Trouble
Motor fails to operate.
(cont)
Low motor and cranking
speed.
Excessive arcing of motor
brushes.
Excessive wear and arcing
of motor brushes.
PIPER AIRCRAFT
PA-28RT-201 / 201T
MAINTENANCE MANUAL
CHART 8001. TROUBLESHOOTING (STARTER) (cont)
Dirty commutator.
Shorted, grounded, or
open armature.
Grounded or open field
circuit.
Worn, rough, or improp-
erly lubricated motor or
starter gearing.
Same electrical causes as
listed under "Motor fails
to operate".
Binding, worn, or im-
properly seated brush or
brushes with excessive
side play.
Dirty commutator, rough,
pitted, or scored.
Rough or scored commu-
tator.
Armature assembly not
concentric.
Cause
3G14
Remedy
If commutator is rough or
dirty, smooth and polish
with number 0000 sand-
paper. If too rough and
pitted, remove and turn
down. Blow out all parti-
cles.
Remove and replace with
an armature known to be
in good condition.
Test, repair if possible or
replace with a new part.
Disassemble, clean, in-
spect, and relubricate,
replacing ball bearings
if worn.
Same remedies listed for
these troubles.
See information above deal
ing with this trouble.
Clean as outlined above.
Remove and turn commu-
tator down on a lathe.
Reface commutator.
