin and rudder surfaces for damage ................................
16. Inspect rudder hinges, horn and attachments for damage and operation.
17. Inspect vertical fin attachments................................................................
18. Inspect rudder hinge bolts for excess wear (Replace as required)...........
19. Inspect rudder control stops to ensure stops have not loosened
and locknuts are tight...............................................................................
20. Inspect stabilator surfaces for damage.....................................................
21. Inspect stabilator, tab hinges, horn and attachments for damage
and operation............................................................................................
22. Inspect stabilator attachments..................................................................
23. Inspect stabilator and tab hinge bolts and bearings for excess wear
(Replace as required)................................................................................
24. Inspect stabilator control stops to ensure stops have not loosened
and locknuts are tight ...............................................................................
24a.Inspect stabilator trim mechanism ...........................................................
25. Inspect fuselage wing attach fittings for corrosion, general condition and
security. (See latest revision of Piper Service Bulletin 977.)...................
26. Inspect all cable tensions (use tensiometer) (See Note 19)......................
27. Inspect cables, aileron, rudder, stabilator, stabilator trim, turnbuckles,
guides and pulleys for safety, damage and operation (See Note 27)........
28. Inspect and lubricate stabilator trim drum screw. ....................................
29. Inspect stabilator balance weight attachments and arm for security
and condition............................................................................................
30. Inspect emergency locator transmitter battery for replacement
date per Maintenance Manual (Refer to latest revision of Piper
Service Letter No. 820)............................................................................
31. Clean and lubricate all exterior needle bearings......................................
PIPER AIRCRAFT
PA-28RT-201 / 201T
MAINTENANCE MANUAL
PERIODIC INSPECTIONS. (cont)
—NOTE—
Nature of Inspection
1B8
Inspection Time (hrs)
50 100 500
O
O O
O
O O
O
O O
O O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
Interim Revision: February 27, 1995
1000
O O
O O
O O
O O
O O
O O
O O
O O
O O
O O
O O
O O
O O
O O
O O
O O
O O
O O
O O
O O
O O
O O
O O
O O
O O
O O
O
5-20-01
Page 5-09
