FIGURE NO.
29-10.
29-11.
32-1.
32-2.
32-3.
32-3a.
32-4.
32-5.
32-5a.
32-6.
32-7.
32-8.
32-9.
32-10.
32-11.
32-12.
32-13.
32-14.
32-15.
32-16.
32-17.
32-18.
32-19.
32-20.
32-21.
32-22.
32-23.
32-24.
33-1.
33-2.
34-1.
35-1.
35-2.
35-3.
35-4.
35-5.
51-1.
51-1a.
51-2.
51-3.
51-4.
51-5.
51-6.
51-7.
51-8.
51-9.
52-1.
PIPER AIRCRAFT
PA-28RT-201 / 201T
MAINTENANCE MANUAL
LIST OF ILLUSTRATIONS (cont)
SUBJECT
End Gland Locking Device
Main Gear Actuating Cylinder
Main Gear Oleo Strut Assembly
Main Gear Installation
Main Gear Service Tolerances
Aligning Main Gear
Nose Gear Oleo Strut Assembly
Nose Gear Installation
Nose Gear Service Tolerances
Nose Gear Adjustment (PA-28RT-201)
Nose Gear Adjustment (PA-28RT-201T)
Clamping Rudder Pedals in Neutral Position
Rudder Pedals at Neutral Angle
Nose Gear Door Retraction Mechanism(PA-28RT-201)
Nose Gear Door Retraction Mechanism (PA-28RT-201T)
Nose Wheel Assembly
Main Wheel Assembly
Wheel Brake Assembly (30-55)
Removal of Anchor Bolt
Installation of Anchor Bolt
Brake System Installation
Brake Master Cylinder (Hand Parking Brake)
Toe Brake Installation
Brake Cylinder (17000) (Toe Brake)
Brake Cylinder (10-30) (Toe Brake)
Adjustment of Nose Gear Down Limit Switch
Adjustment of Main Gear Down Limit Switch
Throttle Warning Switches
Annunciator Panel
Strobe Light Connections
Pitot-Static System Installation
Fixed Oxygen System
Portable Oxygen System
Test Apparatus for Testing Oxygen System
Oxygen Tubing Installations
Installation of Swagelok Fittings
Skin Materials and Thickness
Baggage Compartment Inspection Holes Cutout Details
Surfaces Scratches, Abrasions or Ground-in-Dirt
Deep Scratches, Shallow Nicks and Small Holes
Mixing of Epoxy Patching Compound
Welding Repair Method
Repairing of Cracks
Various Repairs
Repair of Stress Lines
Repair of Impacted Damage
Installation of Door Snubber
2A12
GRID NO.
Interim Revision: February 27, 1995
2C24
2D1
2D16
2D17
2D19
2E3
2E7
2E9
2E10
2E16
2E17
2E19
2E19
2E20
2E21
2E24
2F1
2F2
2F4
2F5
2F7
2F8
2F9
2F10
2F11
2F15
2F15
2F17
2G1
2G4
2G10
2G24
2H1
2H4
2H5
2H8
2I9
2I12
2I16
2I17
2I17
2I19
2I19
2I20
2I22
2I22
2J7
