Refer to
Fig. 32-5a
for Part No.
Fig. No.
13 67054-03
14 95061-144
15 67148-00
16 67026-07
17 67148-00
18 21831-04
19 20735-05
20 20735-05
21 452 366
(#F-310-5)
22 67050-02
23 67026-07
24 67146-00
25 63900-120
##Install using Loctite 601.
Rotate while inserting.
PIPER AIRCRAFT
PA-28RT-201 / 201T
MAINTENANCE MANUAL
CHART 3204. NOSE GEAR SERVICE TOLERANCES (cont)
Nomenclature
Trunnion assembly
assist spring fitting
Bearing, assist spring
fitting
Tube assembly torque
link fitting
Bearing, tube assembly
torque link fitting
Shimmy damper fitting
Shimmy damper fitting
bearing
Torque link
Torque link
Bearing, torque link
Fork assembly-torque
link fitting
Bearing, fork assembly
torque link fitting
Draglink, upper
Bushing, upper draglink
** Line ream to this dimension
after installation of new part.
Manufactures
Dimension Dimension
ID.302
.303
ID.249
.250
ID.4370
.4385
** ID.313
.314
ID.3745
.3760
** ID.249
.251
ID.312
.314
ID.377
.3785
** ID.2495
.2505
ID.4370
.4385
** ID.312
.313
ID.372
.373
ID.2495
.2500
2E12
Service Service
Tol.
ID.302 .0015
.3035
ID.249 .010
.259
ID.4370 .0015
.4385
ID.3155 .0025
.3130
ID.3745 .0017
.3762
ID.249 .003
.252
ID.3155 .0025
.3130
ID.377 .002
.3790
ID.2495 .002
.2515
ID.4370 .0015
.4385
ID.312 .003
.315
ID.2495 .010
.2595
# Coat with zinc chromatic and install
while still wet.
Revised: August 17, 1982
Remarks
##
Press Fit
#
Press Fit
32-20-05
Page 32-29
