Piper Arrow IV Turbo Maintenance Manual page 30

Perform all inspections or operations at each of the inspection
intervals as indicated by a circle (O). (See Notes 1, 2 and 3.)
D. ENGINE GROUP (LYCOMING) (cont)
34. Inspect fuel pumps for operation (engine driven and electric)...........
35. Overhaul or replace fuel pumps (engine driven and electric)
(See Note 7)
36. Check vacuum pump and lines...........................................................
37. Overhaul or replace vacuum pump (See Note 7)
38. Inspect throttle, alternate air, mixture, propeller and governor
controls for travel and operating condition.........................................
39. Inspect exhaust stacks, connections and gaskets (Replace gaskets
as required) (Refer to Chapter 78) ......................................................
40. Inspect muffler, heat exchange and baffles (Refer to latest
revision of Piper Service Bulletin No. 691)........................................
41. Inspect breather tube for obstructions and security ............................
42. Inspect crankcase for cracks, leaks, and security of seam bolts .........
43. Inspect engine mounts for cracks and loose mountings......................
44. Inspect all engine baffles.....................................................................
45. Inspect all wiring connected to the engine or accessories ..................
46. Inspect rubber engine mount bushings for deterioration (Replace
as required)..........................................................................................
47. Inspect fire wall seals..........................................................................
48. Inspect condition and tension of alternator drive belt.........................
49. Alternator and compressor idler pulleys (if installed); remove
front grease seal and add grease..........................................................
50. Inspect condition of alternator and starter...........................................
51. Inspect security of alternator mounting ..............................................
52. Check air conditioning compressor oil level (See Note 15)
53. Inspect condition of compressor belt and tension...............................
54. Inspect compressor clutch security and wiring...................................
55. Inspect security of compressor mounting...........................................
56. Check fluid in brake reservoir (Fill as required).................................
57. Lubricate all controls ..........................................................................
58. Overhaul or replace propeller governor (Refer to latest revision of
Hartzell Service Letter No. 61)
59. Complete overhaul of engine or replace with factory rebuilt
(See Note 7)
60. Reinstall engine cowl..........................................................................
PIPER AIRCRAFT
PA-28RT-201 / 201T
MAINTENANCE MANUAL
PERIODIC INSPECTIONS. (cont)
—NOTE—
Nature of Inspection
1B6
Inspection Time (hrs)
50 100 500
O O
O O
O O
O O
O O
O O
O O
O O
O O
O O
O O
O O
O O
O O
O O
O O
O O
O O
O O
O O O
O O
O O O
5-20-01
Page 5-07
Revised: August 8, 1984
1000
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
O
