CHART 2701. TROUBLESHOOTING (SURFACE CONTROLS) (cont)
Trouble
Resistance to stabilator
control movement. (cont)
Incorrect stabilator travel.
Correct stabilator travel
cannot be obtained by ad-
justing stops.
Lost motion between trim
control wheel and trim tab.
Trim control wheel moves
with excessive resistance.
PIPER AIRCRAFT
PA-28RT-201 / 201T
MAINTENANCE MANUAL
Cause
STABILATOR CONTROL SYSTEM (cont)
Pulleys binding or rubbing.
Cables not in place on
pulleys.
Cables crossed or routed
incorrectly.
Bent stabilator hinge.
Stabilator stops incorrectly
adjusted.
Stabilator cables incor-
rectly rigged or incorrect
stop in control column.
STABILATOR TRIM CONTROL SYSTEM
FLOOR TRIM
Cable tension too low.
Cables not in place on
pulleys.
Broken pulley.
Linkage loose or worn.
System not lubricated
properly.
Cable tension too high.
Pulleys binding or rubbing.
1J24
Remedy
Replace binding pulleys and/
or provide clearance between
pulleys and brackets.
Install cables correctly.
Check routing of control
cables.
Repair or replace stabilator
hinge.
Adjust stop screws.
Rerig stabilator cables.
Replace stop.
Adjust cable tension.
Install cables properly.
Replace pulley.
Check linkage and tighten or
replace.
Lubricate system.
Adjust cable tension.
Replace binding pulleys.
Provide clearance between
pulleys and brackets.
27-00-02
Page 27-05
Revised: February 23, 1979
