Courtesy of Bomar Flying Service
www.bomar.biz
ARROW IV
MAINTENANCE MANUAL
CARD 1 OF 3
PA-28RT-201 ARROW IV
PA-28RT-201T TURBO ARROW IV
PIPER AIRCRAFT CORPORATION
(PART NUMBER 761 694)
1A1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Arrow IV Turbo and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Piper Arrow IV Turbo

Summary of Contents for Piper Arrow IV Turbo

  • Page 1 Courtesy of Bomar Flying Service www.bomar.biz ARROW IV MAINTENANCE MANUAL CARD 1 OF 3 PA-28RT-201 ARROW IV PA-28RT-201T TURBO ARROW IV PIPER AIRCRAFT CORPORATION (PART NUMBER 761 694)
  • Page 2 PA-28RT-201 / 201T MAINTENANCE MANUAL INTRODUCTION. This PIPER AIRCRAFT Maintenance Manual is prepared in accordance with the GAMA (General Aviation Manufacturers Association) format. This maintenance manual is divided into various Groups which enable a broad separation of contents (Chapters) within each group.
  • Page 3 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL VENDOR PUBLICATIONS. ENGINE (LYCOMING): Overhaul Manual = AVCO LYCOMING - OVERHAUL MANUAL DIRECT DRIVE ENGINE - P/N 60294-7 Avco Lycoming Division Williamsport, Pa. 17701 Parts Catalog = AVCO LYCOMING - P/N PC-102 Avco Lycoming Division Williamsport, Pa.
  • Page 4 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL PIPER PUBLICATIONS. ELECTRONICS: AutoFlight II Service Manual = Piper P/N 761 481 Pitch Trim Service Manual = Piper P/N 753 771 AutoControl III B and Altimatic III B Service Manual = Piper P/N 753 502...
  • Page 5 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL AEROFICHE EXPLANATION AND REVISION STATUS Maintenance manual information incorporated in this set of Aerofiche cards is arranged in accordance with the general specifications of Aerofiche adopted by the General Aircraft Manufacturer’s Association. The information compiled in this Aerofiche maintenance manual will be kept current by revisions distributed periodically.
  • Page 6 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Revisions to Maintenance Manual 761 694 issued December 1, 1978 are as follows: Revisions Date Aerofiche Card Effectivity ORG 781201 December 1, 1978 1, 2, and 3 PR790223 February 23, 1979 1, 2, and 3...

  • Page 7: Table Of Contents

    PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GAMA SYSTEM/CHAPTER INDEX GUIDE SYST SUB-SYST AEROFICHE CHAP SECTION TITLE GRID NO. AIRWORTHINESS LIMITATIONS 1A18 TIME LIMITS/MAINT CHECKS 1A22 DIMENSIONS AND AREAS 1B16 LIFTING AND SHORING LEVELING AND WEIGHING TOWING AND TAXIING 1C14...
  • Page 8 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GAMA SYSTEM/CHAPTER INDEX GUIDE (cont) SYST SUB-SYST AEROFICHE CHAP SECTION TITLE GRID NO. ELECTRICAL/ELECTRONIC PANELS AND MULTI-PURPOSE PARTS STRUCTURES DOORS STABILIZERS 2J10 WINDOWS 2J19 WINGS 2J24 PROPELLER 3A18 STANDARD PRACTICES - ENGINE POWER PLANT...
  • Page 9 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL LIST OF ILLUSTRATIONS FIGURE NO. SUBJECT GRID NO. 6-1. Three View of PA-28RT-201T 1B22 6-2. Three View of PA-28RT-201 1B23 6-3. Station Reference Lines of PA-28RT-201/201T 6-4. Access Plates and Panels 7-1. Jacking Arrangements 8-1.
  • Page 10 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL LIST OF ILLUSTRATIONS (cont) FIGURE NO. SUBJECT GRID NO. 21-17. Condenser Air Scoop Installation 1G14 21-18. Expansion Valve 1G15 21-19. Components Installation 1G17 21-20. Adjustment of Air Conditioning Throttle Switch (PA-28RT-201) 1G17 21-21.
  • Page 11 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL LIST OF ILLUSTRATIONS (cont) FIGURE NO. SUBJECT GRID NO. 24-35. Installation of Drive End Head 24-36. Installation of Rectifier 24-37. Terminal Assembly (Prestolite) 24-38. Slip Ring End Bearing Assembly 24-39. Testing Alternator 24-40.
  • Page 12 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL LIST OF ILLUSTRATIONS (cont) FIGURE NO. SUBJECT GRID NO. 29-10. End Gland Locking Device 2C24 29-11. Main Gear Actuating Cylinder 32-1. Main Gear Oleo Strut Assembly 2D16 32-2. Main Gear Installation 2D17 32-3.
  • Page 13 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL LIST OF ILLUSTRATIONS (cont) FIGURE NO. SUBJECT GRID NO. 55-1. Stabilator Installation 2J13 55-2. Stabilator Balance Configuration 2J14 55-3. Vertical Fin Installation 2J15 55-4. Rudder Installation 2J17 55-5. Rudder Balancing 2J18 56-1. Windshield Installation (Typical) 2J22 56-2.
  • Page 14 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL LIST OF ILLUSTRATIONS (cont) FIGURE NO. SUBJECT GRID NO. 74-12. Assembly Tool 3D21 74-13. Assembly Tool Application 3D22 74-14. Measuring Lead Assembly Length 3D23 74-15. Ferrule Seating Tool 3D24 74-16. Measuring Wire From Top of Ferrule 3D24 74-17.
  • Page 15 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL LIST OF ILLUSTRATIONS (cont) FIGURE NO. SUBJECT GRID NO. ELECTRICAL SCHEMATICS —NOTE— Refer to Grid 313 for Electrical Schematic Index. 95-1. Tire Balancer Fixture 95-2. Control Surface Balancing Tool 95-3. Ignition Harness Ferrule Seating Tool 95-4.
  • Page 16 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL LIST OF CHARTS CHART NO. SUBJECT GRID NO. Leading Particulars and Principal Dimensions 1B18 2101 Troubleshooting (Air Conditioner) 2102 Troubleshooting (Air Conditioning System) 2103 Temperature Pressure Chart 1F12 2104 Aluminum Tubing Torque 1F15...
  • Page 17 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL LIST OF CHARTS (cont) CHART NO. SUBJECT GRID NO. 7101 Troubleshooting Chart (Engine) 3B14 7102 Engine Troubleshooting 7301 Metered Fuel Assembly Calibration 3C22 7302 Limits—Fuel Flow Vs. Brake H.P. 3C22 7401 Troubleshooting (Magneto)

  • Page 18: Airworthiness Limitations

    CHAPTER AIRWORTHINESS LIMITATIONS 1A18...
  • Page 19 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 4 - AIRWORTHINESS LIMITATIONS TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 4-00-00 AIRWORTHINESS LIMITATIONS 1A20 4-00-01 General 1A20 4 - Cont./Effec. 1A19 Page - 1 Revised: February 23, 1979...
  • Page 20 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL AIRWORTHINESS LIMITATIONS. GENERAL. The airworthiness limitations is FAA approved and specifies inspections and maintenance required under Part 91.163 of the Federal Aviation Regulations. The following limitations related to fatigue life of the airplane and its components have been established with respect to the PA-28RT-201/201T airplane: 1.
  • Page 21 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK 1A21...

  • Page 22: Time Limits/Maint Checks

    CHAPTER TIME LIMITS/MAINT CHECKS 1A22...
  • Page 23 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 5- TIME LIMITS/MAINTENANCE CHECKS TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 5-00-00 GENERAL 1A24 5-10-00 TIME LIMITS 1A24 5-10-01 Inspection Requirements 1A24 8-82 5-10-02 Preflight Checks 1A24 5-10-03 Overlimits Inspection...

  • Page 24: General

    When performing inspections, use inspection forms P/N 230 818 furnished by the Piper Factory Service Department, available through Piper Dealers or Distributors.

  • Page 25: Periodic Inspections

    PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL SCHEDULED MAINTENANCE CHECKS. PERIODIC INSPECTIONS. —NOTE— Perform all inspections or operations at each inspection interval as indicated by a circle (O). (See notes 1, 2 and 3.) Inspection Time (hrs) Nature of Inspection 1000 A.
  • Page 26 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL PERIODIC INSPECTIONS. (cont) —NOTE— Perform all inspections or operations at each of the inspection intervals as indicated by a circle (O). (See Notes 1, 2 and 3.) Inspection Time (hrs) Nature of Inspection 1000 B.
  • Page 27 42. Inspect all lines, air ducts, electrical leads and engine attachments for security, proper routing, chafing, cracks, deterioration and correct installation (See latest revision of Piper Service Bulletin 561) 43. Check air conditioning compressor oil level (See Note 15) 44. Inspect condition and tension of compressor drive belt......
  • Page 28 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL PERIODIC INSPECTIONS. (cont) —NOTE— Perform all inspections or operations at each of the inspection intervals as indicated by a circle (O). (See Notes 1, 2 and 3.) Inspection Time (hrs) Nature of Inspection 1000 C.
  • Page 29 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL PERIODIC INSPECTIONS. (cont) —NOTE— Perform all inspections or operations at each of the inspection intervals as indicated by a circle (O). (See Notes 1, 2 and 3.) Inspection Time (hrs) Nature of Inspection 1000 D.
  • Page 30 (Refer to Chapter 78) ............40. Inspect muffler, heat exchange and baffles (Refer to latest revision of Piper Service Bulletin No. 691)........41. Inspect breather tube for obstructions and security ......42. Inspect crankcase for cracks, leaks, and security of seam bolts ..
  • Page 31 7. Inspect control wheels, column, pulleys and cables......8. Inspect flap control cable attachment bolt (See latest revision of Piper Service Bulletin 965.) ..............9. Inspect landing, navigation, cabin and instrument lights....10. Inspect instruments, lines and attachments .........
  • Page 32 29. Inspect stabilator balance weight attachments and arm for security and condition.................... 30. Inspect emergency locator transmitter battery for replacement date per Maintenance Manual (Refer to latest revision of Piper Service Letter No. 820)................31. Clean and lubricate all exterior needle bearings........
  • Page 33 8. Inspect condition of bolts used with hinges (Replace as required)..9. Lubricate per lubrication chart............10. Inspect forward and aft wing attach fittings for corrosion, general condition and security. (See latest revision of Piper Service Bulletin 977.)....................11. Inspect wing attachment bolts and brackets........
  • Page 34 24. Inspect actuating cylinders for leaks and security ......25. Inspect all hydraulic lines, electrical leads, and attaching parts for security, routing, chafing, deterioration, wear and correct installation (See latest revisions of Piper Service Letters 808 and 810) ..................26. Inspect position indicator switch and electrical leads for security....................
  • Page 35 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL PERIODIC INSPECTIONS. (cont) —NOTE— Perform all inspections or operations at each of the inspection intervals as indicated by a circle (O). (See Notes 1, 2 and 3.) Inspection Time (hrs) Nature of Inspection 1000 I.
  • Page 36 PERIODIC INSPECTIONS (cont) NOTES: 1. Refer to the last card of the Piper parts price list - Aerofiche, for a check list of current revision dates to Piper inspection reports and manuals. 2. All inspections or operations are required at each inspection interval as indicated by a (O). Both the...
  • Page 37 500 hours time in service. Inspect pin for condition and replace as necessary. 26. If not already installed, add access panels per instructions in Chapter 51. See latest revision of Piper Service Bulletin 977.

  • Page 38: Programmed Inspection

    This programmed inspection schedule is prepared in a manual form which is available from Piper Service Sales under Part No. 761 736. Refer to Piper Parts Price List Aerofiche, last card for revision check list to insure obtaining latest issue.
  • Page 39 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK 1B15...

  • Page 40: Dimensions And Areas

    CHAPTER DIMENSIONS AND AREAS 1B16...
  • Page 41 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 6- DIMENSIONS AND AREAS TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 6-10-00 DIMENSIONS 1B18 2-79 6-20-00 Station Reference Lines 1B24 2-79 6-30-00 Access and Inspection Provisions 2-79 6-40-00 Weight and Balance Data...
  • Page 42 PIPER AIRCRAFT PA-28RT-201 / 201T * MAINTENANCE MANUAL DIMENSIONS. The principal airplane dimensions are shown in Figures 6-1 and 6-2 and are listed in Chart 601. CHART 601. LEADING PARTICULARS AND PRINCIPAL DIMENSIONS MODEL PA-28RT-201 PA-28RT-201T ENGINE Manufacturer Lycoming Continental...
  • Page 43 PIPER AIRCRAFT PA-28RT-201 / 201T * MAINTENANCE MANUAL CHART 601. LEADING PARTICULARS AND PRINCIPAL DIMENSIONS (cont) MODEL PA-28RT-201 PA-28RT-201T ENGINE (cont) Spark Plugs (Shielded): SR86 SR86, S86R, HSR86 Champion REM38E REM38W, RHM38W, RHM38EP, REM38P, REM38E, RHM38E Autolite SH-15 PH26, PH260...
  • Page 44 PIPER AIRCRAFT PA-28RT-201 / 201T * MAINTENANCE MANUAL CHART 601. LEADING PARTICULARS AND PRINCIPAL DIMENSIONS (cont) MODEL PA-23RT-201 PA-28RT-201T PROPELLER (cont) Blade Angle, Low Pitch* 14.0° ± 0.2° 13.2 ± .2° Blade Angle, High Pitch* 29° ± 2° 33 ± 1°...
  • Page 45 PIPER AIRCRAFT PA-28RT-201 / 201T * MAINTENANCE MANUAL CHART 601. LEADING PARTICULARS AND PRINCIPAL DIMENSIONS (cont) MODEL PA-28RT-201 PA-28RT-201T FUEL SYSTEM Fuel Tanks: Capacity (each) 38.5 gal. 38.5 gal. Unusable Fuel (each) 2.5 gal. 2.5 gal. Total Capacity 77 gal.
  • Page 46 PIPER AIRCRAFT PA-28RT-201 / 201T * MAINTENANCE MANUAL Figure 6-1. Three View of PA-28RT-201T 6-10-00 Page 6-05 1B22 Revised: August 17, 1982...
  • Page 47 PIPER AIRCRAFT PA-28RT-201 / 201T * MAINTENANCE MANUAL Figure 6-2. Three View of PA-28RT-201 6-10-00 Page 6-06 1B23 Revised: August 17, 1982...
  • Page 48 PIPER AIRCRAFT PA-28RT-201 / 201T * MAINTENANCE MANUAL STATION REFERENCE LINES. In order to facilitate the location of various components of the airplane which require maintenance and servicing, a method utilizing fuselage station (Sta.) wing station or buttock line (BL), and water line (WL) designations is frequently employed in this manual.
  • Page 49 PIPER AIRCRAFT PA-28RT-201 / 201T * MAINTENANCE MANUAL Figure 6-3. Station Reference Lines of PA-28RT-201/201T 6-20-00 Page 6-08 Revised: July 13, 1983...
  • Page 50 PIPER AIRCRAFT PA-28RT-201 / 201T * MAINTENANCE MANUAL ACCESS AND INSPECTION PROVISIONS. The access and inspection provisions for the airplane are shown in Figure 6-4. The component to be serviced or inspected through each opening is identified in the illustration. All access plates and panels are secured by either metal fasteners or screws.
  • Page 51 PIPER AIRCRAFT PA-28RT-201 / 201T * MAINTENANCE MANUAL Figure 6-4. Access Plates and Panels 6-50-00 Page 6-10 Interim Revision: February 27, 1995...
  • Page 52 PIPER AIRCRAFT PA-28RT-201 / 201T * MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK...

  • Page 53: Lifting And Shoring

    CHAPTER LIFTING AND SHORING...
  • Page 54 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 7- LIFTING AND SHORING TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 7-10-01 JACKING 7- Cont./Effec. Page - 1 Revised: February 23, 1979...
  • Page 55 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 7-1. Jacking Arrangement JACKING. Jacking the airplane is necessary to service the landing gear and to perform other service operations. Proceed as follows: 1. Place jacks under jack pads on the front wing spar. (Refer to Figure 7-1.) —NOTE—...
  • Page 56 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK...

  • Page 57: Leveling And Weighing

    CHAPTER LEVELING AND WEIGHING...
  • Page 58 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 8- LEVELING AND WEIGHING TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 8-10-01 LEVELING 1C11 8-20-01 WEIGHING 1C11 8 - Cont./Effec. Page - 1 1C10 Revised: February 23, 1979...
  • Page 59 PIPER AIRCRAFT PA-28RT-201 / 201T * MAINTENANCE MANUAL LEVELING. The airplanes are provided with a means for longitudinal and lateral leveling. The airplanes may be leveled while on jacks, during the weighing procedure while the wheels are on scales, or while the wheels are on the ground.
  • Page 60 PIPER AIRCRAFT PA-28RT-201 / 201T * MAINTENANCE MANUAL Figure 8-1. Leveling Longitudinally Figure 8-2. Leveling Laterally Figure 8-3. Weighing Arrangement 8-20-01 Page 8-02 1C12 Revised: July 13, 1983...
  • Page 61 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK 1C13...

  • Page 62: Towing And Taxiing

    CHAPTER TOWING AND TAXIING 1C14...
  • Page 63 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 9 - TOWING AND TAXIING TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 9-10-01 TOWING 1C16 9-20-01 TAXIING 1C16 9 - Cont./Effec. Page - 1 1C15 Revised: February 23, 1979...
  • Page 64 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL TOWING. The airplane may be moved by using the nose wheel steering bar that is stowed in the baggage area or power equipment that will not damage or cause excess strain to the nose gear steering assembly. The stem on the bar is inserted in the hollow of the nose wheel axle at its right side.
  • Page 65 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK 1C17...

  • Page 66: Parking And Mooring

    CHAPTER PARKING AND MOORING 1C18...
  • Page 67 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 10 - PARKING AND MOORING TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 10-10-01 PARKING 1C20 10-20-01 MOORING 1C20 10-20-02 Locking Airplane 1C20 10- Cont./Effec. Page- 1 1C19 Revised: February 23, 1979...
  • Page 68 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL PARKING. When parking the airplane, insure that it is sufficiently protected against adverse weather conditions and presents no danger to other aircraft. When parking the airplane for any length of time or overnight, it is recommended that it be moored.
  • Page 69 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK 1C21...

  • Page 70: Required Placards

    CHAPTER REQUIRED PLACARDS 1C22...
  • Page 71 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 11- REQUIRED PLACARDS TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 11-20-00 EXTERIOR PLACARDS AND MARKINGS 1C24 2R 7-81 11-30-00 INTERIOR PLACARDS AND MARKINGS 11 - Cont./Effec. Page - 1 1C23...
  • Page 73 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL INTERIOR PLACARDS AND MARKINGS. Figure 11-1. Placards and Decals (cont) 11-30-00 Page 11-02 Revised: February 23, 1979...
  • Page 74 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 75 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 76 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK...

  • Page 77: Servicing

    CHAPTER SERVICING...
  • Page 78 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL CHAPTER 12 - SERVICING TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 12-00-00 GENERAL 2-79 12-10-01 REPLENISHING 1D10 12-10-02 Fuel System 1D10 2-79 12-10-03 Filling Fuel Tanks 1D10 12-10-04 Fuel Anti-Icing Additive...
  • Page 79 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL CHAPTER 12- SERVICING (cont) TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 12-20-01 SCHEDULED SERVICING (cont) — 12-20-24 Landing Gear 1D21 12-20-25 Exterior Surfaces 1D21 12-20-26 Windshield and Windows 1D21 12-20-27 Headliner, Side Panels and Seats...
  • Page 80 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL GENERAL. Servicing the airplane includes the replenishment of fuel, oil, hydraulic fluid, tire pressures, lubrication requirements and other required items. Figure 12-1. Servicing Points (PA-28RT-201) 12-00-00 Page 12-01 Revised: February 23, 1979...
  • Page 81 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL Figure 12-2. Servicing Points (PA-28RT-201T) 12-00-00 Page 12-02 December 1, 1978...
  • Page 82 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL Figure 12-3. Fuel Strainer REPLENISHING. FUEL SYSTEM. At intervals of 50-hours or 90 days, whichever comes first, clean the fuel strainer screen, located in the fuel bowl mounted on the lower left side of the firewall, and clean the screen in the inlet side of the injector.
  • Page 83 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL —CAUTION— Assure that the additive is directed into the flowing fuel stream. The additive flow should start after and stop before the fuel flow. Do not permit the concentrated additive to come in contact with the aircraft painted surfaces or the interior surfaces of the fuel tanks.
  • Page 84 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL —CAUTION— Do not introduce any trade additive to the basic lubricant unless recommended by the engine manufacturer. FILLING OIL SUMP. The oil sump should normally be filled with oil to the mark on the engine dipstick. The quantity of oil required for the engines may be found in Chapter 6.
  • Page 85 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL 4. On Lycoming engines proceed as follows: A. After the element has been replaced, tighten the attaching bolt 15 to 18 foot-pounds of torque. B. Lockwire the bolt through the loops on the side of the housing to the drilled head of the thermostatic valve.

  • Page 86: Landing Gear

    PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL SCHEDULED SERVICING. LANDING GEAR. The landing gear consists of tires, brakes and oleo strut assemblies. These should be inspected for proper gear extension, scored piston tubes, possible hydraulic fluid leakage and security and condition of all connection points.
  • Page 87 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL FILLING OLEO STRUTS. To fill the nose or main gear oleo strut with fluid (MIL-H-5606), whether it be the addition of a small or large amount, proceed as follows: 1. Raise the airplane on jacks.
  • Page 88 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL 5. With the airplane raised, compress and extend the gear strut several times to ascertain that the strut actuates freely. The weight of the gear fork and wheel should extend the strut. 6. Clean off overflow of fluid and inflate the strut as described in Inflating Oleo Struts.
  • Page 89 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL TIRE BALANCE. Proper balancing is critical for the life of aircraft tires. If a new tire is balanced upon installation it will usually remain balanced for the life of the tire without having any shimmy or flat spots, and an inexpensive balancer can be made that will balance almost any tire for light aircraft.
  • Page 90 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL SERVICING HYDRAULIC PUMP/RESERVOIR. The fluid level of the reservoir of the combination pump and reservoir should be checked every 50 hours by viewing the fluid through the filler plug hole in the hydraulic pump. Access to the pump is through the panel at the right rear side of the baggage compartment.
  • Page 91 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL SERVICE INSTRUCTIONS. (Cleaning and Inspection) 1. The filter should be cleaned daily when operating in dusty conditions and if any holes or tears are noticed, the filter should be replaced immediately. For replacement filter, refer to Parts Catalog.
  • Page 92 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL POWER PLANT. Regularly check the engine compartment for oil and fuel leaks, chafing of lines, loose wires and tightness of all parts. Maintenance instructions for the power plant may be found in Chapter 71 of this manual and in the appropriate manufacturer’s manuals.

  • Page 93: Exterior Surfaces

    PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL LANDING GEAR. Before cleaning the landing gear, place a plastic cover or similar material over the wheel and brake assembly. 1. Place a pan under the gear to catch waste. 2. Spray or brush the gear area with solvent or a mixture of solvent and degreaser, as desired. It may be necessary to brush areas that were sprayed where heavy grease and dirt deposits have collected in order to clean them.

  • Page 94: Carpets

    PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL HEADLINER, SIDE PANELS AND SEATS. 1. Clean headliner, side panels and seats with a stiff bristle brush and vacuum where necessary. 2. Soiled upholstery, except leather, may be cleaned by using an approved air type cleaner or foam upholstery cleaner.

  • Page 95: Lubrication Charts

    PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL 3. Squeeze the magneto cam follower felt at regular inspection periods. If oil appears on fingers, do not add oil. If the felt is dry, moisten with light oil. —CAUTION— Be careful not to add too much oil, because the excess will be thrown off during operation and will cause pitting and burning of the magneto points.
  • Page 96 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL COMPONENT LUBRICANT FREQUENCY MAIN GEAR PIVOT POINTS MIL-G-23827 100 HRS MAIN GEAR DOOR HINGE MIL-L-7870 100 HRS MAIN GEAR TORQUE LINKS MIL-L-7870 100 HRS EXPOSED OLEO STRUT MAIN MIL-L-60326 100 HRS MAIN GEAR WHEEL BEARINGS...
  • Page 97 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL Figure 12-4. Lubrication Chart (Landing Gear, Main) (cont) 12-20-32 Page 12-18 December 1, 1978...
  • Page 98 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL COMPONENT LUBRICANT FREQUENCY NOSE GEAR STRUT HOUSING GREASE FITTING MIL-G-23827 100 HRS NOSE GEAR PIVOT POINT AND HYDRAULIC CYLINDER ROD END MIL-L-7870 100 HRS NOSE GEAR DOOR RETRACTION MECHANISM MIL-L-7870 100 HRS NOSE GEAR DOOR HINGES...
  • Page 99 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL Figure 12-5. Lubrication Chart (Landing Gear, Nose) (cont) 12-20-32 Page 12-20 December 1, 1978...
  • Page 100 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL —CAUTION— Do not lubricate control wheel shaft or bushing. Clean only using alcohol or other suitable solvent. COMPONENT LUBRICANT FREQUENCY AILERON HINGE PINS MIL-L-7870 100 HRS FLAP HINGE BEARINGS MIL-L-7870 100 HRS STABILATOR HINGE PINS...
  • Page 101 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL COMPONENT LUBRICANT FREQUENCY FLAP TORQUE TUBE BEARING BLOCKS MIL-L-7870 100 HRS FLAP CONTROL ROD END BEARINGS MIL-L-7870 100 HRS FLAP HANDLE PIVOT POINT, LOCK MECHANISM AERO LUBRIPLATE, MAG-1 AND TURNBUCKLE END OR AERO SHELL #7...
  • Page 102 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL COMPONENT LUBRICANT FREQUENCY RUDDER TUBE BEARING BLOCKS FLUOROCARBON RELEASE AGENT DRY LUBRICANT MS-122 100 HRS TOE BRAKE CYLINDER ATTACHMENTS MIL-L-7870 100 HRS RUDDER TUBE CONNECTIONS MIL-L-7870 100 HRS BRAKE ROD ENDS MIL-L-7870 100 HRS...
  • Page 103 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 104 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL COMPONENT LUBRICANT FREQUENCY DOOR HINGES MIL-L-7870 100 HRS DOOR SEALS MIL-L-60326 50 HRS DOOR LATCH MECHANISMS AERO LUBRIPLATE, MAG-1 FISKE BROS. REFINING CO. OR AERO SHELL #7 500 HRS SEAT TRACK ROLLERS, STOP PINS AND REAR SEAT...
  • Page 105 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL COMPONENT LUBRICANT FREQUENCY 1. ENGINE SUM LYCOMING) MIL-L-6082 LUBRICATING PA-28RT-201 ONLY OIL, AIRCRAFT RECIPRO- CATING ENGINE (PISTON) GRADE AS SPECIFIED, SAE 50 ABOVE 60°F AIR TEMP., SAE 40 30° TO 90°F AIR TEMP., SAE 30 0°...
  • Page 106 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL COMPONENT LUBRICANT FREQUENCY 1. ENGINE OIL SUMPS (CONTINENTAL) CONTINENTAL SPECIFI- PA-28RT-201T ONLY CATION MHS-24A AND SERVICE BULLETIN M75-2 100 HRS 2. OIL FILTER 50 HRS INDUCTION AIR FILTERS CLEAN AS OFTEN AS NECESSARY, EVERYDAY...
  • Page 107 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL COMPONENT LUBRICANT FREQUENCY DIAPHRAGM SHAFT AND BUSHING MIL-L-7870 ABOVE 20°F MIL-C-21567 BELOW 20°F 100 HRS BACK-UP EXTENDER LINKS AND CONTROL ARM PIVOT POINTS MIL-L-7870 100 HRS BACK-UP EXTENDER SPRING ATTACHMENT POINTS MIL-L-7870 100 HRS...
  • Page 108 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL COMPONENT LUBRICANT FREQUENCY 1. CONDENSER HINGE AND ACTUATORS MIL-L-7870 100 HRS 2. CONDENSER DOOR ACTUATING TRANSMISSION MIL-G-23827 500 HRS SPECIAL INSTRUCTIONS Transmission to be 1/2 full of grease. Apply grease during assembly and lubricate transmission ball nut and screw with MIL-G-23827 grease.
  • Page 109 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK 1E13...
  • Page 110 CHAPTER STANDARD PRACTICES/ AIRFRAME 1E14...
  • Page 111 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL CHAPTER 20- STANDARD PRACTICES/AIRFRAME TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 20-00-00 STANDARD PRACTICES - AIRFRAME 1E16 20-00-01 Torque Wrenches 1E16 20-00-02 Method of Installing Rod End Bearings 1E17 20-10-00 AIRCRAFT FINISH CARE (CLEANING)

  • Page 112: Torque Wrenches

    PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL STANDARD PRACTICES - AIRFRAME. TORQUE WRENCHES. Torque wrenches should be checked daily and calibrated by means of weights and a measured lever arm to make sure that inaccuracies are not present. Checking one torque wrench against another is not sufficient and is not recommended.
  • Page 113 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL METHOD OF INSTALLING ROD END BEARINGS. Figure 20-2. Method of Installing Rod End Bearings 20-00-02 Page 20-02 1E17 December 1, 1978...

  • Page 114: Exterior Surfaces

    PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL AIRCRAFT FINISH CARE. (Cleaning) EXTERIOR SURFACES. The airplane should be washed with a mild soap and water. Harsh abrasives or detergents used on painted or plastic surfaces could make scratches or cause corrosion of metal surfaces. Cover areas where cleaning solution could cause damage.

  • Page 115: Carpets

    PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL CARPETS. Use a small whisk broom or vacuum to remove dirt. For soiled spots, use a non-inflammable dry-cleaning fluid. ENGINE COMPARTMENT. Before cleaning the engine compartment, place a strip of tape on the magneto vents to prevent any solvent from entering these units.
  • Page 116 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK 1E20...

  • Page 117: Environmental System

    CHAPTER ENVIRONMENTAL SYSTEM 1E21...
  • Page 118 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 21 - ENVIRONMENTAL SYSTEM TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 21-00-00 GENERAL 1E24 21-00-01 Description and Operation 1E24 21-00-02 Troubleshooting 1E24 21-40-00 HEATING 1F10 21-40-01 Heater Maintenance 1F10 21-40-02 Overhead Vent System “Not Available With...
  • Page 119 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 21 - ENVIRONMENTAL SYSTEM (cont) TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 21-50-00 COOLING (cont) — 21-50-29 Condenser 1G13 21-50-30 Condenser Assembly Removal 1G13 21-50-31 Condenser Installation 1G13 21-50-32 Condenser Door Actuator...
  • Page 120 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GENERAL. DESCRIPTION AND OPERATION. Because of the simplicity of the heating and ventilating system installed on both the PA-28RT-201 and PA- 2 8 RT-201T models the operation and maintenance instructions of the components are contained in Heater Maintenance.
  • Page 121 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2101. TROUBLESHOOTING (AIR CONDITIONER) Gauge Indication Probable Causes Remedy High discharge pressure. Overcharge of refrigerant. Purge excess refrigerant. Air in system. Check for leaks. Bleed charge from system. Evac- uate and recharge system.
  • Page 122 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2101. TROUBLESHOOTING (AIR CONDITIONER) (cont) Gauge Indication Probable Causes Remedy Low suction pressure. Undercharge of refrigerant. Add refrigerant. Install new (Evaporator not cold enough) Moisture freezing in ex- dryer. Evacuate and recharge.
  • Page 123 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2102. TROUBLESHOOTING (AIR CONDITIONING SYSTEM) Trouble Cause Remedy Door will not close when Faulty relay “K-2.” Replace relay. air conditioner switch is in OFF position. System produces no Electrical cooling. Blown fuse in control Replace fuse.
  • Page 124 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2102. TROUBLESHOOTING (AIR CONDITIONING SYSTEM) (cont.) Trouble Cause Remedy System produces no Refrigeration cooling. (cont) Broken refrigerant line. Examine all lines for evidence of breakage by external stress or rubbing wear. Leak in system.
  • Page 125 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2102. TROUBLESHOOTING (AIR CONDITIONING SYSTEM) (cont) Trouble Cause Remedy System will not produce Refrigeration sufficient cooling. (cont) Insufficient refrigerant in Recharge system until bub- system. bles disappear in receiver- dehydrator and gauge readings stabilize to specifi- cations.
  • Page 126 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2102. TROUBLESHOOTING (AIR CONDITIONING SYSTEM) (cont) Trouble Cause Remedy Excessively noisy system. Electrical (cont) Compressor noisy. Check mountings and re- pair; remove compressor for service or replacement. Compressor oil level low. Fill with correct amount of specified oil.
  • Page 127 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 21-1. Cabin Heater, and Defroster (PA-28RT-201) 21-00-01 Page 21-08 December 1, 1978...
  • Page 128 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 21-2. Cabin Heater and Defroster (PA-28RT-201T) 21-00-01 Page 21-09 December 1, 1978...
  • Page 129 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 21-3. Overhead Vent System and Fresh Air System “NOT AVAILABLE WITH AIR CONDITIONING” 21-00-01 Page 21-10 December 1, 1978...
  • Page 130 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL HEATING. HEATER MAINTENANCE. If the exhaust manifold should become defective, carbon monoxide fumes may be discharged into the cabin area, therefore it is imperative that the exhaust manifold (on PA-28RT-201) be inspected regularly. The heater exchanger must be removed in order to inspect the tailpipe on PA-28RT-201T;...
  • Page 131 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL COMPRESSOR PRESSURE SWITCH FREON LINES RECEIVER DEHYDRATOR ALTERNATOR EVAPORATOR PULLEY POSITIONS SLOWER MOTOR DUCT ASSEMBLY CONDENSER EVAPORATOR FILTER AND COVER COVER ASSEMBLY EXPANSION VALVE BELLCRANK ASSEMBLY Figure 21-4. Air Conditioning System Installation 21-50-01...
  • Page 132 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2103. TEMPERATURE PRESSURE CHART Evaporator Pressure Evaporator High Pressure Ambient Gauge Reading Temperature Gauge Reading Temperature p.s.i. ° F. p.s.i. ° F. 10.1 11.2 12.3 13.4 14.6 15.8 17.1 18.3 19.7 22.4 23.1...
  • Page 133 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL —NOTE— The air conditioning system should be operated at least once a month to prevent sticking valves and keep the system lubricated. MALFUNCTION DETECTION. The detection of system malfunction largely depends on the mechanic’s ability to interpret the gauge pressure readings into system problems.
  • Page 134 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL SPECIAL SERVICING PROCEDURES. The air conditioning system should be serviced by a qualified shop with trained personnel. The following procedures and precautions should be observed: The efficiency of this system depends upon the pressure-temperature relationship of pure refrigerant. As long as the system contains only pure refrigerant plus a specified amount of compressor oil (which is mixed with the refrigerant), it is considered to be chemically stable.
  • Page 135 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL (7) When Loctite Refrigerant Sealant has been used on a joint it must be heated to 400°F prior to disassembly. Loctite must be used to seal any pipe threads in the system lines.
  • Page 136 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 21-5. Service Valves Figure 21-6. Test Gauge and Manifold Set 21-50-04 Page 21-17 1F16 December 1, 1978...
  • Page 137 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL SERVICE VALVE REPLACEMENT. The valves on the York compressor are sealed with a gasket placed in the valve port boss. Lubricate the gasket with refrigerant oil of the type used in the compressor, place the valves with the tube fitting facing aft and secure with .312 bolts, torque to 15-23 inch-pounds.
  • Page 138 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 21-7. Manifold Set Operation 21-50-07 Page 21-19 1F18 December 1, 1978...
  • Page 139 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 21-8. Leak Test Hookup LEAK CHECK - METHOD I. 1. Connect the manifold gauge set into the system and determine if there is any refrigerant in the system. A minimum of 50 psi refrigerant pressure in the system is needed for leak detection. (Refer to Figure 21-8.) 2.
  • Page 140 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL LEAK CHECK - METHOD II. 1. Remove the access panel at the rear of the cabin to gain access to the service valves. 2. Remove the protective cap on the high pressure Schrader valve fitting and connect a charging hose with a shut-off valve arrangement to the fitting.
  • Page 141 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 21-9. Evacuation Hookup EVACUATING THE SYSTEM. If the system has been operated in a discharged condition or anytime the system has been open to atmospheric pressure, the receiver-dehydrator must be replaced and the system evacuated to remove any trapped air and moisture which has entered it.
  • Page 142 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL The following steps should be of help when performing this operation. 1. Remove access panel at the rear of the cabin to gain access to the Schrader service valves. —CAUTION— Ascertain that all system pressure is released before attempting the evacuation.
  • Page 143 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL WITH A CHARGING STAND. This is the preferred method of charging the system. —NOTE— The following instructions apply to Kent Moore, J23500 charging stand. (Refer to Figure 21-10.) 1. With the system discharged and evacuated, proceed to hook-up the charging stand. (Refer to Figure 21-11.)
  • Page 144 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 21-10. Charging Stand Figure 21-11. Charging Hookup 21-50-14 Page 21-25 1F24 December 1, 1978...
  • Page 145 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 1. With the system evacuated as outlined in Evacuating the System, connect the refrigerant charging hose to the manifold (refer to Figure 21-11) and purge the charging hose of air. 2. Place the refrigerant container on a scale to observe the amount of refrigerant entering the system.
  • Page 146 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 9. Close the refrigerant valve and check to see that the sight glass remains clear during system operation. 10. When the sight glass stays clear of bubbles, add an additional 1/4 pound of refrigerant to the system.
  • Page 147 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL F. Loosen the bolt securing the compressor idler pulley to release the belt tension and remove belt from compressor pulley. (Do not force belt over the pulleys.) G. Support the compressor and remove the six bolts securing the compressor to the engine mounting brackets.
  • Page 148 F. The compressor should never be operated with less than 6 ounces of oil. When oil is added the level should not go above 10 ounces. Piper refrigerant oil PMS-L2000 or equivalent 500 viscosity refrigerant oil must be used.
  • Page 149 G. Remove the dipstick and count the number of increments of oil. The acceptable oil level in increments is 7 to 10. This represents between 2.6 and 4.4 fluid ounces. H. When oil is added, Piper refrigerant oil PMS-L2000 or equivalent 500 viscosity refrigerant oil must be used.
  • Page 150 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 21-12. Top Dead Center Casting Mark (Sankyo Compressor) Figure 21-13. Rotation of Clutch Front Plate (Sankyo Compressor Oil Check) 21-50-20 Page 21-31 December 1, 1978...
  • Page 151 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 21-14. York Compressor and Fabricated Oil Dipstick (PA-28RT-201) 4. Route the belts to the proper pulley sheaves as shown in Figure 21-15. —CAUTION— Do not force the belts into the pulley sheaves. Remove the idler assemblies if necessary and the alternator lower mounting bolts in order to install the belts.
  • Page 152 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL B. Obtain a basic measurement from the top of the ring gear by measuring the width of the starter ring gear plus the dimension from the forward machined surface of the ring gear to the forward edge of the compressor drive belt.
  • Page 153 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 21-15. Compressor and Alternator Belt Installation (PA-28RT-201) 21-50-21 Page 21-34 December 1, 1978...
  • Page 154 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 21-16. Magnetic Clutch (York Compressor) 2. Adjust the Sankyo Compressor on the PA-28RT-201T as follows: A. Rotate the compressor to obtain tension of 100 pounds for new belt or 85 to 90 pounds for old belt.
  • Page 155 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL MAGNETIC CLUTCH. (York Compressor) MAGNETIC CLUTCH REMOVAL. (Refer to Figure 21-16.) 1. Remove the self-locking capscrew and washer from the compressor shaft. 2. Insert a 5/8 - 11UNC-2B bolt in the threaded portion of the hub and tighten. The pressure exerted by the bolt on the end of the compressor crankshaft will force off the rotor pulley assembly without damage to the clutch or compressor.
  • Page 156 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL REFRIGERANT LINES AND ROUTING. The refrigerant lines in this aircraft are flexible high pressure hoses and should be handled accordingly. The hoses in the power plant area are routed so as to provide maximum protection from heat and abrasion.
  • Page 157 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CONDENSER. The condenser is mounted in a frame assembly located in the bottom of the fuselage between stations 156.00 and 191.00. CONDENSER ASSEMBLY REMOVAL. 1. Discharge the system. (See Special Servicing Procedures and Discharging.) 2.
  • Page 158 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 21-17. Condenser Air Scoop Installation 21-50-32 Page 21-39 1G14 Revised: August 17, 1982...
  • Page 159 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 21-18. Expansion Valve CONDENSER ASSEMBLY RIGGING INSTRUCTIONS. (Refer to Figure 21-17.) The condenser assembly is actuated by an electric motor through bellcranks, push rods and limit switches. It is necessary for the condenser door to fit flush with the fuselage skin, and with increased force along the forward edge.
  • Page 160 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 1. Remove the necessary access panels and discharge system. 2. Remove the capillary coil from the outlet line. (Do not kink the capillary tube.) 3. Uncouple all related tube fittings. (See Special Servicing Procedures, B-7.) —NOTE—...
  • Page 161 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 21-19. Components Installation Figure 21-20. Adjustment of Air Conditioning Throttle Switch (PA-28RT-201) 21-50-38 Page 21-42 1G17 December 1, 1978...
  • Page 162 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL EVAPORATOR ASSEMBLY INSTALLATION. 1. Cement gasket in place on the flanges of the evaporator housing and attach the large end of the mounting gasket to the back of the housing. 2. Install the housing through the access hole with the air duct outlet on top. Mate the mounting flanges to the mating surface of the mounting panel and insert the screws.
  • Page 163 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 21-21. Air Conditioning Wiring Schematic 21-50-41 Page 21-44 1G19 Revised: July 13, 1983...
  • Page 164 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL AIR CONDITIONING THROTTLE SWITCH. This switch is responsible for shutting down the air conditioning system when the airplane is at full throttle enabling maximum performance. On the PA-28RT-201 model the switch is behind the control quadrant and is actuated by the throttle lever.
  • Page 165 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL REASSEMBLY OF BLOWER ASSEMBLY. 1. Mount the motor on the plate and secure it with the bolts, washers and nuts. Be sure that the motor nuts are snug and the shaft spins freely.
  • Page 166 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2107. BLOWER SYSTEM WIRE COLOR CODES AIRCRAFT MOTOR WIRES WIRES YY1S062 ESB- Universal Aircraft Nos. Elect. Company Harness Nos. Ground Plug Brown AC26A Receptacle Low Speed Plug Yellow Black Receptacle Medium Speed...
  • Page 167 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK 1G23...
  • Page 168 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK 1G24...

  • Page 169: Autoflight

    CHAPTER AUTO FLIGHT...
  • Page 170 CHAPTER 22 - AUTOFLIGHT TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 22-00-00 GENERAL A 8-82 22-10-00 NON-PIPER A.F.C.S. EQUIPMENT CONTACTS A 8-82 22-10-01 PIPER A.F.C.S. EQUIPMENT A 8-82 22 - Cont./Effec. Page - 1 Revised: August 17, 1982...
  • Page 171 This includes mechanical service such as; adjusting bridle cable tension, servo removal and installation, servo clutch adjustments, etc. NON-PIPER A.F.C.S. EQUIPMENT CONTACTS. Refer to the following list of AutoPilot/Flight Director manufacturers to obtain service direction, parts support, and service literature: Bendix Avionics Division 2100 N.W.
  • Page 172 PA-28RT-201 / 201T MAINTENANCE MANUAL PIPER A.F.C.S. EQUIPMENT. In the case of early models, Piper AutoPilot equipment bears the Piper name, and the appropriate Piper AutoPilot/Flight Director Service Manual shall be used. —NOTE— If a Roll Axis-only AutoPilot is installed, or if no AutoPilot is installed, consult the Piper Pitch Trim Service Manual - 753 771 for manual electric pitch trim service information.
  • Page 173 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 174 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 175 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK...

  • Page 176: Communications

    CHAPTER COMMUNICATIONS...
  • Page 177 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 23- COMMUNICATIONS TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 23-00-00 GENERAL 1H10 23-10-00 EMERGENCY LOCATOR TRANSMITTER 1H10 23-10-01 Description 1H10 7-81 23-10-02 Battery Removal and Installation (C.C.C.) 1H10 7-81 23-10-03...

  • Page 178: Electrical Power

    PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GENERAL. This section of the manual contains information necessary to perform operational checks of the Emergency Locator Transmitter (ELT), with and without a pilot’s remote switch. Included are the appropriate removal and installation instructions to facilitate battery replacement.
  • Page 179 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL BATTERY REMOVAL AND INSTALLATION (NARCO). (Refer to Figures 23-1 and 23-2.) 1. Set the ON/OFF/ARM switch on the transmitter to OFF. 2. Disconnect antenna coaxial cable from ELT. 3. Remove ELT from its mounting bracket by releasing the latch on the strap and sliding the ELT off the bracket.
  • Page 180 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 23-1. ELT Portable Folding Antenna (Narco) Figure 23-2. ELT Using Fixed Aircraft Antenna (Narco) 23-10-03 Page 23-03 1H12 Added: July 24, 1981...
  • Page 181 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL PILOT’S REMOTE SWITCH. A pilot’s remote switch, located on the left side panel, is provided to allow the transmitter to be controlled from inside the cabin. The pilot’s remote switch is placarded ON, AUTO/ ARM and OFF/ RESET. The switch is normally left in the AUTO/ ARM position.
  • Page 182 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 4. A transmitter which is functioning properly should emit a characteristic downward swept tone. 5. When the test is completed, ascertain the transmitter ON/ARM/OFF switch is in the ARM position. 6. Place the access panel on the right side of the fuselage aft of sta. 228.30.
  • Page 183 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL INADVERTENT ACTIVATION. The remote switch allows the pilot to turn off the transmitter inadvertently activated by impact or improper switch selection. The pilot simply selects the momentary OFF, RESET position. The transmitter shuts off and the spring loaded switch automatically returns to the ARM position.
  • Page 184 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL OTE: AIRCRAFTG POWER USED TO SHUT OFF THE ELT WITH REMOTE SWITCH Figure 23-3. ELT Schematics 23-10-07 Page 23-07 1H16 Revised: July 24, 1981...
  • Page 185 CHAPTER ELECTRICAL POWER 1H17...
  • Page 186 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 24 - ELECTRICAL POWER TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 24-00-00 GENERAL 1H20 8-82 24-01-00 Description and Operation 1H20 2-79 24-02-00 Troubleshooting 1H20 24-30-00 D.C. GENERATOR 24-31-00 Description of Alternator System...
  • Page 187 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 24 - ELECTRICAL POWER (cont) TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 24-30-00 D.C. GENERATION (cont) — 24-34-00 Battery 24-34-01 Servicing Battery 2-79 24-34-02 Removal of Battery 2-79 24-34-03 Installation of Battery...
  • Page 188 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GENERAL. This section contains instructions for correcting difficulties which may arise in the operation of the electrical system in PA-28RT-201 and PA-28RT-201T airplanes. The instructions are organized so the mechanic can refer to: Description and Principles of Operation for a basic understanding of the various electrical systems;...
  • Page 189 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2401. TROUBLESHOOTING (ALTERNATOR) Trouble Cause Remedy Zero output indicated on Open field circuit. With master switch turned ammeter regardless of RPM. on, check for battery voltage (Refer to alternator system from airplane’s main buss test procedure.)
  • Page 190 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2401. TROUBLESHOOTING (ALTERNATOR) (cont) Trouble Cause Remedy Zero output indicated on Open field winding in Disconnect field terminal of ammeter regardless of RPM. alternator. alternator from field wiring (Refer to alternator system and check for continuity from test procedure.) (cont)
  • Page 191 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2401. TROUBLESHOOTING (ALTERNATOR) (cont) Trouble Cause Remedy Output indicated on am- High resistance connections Check visually for loose bind- meter does not meet min- in field or output circuit. ing posts at the various junc-...
  • Page 192 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2401. TROUBLESHOOTING (ALTERNATOR) (cont) Trouble Cause Remedy Field circuit breaker trips. Short circuit in field wind- Disconnect field wiring at (cont) ing of alternator. terminal of alternator. Turn on master switch. Reset...
  • Page 193 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2401. TROUBLESHOOTING (ALTERNATOR) (cont) Trouble Cause Remedy Output circuit defective. Battery charged backwards. Remove battery. Connect (cont) load such as landing light lamp or similar load and dis- charge battery. Recharge with correct polarity and test each cell for signs of damage due to reversed charging.
  • Page 194 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2402. TROUBLESHOOTING (BATTERY) Trouble Cause Remedy Discharged battery. Battery worn out. Replace battery. Low electrical system Check voltage regulator voltage. voltage. Standing too long. Remove and recharge battery if left in unused airplane three weeks or more.
  • Page 195 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2402. TROUBLESHOOTING (BATTERY) (cont) Trouble Cause Remedy Excessive corrosion inside Spillage from overfilling. Use care in adding water. container. Vent lines leaking or Repair or clean. clogged. Charging rate too high. Check voltage regulator voltage.
  • Page 196 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2403. TROUBLESHOOTING (ANNUNCIATOR PANEL) Trouble Cause Remedy All warning lights fail to Blown fuse. Replace the 5 amp fuse be- operate. hind instrument panel. No current from bus. Check all wire segments,...
  • Page 197 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2403. TROUBLESHOOTING (ANNUNCIATOR PANEL) (cont) Trouble Cause Remedy VAC warning light fails to Bulb burned out. Replace. operate. No current to sensor. Check all wire segments and connections. Sensor activates at a too Replace.
  • Page 198 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL D.C. GENERATION. DESCRIPTION OF ALTERNATOR SYSTEM. The PA-28RT-201 alternator is located on the front lower right side of the engine and utilizes a belt drive from the engine crankshaft. The PA-28RT-201T alternator is mounted on the accessory case at the rear of the engine.
  • Page 199 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHECKING ALTERNATOR SYSTEM. With all electrical equipment off (except master switch) the ammeter will indicate the amount of charging current demanded by the battery. This amount will vary, depending on the percentage of charge in the battery at the time.
  • Page 200 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL SERVICE PRECAUTIONS. Since the alternator and regulator are designed for use on only one polarity system, the following precautions must be observed when testing or servicing the electrical system. Failure to observe these precautions will result in serious damage to the electrical equipment.
  • Page 201 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL ALTERNATOR SYSTEM (CHRYSLER). BENCH TESTING ALTERNATOR. ROTOR FIELD COIL CURRENT DRAW. (Refer to Figure 24-3.) 1. Connect a jumper wire between one field terminal of the alternator and the positive terminal of a fully charged battery.
  • Page 202 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 24-2. Exploded View of Alternator (Chrysler) Figure 24-3. Checking Field Coil Current Draw Figure 24-4. Testing Field Circuit 24-32-03 EFFECTIVITY: Page 24-15 1I10 CHRYSLER ALTERNATOR Revised: July 13, 1983...
  • Page 203 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL INSPECTION. Inspect the condition of the alternator components paying special attention to the condition of the slip rings for indications of oil, being burnt or worn. Inspect brushes for signs of sticking in holder or shield and for wear.
  • Page 204 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 24-5. Testing Positive Rectifiers Figure 24-6. Testing Negative Rectifiers With C-3829 Tester With C-3829 Tester Figure 24-7. Rectifier End Shield and Stator Assembly 24-32-06 EFFECTIVITY: Page 24-17 1I12 CHRYSLER ALTERNATOR Revised: July 13, 1983...
  • Page 205 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL TESTING OF NEGATIVE RECTIFIERS USING C-3829 TESTER. (Refer to Figure 24-6.) 1. Observe CAUTION noted in “Testing of Rectifier Assemblies.” 2. Connect test lead “alligator” clip to rectifier end housing. 3. Touch the metal strap of each of the negative rectifiers with the test probe and note the reading of each.
  • Page 206 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 24-8. Testing Positive Rectifiers Figure 24-9. Testing Negative Rectifiers With Test Lamp With Test Lamp Figure 24-l0. Rectifier and Heatsink Figure 24-l l. Rectifier End Shield Assembly Assembly Removal 24-32-08 EFFECTIVITY: Page 24-19...
  • Page 207 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL REMOVAL OF RECTIFIER AND HEATSINK ASSEMBLY. (Refer to Figure 24-10.) —NOTE— If negative heatsink rectifier straps are under the positive heatsink straps, proceed to Step 2. 1. Remove the four screws which secure the negative rectifier and heatsink assembly to the rectifier end shield and lift the heatsink assembly from the end shield.
  • Page 208 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 24-12. Testing Stator Figure 24-13. Removal of Pulley Figure 24-14. Removal of Bearing Figure 24-15. Removal of Rectifier End Shield Bearing 24-32-11 EFFECTIVITY: Page 24-21 1I16 CHRYSLER ALTERNATOR Revised: July 13, 1983...
  • Page 209 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL TESTING OF ROTOR. 1. Check for a “grounded” field coil by connecting an ohmmeter from each slip ring to the rotor shaft. The ohmmeter should read infinite. If the reading is zero or higher, the rotor is grounded.
  • Page 210 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 24-18. Installation of Grease Retainer Figure 24-l9. Installation of Rectifier End Shield Bearing Figure 24-20. Installation of Drive End Figure 24-21. Installation of Pulley Shield Bearing 24-32-14 EFFECTIVITY: Page 24-23 1I18 CHRYSLER ALTERNATOR...
  • Page 211 —NOTE— Models with S/N PA-28R-7918001 thru 28R-8218017, the capacitor is located on the aft alternator bracket per Piper Kit No. 764 372v. This kit when installed will provide improved service life of the alternator bracketry and filter capacitor.
  • Page 212 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 24-22. Installation of Insulators Figure 24-23. Installation of Positive Rectifier Assembly Figure 24-24. Installation of Capacitor Figure 24-25. Installation of Battery Output Insulator 24-32-14 EFFECTIVITY: Page 24-25 1I20 CHRYSLER ALTERNATOR Revised: July 13, 1983...
  • Page 213 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 14. Install the hex-head screws through the end shield and into the heatsink assembly. Torque 15 to 25 inch-pounds. 15. Position the stator over the rectifier end shield assembly and place the winding terminals on the terminal block studs.
  • Page 214 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL ALTERNATOR SYSTEM (PRESTOLITE). ALTERNATOR NOMENCLATURE. 1. Bearings: These units have a sealed ball bearing at the drive end and a two-piece roller bearing at the slip ring end. The inner race is pressed onto the rotor shaft and the rest of the bearing is in the slip ring end head.
  • Page 215 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL DESCRIPTION OF ALTERNATOR. (Refer to Figure 24-28.) The principal components of the alternator are the brush holder assembly, the slip ring end head, the rectifiers, the stator, the rotor and the drive end head.
  • Page 216 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 24-29. Removal of Slip Ring Figure: 24-30. Removal of Rectifier End Bearing THIS SPACE INTENTIONALLY LEFT BLANK 24-33-03 EFFECTIVITY: Page 24-29 1I24 PRESTOLITE ALTERNATOR Revised: July 13, 1983...
  • Page 217 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL OVERHAUL OF ALTERNATOR. When repairing the alternator, complete disassembly may not be required. In some cases it will only be necessary to perform those operations which are required to effect the repair. However, in this section, the complete overhaul is covered step-by-step to provide detailed information on each operation.
  • Page 218 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 24-31. Removal of Drive End Head Figure 24-32. Removal of End Head Bearing Figure 24-33. Testing Rotor for Ground Figure 24-34. Testing Rotor for Shorts 24-33-06 EFFECTIVITY: Page 24-31 PRESTOLITE ALTERNATOR Revised: July 13, 1983...
  • Page 219 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 2. Rectifiers: A diode rectifier tester will detect and pinpoint open or shorted rectifiers without going through the operation of disconnecting the stator leads. However, if a tester is not available, test probes and a No.
  • Page 220 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 24-35. Installation of Drive End Head Figure 24-36. Installation of Rectifier Figure 24-37. Terminal Assembly (Prestolite) 24-33-07 EFFECTIVITY: Page 24-33 PRESTOLITE ALTERNATOR Revised: July 13, 1983...
  • Page 221 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 5. Install the slip ring end bearing and oil seal. Make sure the lip of the oil seal is toward the bearing. Stake the seal in place. Correct assembly of bearing, seal, inner race and spacer as shown in Figure 24-38.
  • Page 222 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 24-38. Slip Ring End Bearing Assembly Figure 24-39. Testing Alternator CHART 2404. ALTERNATOR SPECIFICATIONS (PRESTOLITE) Aircraft Model PA-28RT-201 PA-28RT-201T Alternator Model ALY 6422 ALX 9425 Voltage 12-volts 12-volts Rated Output 60 amperes...
  • Page 223 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL Figure 24-40. Brush Installation Figure 24-41. Internal Wiring Diagram CHECKING ALTERNATOR BELT TENSION. (PA-28RT-201) For aircraft with air conditioning installed, see Chapter 21, Replacement of Compressor and/or Alternator Drive Belts. BATTERY. SERVICING BATTERY.
  • Page 224 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL REMOVAL OF BATTERY. 1. Make access to the battery as explained in the Description and Operation section of this chapter. 2. Remove battery box cover. 3. Disconnect the battery cables. —NOTE— Always remove the ground cable first and install last to prevent accidental short circuiting or arching.
  • Page 225 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL BATTERY BOX CORROSION PREVENTION. The battery should be checked for spilled electrolyte or corrosion at least each 50 hour inspection or at least every 30 days, whichever comes first. Should this be found in the box, on the terminals or around the battery, the battery should be removed and both the box and battery cleaned by the following procedure: 1.
  • Page 226 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 6. The voltage regulator heat sink, or case, is the ground connection for the electronic circuit. Therefore, if this unit is tested on the bench it is most important that a wire, No. 14, be connected between the regulator case and the alternator.
  • Page 227 1. Turn aircraft MASTER SWITCH to OFF position. 2. Ensure that the RED lead of PEP (Piper External Power) kit jumper cable is connected to the POSITIVE (+) terminal of the external 12-volt battery and that the BLACK lead is connected to the NEGATIVE terminal.
  • Page 228 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL STARTING THROUGH EXTERNAL POWER RECEPTACLE WITH AIRPLANE’S BATTERY NEARLY DEPLETED. —NOTE— Should the hydrometer reading indicate less than 1190, the battery should be removed and recharged or replaced. 1. When using a 12-volt battery for external power starting and the airplane’s battery is nearly depleted, the following procedure should be used: A.
  • Page 229 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK 1J13...
  • Page 230 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK 1J14...
  • Page 231 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK 1J15...
  • Page 232 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK 1J16...

  • Page 233: Flight Controls

    CHAPTER FLIGHT CONTROLS 1J17...
  • Page 234 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 27 - FLIGHT CONTROLS TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 27-00-00 GENERAL 1J20 27-00-01 Description and Operation 1J20 2R 7-83 27-00-02 Troubleshooting 1J20 1R 2-79 27-00-03 Standard Procedures 27-05-00...
  • Page 235 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 27 - FLIGHT CONTROLS (cont) TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 27-35-00 STABILATOR TRIM CONTROLS 27-35-01 Removal of Stabilator Trim Assembly (Forward) 1R 2-79 27-35-02 Installation of Stabilator Trim Assembly (Forward)
  • Page 236 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GENERAL. This chapter contains the explanation for the removal, installation, rigging and adjustment procedures for the control assemblies of the various structural surfaces. The assemblies need not be removed in order of paragraphs since each paragraph describes the individual removal and installation of the component.
  • Page 237 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2701. TROUBLESHOOTING (SURFACE CONTROLS) Trouble Cause Remedy AILERON CONTROL SYSTEM Lost motion between control Cable tension too low. Adjust cable tension. wheel and aileron. Linkage loose or worn. Check linkage and tighten or replace.
  • Page 238 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2701. TROUBLESHOOTING (SURFACE CONTROLS) (cont) Trouble Cause Remedy AILERON CONTROL SYSTEM (cont) Incorrect aileron travel. Aileron control rods not ad- Adjust control rods. justed properly. Aileron bellcrank stops not Adjust bellcrank stops.
  • Page 239 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2701. TROUBLESHOOTING (SURFACE CONTROLS) (cont) Trouble Cause Remedy RUDDER CONTROL SYSTEMS (cont) Excessive resistance to rud- Cables not in place on Install cables correctly. Check der pedal movement. (cont) pulleys. cable guards.
  • Page 240 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2701. TROUBLESHOOTING (SURFACE CONTROLS) (cont) Trouble Cause Remedy STABILATOR CONTROL SYSTEM (cont) Resistance to stabilator Pulleys binding or rubbing. Replace binding pulleys and/ control movement. (cont) or provide clearance between pulleys and brackets.
  • Page 241 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2701. TROUBLESHOOTING (SURFACE CONTROLS) (cont) Trouble Cause Remedy STABILATOR TRIM CONTROL SYSTEM FLOOR TRIM (cont) Trim control wheel moves Cables not in place on Install cables properly. with excessive resistance. pulleys. (cont) Trim tab hinge binding.
  • Page 242 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2702. CABLE TENSION VS. AMBIENT TEMPERATURE 27-00-02 Page 27-07 December 1, 1978...
  • Page 243 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 27-1. Rod End Installation Method 27-00-02 Page 27-08 December 1, 1978...
  • Page 244 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL STANDARD PROCEDURES. The following tips may be helpful in the removal, installation and rigging of the various assemblies: 1. It is recommended, though not always necessary to level and place the airplane on jacks during rigging and adjustment.
  • Page 245 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 27-2. Control Column Assembly 27-05-01 Page 27-10 December 1, 1978...
  • Page 246 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 2. The tee bar with assembled parts may be removed from the airplane by the following procedure: A. Remove the access panel or door to the aft section of the fuselage. B. Relieve cable tension from the stabilator control cables at one of the stabilator cable turnbuckles in the aft section of the fuselage.
  • Page 247 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL I. Set stabilator cable tension with the turnbuckle in the aft section of the fuselage and instructions given in Rigging and Adjustment of Stabilator Controls. Check safety of all turnbuckles upon completion of adjustments.
  • Page 248 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 27-3. Aileron Controls (Typical) 27-10-01 Page 27-13 December 1, 1978...
  • Page 249 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL F. Remove the cotter pins used as cable guards at the pulley in the forward area of the floor opening aft of the main spar. G. Disconnect the cable from the control chain at the control column tee bar assembly by removing the cotter pin, nut, bolt and bushing that connect the two together.
  • Page 250 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 2. The primary control cable in either wing may be installed by the following procedure: A. Draw the control cable into the wing. B. Connect the cable to the forward end of the aileron bellcrank using a bolt, washer, nut and cotter pin.
  • Page 251 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 5. Connect the ends of the primary and balance control cables to the bellcrank using bolts, washers, nuts and cotter pins. Allow the cable ends to rotate freely on the bellcrank. 6. Tighten the control cables at the balance cable turnbuckle in the floor opening aft of the main spar.
  • Page 252 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 27-4. Aileron Rigging Figure 27-5. Bellcrank Rigging Tool 27-10-05 Page 27-17 1K12 Revised: August 17, 1982...
  • Page 253 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 27-6. Aileron Rigging Tool D. Adjust the turnbuckles, located in the access opening just aft of the main spar, of the primary and balance cables to their proper cable tension and maintain neutral-center position of the control wheels.
  • Page 254 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 5. Check the bellcrank stops to assure that the bellcrank contact is made simultaneously, but still have cushion before contacting the control wheel stops. Maintain .030 to .040 clearance between sprocket pin and adjustable stop bolts on models having adjustable tee bar stops.
  • Page 255 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 27-7. Rudder and Steering Pedal Assembly 27-20-01 Page 27-20 1K15 December 1, 1978...
  • Page 256 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 14. Remove the trim side panels, if desired. 15. Rotate the rudder pedal bar assembly toward the cabin door far enough to pull the right pedal bar out. Rotate the remaining assembly to the left and remove the assembly from the aircraft. Note the spacers and washers on each end and between the support blocks.
  • Page 257 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 27-8. Rudder Controls 27-20-02 Page 27-22 1K17 Revised: November 6, 1979...
  • Page 258 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 27-9. Rudder Rigging Tool Figure 27-10. Clamping Rudder Pedals Figure 27-11. Rudder Rigging 27-20-02 Page 27-23 1K18 Revised: August 17, 1982...
  • Page 259 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL REMOVAL OF RUDDER CONTROL CABLES. (Refer to Figure 27-8.) 1. To remove either the forward or aft rudder cables, first remove the access panel to the aft section of the fuselage. 2. Disconnect the desired cable at the turnbuckle in the aft section of the fuselage.
  • Page 260 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 2. The aft rudder control cables may be installed by the following procedure: A. Position the control cable in the fuselage. B. Connect the end of the cable to the rudder sector at the turnbuckles.
  • Page 261 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 4. Disconnect the housing lug from the arm on the rudder pedal torque tube by removing cotter pin, nut, washer and bolt. 5. Remove the threaded bushing from the aft end of the mounting channel by removing cotter pin and clevis pin.
  • Page 262 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 27-12. Rudder and Stabilator Travel Adjustments Figure 27-13. Rudder Trim Control 27-30-01 Page 27-27 1K22 Revised: February 23, 1979...
  • Page 263 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 3. Either forward stabilator cable may be removed by the following procedure: A. Remove the tunnel carpet and cover plate by the following procedure: (1) Remove the rudder trim covers by removing the knobs and the attaching screws. Remove the tunnel plate located just aft of the tee bar by laying back enough tunnel carpet to remove the plate attaching screws.
  • Page 264 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 27-14. Stabilator Controls 27-30-02 Page 27-29 1K24 December 1, 1978...
  • Page 265 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 27-15. Stabilator and Stabilator Trim Travel Adjustments Figure 27-16. Stabilator Rigging Tool 27-30-02 Page 27-30 Revised: August 8, 1984...
  • Page 266 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL I. Install the floor tunnel plate and trim covers by the following procedure: (1) Install the floor tunnel plate and secure with the attachment screws. Fasten the tunnel carpet into place. Replace the rudder trim cover and the rudder trim knob.
  • Page 267 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL E. Should tension be incorrect, loosen the turnbuckle of the lower cable in the aft section of the fuselage and adjust the turnbuckle of the upper cable to obtain correct tension. Cable tension should be obtained with the control wheel at the one-half + 1/4 inch dimension from the stop and the stabilator contacting its stop.
  • Page 268 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 27-17. Methods of Securing Trim Cables G. With the cables disconnected from the trim control wheel, draw the cable(s) through the floor tunnel. INSTALLATION OF STABILATOR TRIM ASSEMBLY. (Forward) (Refer to Figure 27-18.) 1.
  • Page 269 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 27-18. Stabilator Trim Control 27-35-02 Page 27-34 Revised: February 23, 1979...
  • Page 270 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL E. Align the control cables and position the control wheel assembly between its mounting brackets. Ascertain that the end of the trim indicator wire is positioned in the spiraled slot of the drum with no bind on the end.
  • Page 271 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL INSTALLATION OF STABILATOR TRIM ASSEMBLY. (Aft) (Refer to Figure 27-18.) 1. Wrap the trim barrel by first laying the center (as measured equally from each end to the center of the cable) of the trim cable in the slot of the barrel. Bring the upper cable through the diagonal slot in the flange at the upper end of the barrel and wrap down in a counterclockwise direction.
  • Page 272 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL FLAPS. REMOVAL OF WING FLAP CONTROLS. (Refer to Figure 27-19.) 1. The flap torque tube assembly may be removed by the following procedure: A. Remove the access plate located between the underside of the aft section of each wing and the fuselage by removing attaching screws.
  • Page 273 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 27-19. Flap Controls 27-50-01 Page 27-38 Interim Revision: February 27, 1995...
  • Page 274 Ascertain that the turnbuckle end is free to rotate on the arm. * ( S e e latest revision of Piper Service Bulletin 965.) B. Route the cable through the tunnel and spar housing.
  • Page 275 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 27-20. Flap Step Adjustment Figure 27-21. Flap Rigging Tool 27-50-02 Page 27-40 1L11 Revised: August 8, 1984...
  • Page 276 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL RIGGING AND ADJUSTMENT OF WING FLAPS. 1. Place the flap handle in full forward position. 2. If not previously removed, remove the bottom half of the rear seat. 3. To adjust the flap up stop and step lock, loosen the jam nut of the right torque tube stop screw, located in the floor opening along the outer end of the flap torque tube, and turn the stop screw to obtain approximately .60 of an inch between the stop fitting and the bearing block as measured along the top side of...
  • Page 277 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 11. Check the flap for full down travel to the degrees required in Figure 27-22. Should the travel not be as that required, readjust the torque tube stop screw in or out as required. After readjusting the screw, it will be necessary to review Steps 4 through 10.
  • Page 278 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Loosen the two Phillips head screws; one on either side of the vane. If the stall warning comes on too late, move the switch up. If the stall warning comes on too early; move the switch down. Retighten the screws after making any adjustments.
  • Page 279 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GRIDS 1L15 THRU 1L24 INTENTIONALLY LEFT BLANK 1L15...
  • Page 280 Courtesy of Bomar Flying Service www.bomar.biz ARROW IV MAINTENANCE MANUAL CARD 2 OF 3 PA-28RT-201 ARROW IV PA-28RT-201T TURBO ARROW IV PIPER AIRCRAFT CORPORATION (PART NUMBER 761 694)

  • Page 281: Fuel

    PA-28RT-201 / 201T MAINTENANCE MANUAL INTRODUCTION. This PIPER AIRCRAFT Maintenance Manual is prepared in accordance with the GAMA (General Aviation Manufacturers Association) format. This maintenance manual is divided into various Groups which enable a broad separation of contents (Chapters) within each group.
  • Page 282 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL VENDOR PUBLICATIONS. ENGINE (LYCOMING): Overhaul Manual = AVCO LYCOMING - OVERHAUL MANUAL DIRECT DRIVE ENGINE - P/N 60294-7 Avco Lycoming Division Williamsport, Pa. 17701 Parts Catalog = AVCO LYCOMING - P/N PC-102 Avco Lycoming Division Williamsport, Pa.
  • Page 283 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL PIPER PUBLICATIONS. ELECTRONICS: AutoFlight II Service Manual = Piper P/N 761 481 Pitch Trim Service Manual = Piper P/N 753 771 AutoControl III B and Altimatic III B Service Manual = Piper P/N 753 502...
  • Page 284 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL AEROFICHE EXPLANATION AND REVISION STATUS The Maintenance Manual information incorporated in this set of Aerofiche cards has been arranged in accordance with the general specifications of Aerofiche adopted by the General Aircraft Manufacturer’s Association, (GAMA).
  • Page 285 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Revisions to Maintenance Manual 761 694 issued December 1, 1978 are as follows: Revisions Date Aerofiche Card Effectivity ORG 781201 December 1, 1978 1, 2, and 3 PR790223 February 23, 1979 1, 2, and 3...

  • Page 286: Hydraulic Power

    PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GAMA SYSTEM/CHAPTER INDEX GUIDE SYST SUB-SYST AEROFICHE CHAP SECTION TITLE GRID NO. AIRWORTHINESS LIMITATIONS 1A18 TIME LIMITS/MAINT CHECKS 1A22 DIMENSIONS AND AREAS 1B16 LIFTING AND SHORING LEVELING AND WEIGHING TOWING AND TAXIING 1C14...
  • Page 287 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GAMA SYSTEM/CHAPTER INDEX GUIDE (cont) SYST SUB-SYST AEROFICHE CHAP SECTION TITLE GRID INO. ELECTRICAL/ELECTRONIC PANELS AND MULTI-PURPOSE PARTS STRUCTURES DOORS STABILIZERS 2J10 WINDOWS 2J19 WINGS 2J24 PROPELLER 3A18 STANDARD PRACTICES - ENGINE POWER PLANT...

  • Page 288: Landing Gear

    PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL LIST OF ILLUSTRATIONS FIGURE NO. SUBJECT GRID NO. 6-1. Three View of PA-28RT-201T 1B22 6-2. Three View of PA-28RT-201 1B23 6-3. Station Reference Lines of PA-28RT-201/201T 6-4. Access Plates and Panels 7-1. Jacking Arrangements 8-1.
  • Page 289 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL LIST OF ILLUSTRATIONS (cont) FIGURE NO. SUBJECT GRID NO. 21-17. Condenser Air Scoop Installation 1G14 21-18. Expansion Valve 1G15 21-19. Components Installation 1G17 21-20. Adjustment of Air Conditioning Throttle Switch (PA-28RT-201) 1G17 21-21.
  • Page 290 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL LIST OF ILLUSTRATIONS (cont) FIGURE NO. SUBJECT GRID NO. 24-35. Installation of Drive End Head 24-36. Installation of Rectifier 24-37. Terminal Assembly (Prestolite) 24-38. Slip Ring End Bearing Assembly 24-39. Testing Alternator 24-40.

  • Page 291: Lights

    PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL LIST OF ILLUSTRATIONS (cont) FIGURE NO. SUBJECT GRID NO. 29-10. End Gland Locking Device 2C24 29-11. Main Gear Actuating Cylinder 32-1. Main Gear Oleo Strut Assembly 2D16 32-2. Main Gear Installation 2D17 32-3.
  • Page 292 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL LIST OF ILLUSTRATIONS (cont) FIGURE NO. SUBJECT GRID NO. 55-1. Stabilator Installation 2J13 55-2. Stabilator Balance Configuration 2J14 55-3. Vertical Fin Installation 2J15 55-4. Rudder Installation 2J17 55-5. Rudder Balancing 2J18 56-1. Windshield Installation (Typical) 2J22 56-2.
  • Page 293 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL LIST OF ILLUSTRATIONS (cont) FIGURE NO. SUBJECT GRID NO. 74-12. Assembly Tool 3D21 74-13. Assembly Tool Application 3D22 74-14. Measuring Lead Assembly Length 3D23 74-15. Ferrule Seating Tool 3D24 74-16. Measuring Wire From Top of Ferrule 3D24 74-17.
  • Page 294 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL LIST OF ILLUSTRATIONS (cont) FIGURE NO. SUBJECT GRID NO. ELECTRICAL SCHEMATICS —NOTE— Refer to Grid 313 for Electrical Schematic Index. 95-1. Tire Balancer Fixture 95-2. Control Surface Balancing Tool 95-3. Ignition Harness Ferrule Seating Tool 95-4.
  • Page 295 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL LIST OF CHARTS CHART NO. SUBJECT GRID NO. Leading Particulars and Principal Dimensions 1B18 2101 Troubleshooting (Air Conditioner) 2102 Troubleshooting (Air Conditioning System) 2103 Temperature Pressure Chart 1F12 2104 Aluminum Tubing Torque 1F15...
  • Page 296 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL LIST OF CHARTS (cont) CHART NO. SUBJECT GRID NO. 7101 Troubleshooting Chart (Engine) 3B14 7102 Engine Troubleshooting 7301 Metered Fuel Assembly Calibration 3C22 7302 Limits—Fuel Flow Vs. Brake H.P. 3C22 7401 Troubleshooting (Magneto)
  • Page 297 CHAPTER FUEL 2A18...
  • Page 298 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 28-FUEL TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 28-00-00 GENERAL 2A20 28-00-01 Description 2A20 28-00-02 Troubleshooting 2A22 28-10-00 STORAGE 28-10-01 Removal of Fuel Tanks 28-10-02 Inspection and Repair of Fuel Tank...
  • Page 299 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GENERAL. The fuel system components covered in this section consist of the fuel tanks, selector valves, filter screens, fuel pumps and quantity transmitter units. Instructions are given for remedying difficulties which may arise in the normal operation of the fuel system.
  • Page 300 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL A fuel tank selector allows the pilot to control the flow of fuel to the engine, and is located on the left side wall below the instrument panel. It has three positions: OFF, LEFT TANK and RIGHT TANK. The arrow on the handle of the selector points to the tank which is supplying fuel to the engine.

  • Page 301: Chapter 28-Fuel

    PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL TROUBLESHOOTING. Troubles peculiar to the fuel system are listed in Chart 2801 along with their probable causes and suggested remedies. When troubleshooting, check from the power supply to the items affected. If no trouble is found by this method, the trouble probably exists inside individual pieces of equipment;...
  • Page 302 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2801. TROUBLESHOOTING CHART (FUEL SYSTEM) (cont.) Trouble Cause Remedy No fuel pressure indica- Fuel selector valve stuck. Check fuel selector valve. tion. Fuel tanks empty. Check fuel tanks and fill. Defective gauge.
  • Page 303 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 28-1. Fuel System Diagram (PA-28RT-201) 28-00-01 Page 28-05 2A24 December 1, 1978...
  • Page 304 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 28-2. Fuel System Diagram (PA-28RT-201T) 28-00-01 Page 28-06 December 1, 1978...

  • Page 305: Removal Of Fuel Tanks 2B2

    2. If peeling has occurred and separated material is found, the fuel tank should be removed and resloshed in accordance with the instructions included with each can of Randolph Sloshing Sealer, 802, Piper Part Number 757 572V. (Approved under Mil. Spec. MIL-L-G0478.) One gallon of sloshing compound is required per tank.
  • Page 306 3. Fill the fuel tank and check for leaks, unrestricted fuel flow and proper sender indications on the quantity gauge. Refer to Fuel Quantity Sender/Gauge Check (Installed). —NOTE— Refer to latest revision of Piper Service Bulletin 625A; Fuel and Vapor Return Lines Support. DISASSEMBLY OF LOCKING FUEL CAP. (Refer to Figure 28-4.) 1.

  • Page 307: Fuel Filter Bowl And Screen 2B4

    PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 28-4. Locking Fuel Cap Assembly DISTRIBUTION. FUEL FILTER BOWL AND SCREEN. (Refer to Figure 28-5.) REMOVAL OF FUEL FILTER BOWL AND HOUSING. 1. Ascertain that the fuel shutoff is in the off position.

  • Page 308: Cleaning And Inspection Of Filter Bowl Screen 2B5

    PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 28-5. Fuel Filter Bowl and Screen CLEANING AND INSPECTION OF FILTER BOWL SCREEN. 1. Follow Steps 1, 2 and 4 of Removal of Fuel Filter Bowl and Housing for removal of the filter bowl.

  • Page 309: Fuel Selector Valve 2B6

    PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL FUEL SELECTOR VALVE. REMOVAL OF FUEL SELECTOR VALVE. 1. Remove three screws holding selector cover and the screw holding the handle. It will be necessary to remove side panel to gain access to the selector valve.
  • Page 310 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 28-6. Aux Fuel Pump Variable Resistor AUXILIARY FUEL PUMP SYSTEM ADJUSTMENT. (INSTALLED) 1. Install a calibrated pressure gauge in the fuel line between the electric fuel pump and engine. 2. Remove the aft access panel in the baggage compartment. The slider resistor is located at station 165.5 attached to the plate containing the voltage and over voltage relays.

  • Page 311: Removal Of Fuel Pump 2B8

    PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 14 Secure the “MEDIUM” power terminal and attach disconnected wires. 15 If the aircraft is equipped with a fuel diverter valve, operate the primer switch and insure the valve is being energized. Release the primer switch and operate the fuel pump switch in the HI-BOOST position and insure that the pump operates and that the diverter valve does not.

  • Page 312: Disassembly, Repair And Assembly Of Fuel Pump 2B9

    PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL DISASSEMBLY, REPAIR AND ASSEMBLY OF FUEL PUMP. Overhaul of the fuel pump is not recommended because of special tools needed. If overhaul is necessary, the pump should be returned to: The Weldon Tool Company...
  • Page 313 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL ADJUSTMENT OF ELECTRIC FUEL PUMP. (In Airplane) 1. With the access panel removed and the fuel selector in the OFF position, remove the fuel line from the outlet end of the pump. 2. Connect a test line with a bypass valve and pressure gauge to the outlet end of the pump.
  • Page 314 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL —NOTE— If during the torque check procedure the mechanic suspects a galled nut and union, back off the nut and inspect the threads. If the union is serviceable apply thread lube such as Slip Spray Lubricant (DuPont) or Ferrulube (Parker-Hannifin) and torque the nut to the proper value as listed in Step 4.

  • Page 315: Inspection And Tightening Of Fuel Line Fittings 2B10 A

    AC43: 13-1A, Paragraph 392. This will require cutting off the swaged ferrule and adding a short length of tubing. 3. A replacement tube and union purchased from Piper Service Sales will have the ferrule pre-swaged onto the tube. Install the prefabricated tube as follows: A.
  • Page 316 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL INDICATING. FUEL QUANTITY TRANSMITTER UNIT. REMOVAL OF FUEL QUANTITY TRANSMITTER UNIT. 1. Remove the fuel tank. (Refer to Removal of Fuel Tanks.) 2. Disconnect the transmitter wire from the connection post. 3. Cut the safety wire which secures the five attaching screws.
  • Page 317 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 28-8. Fuel Gauge CHART 2802. TRANSMITTER/FUEL GAUGE TOLERANCES Tolerance Actual Fuel in Gauge Reading (Plus or Minus) Tank (U.S. Gal.) (U.S. Gal.) (Needle-Widths) Full 32.5 22.5 12.5 Zero Plus 0-Minus 1 0 Empty...
  • Page 318 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL FUEL QUANTITY INDICATOR. The two quantity gauges are mounted in the cluster on the instrument panel. These instruments are calibrated in divisions of 10, 20, 30 gallons and full. Two transmitter units are installed in each fuel cell. These units contain a resistance strip and a movable control arm.
  • Page 319 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL FUEL PRESSURE GAUGE. The fuel pressure gauge instrument is mounted in the cluster on the instrument panel. This gauge is connected to the fuel system at the carburetor fuel inlet fitting. CHART 2804. FUEL PRESSURE GAUGE...
  • Page 320 CHAPTER HYDRAULIC POWER 2B17...
  • Page 321 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 29 - HYDRAULIC POWER TABLE OF CONTENTS CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 29-00-00 GENERAL 2B19 29-00-01 Description 2B19 1R 11-79 29-00-02 Troubleshooting 2B24 1R 11-79 29-10-00 MAIN 2C10 29-10-01 Hydraulic Pump...
  • Page 322 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GENERAL. The hydraulic system components covered in this section consist of the combination hydraulic pump and reservoir, gear back-up extender actuator assembly, actuating cylinders and hydraulic lines. The brake system, although hydraulically operated, is not included in this section as it has its own hydraulic system independent of the gear retraction system.
  • Page 323 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 29-1. Schematic Diagram of Hydraulic System 29-00-02 Page 29-02 2B20 Revised: November 6, 1979...
  • Page 324 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 29-2. Schematic Diagram of Hydraulic System 29-00-02 Page 29-03 2B21 Added: November 6, 1979...
  • Page 325 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 29-3. Hydraulic System Installation 29-00-02 Page 29-04 2B22 Revised: November 6, 1979...
  • Page 326 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 29-4. Hydraulic System Installation 29-00-02 Page 29-05 2B23 Added: November 6, 1979...
  • Page 327 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Also in the system is a bypass or free-fall valve that allows the gear to drop should a malfunction in the pump system occur. To prevent the gear from extending too fast, there is a special restrictor fitting on the side of the valve.
  • Page 328 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2901. HYDRAULIC SYSTEM TROUBLESHOOTING Trouble Cause Remedy Landing gear retraction Landing gear actuator Reset circuit breaker and system fails to operate. circuit breaker open. determine cause for open circuit breaker. Landing gear selector Reset circuit breaker and circuit breaker open.
  • Page 329 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2901. HYDRAULIC SYSTEM TROUBLESHOOTING (cont.) Trouble Cause Remedy Landing gear retraction Hydraulic pump ground Cheek ground. system fails to operate. incomplete. (cont.) Hydraulic pump inopera- Replace or overhaul pump. tive. Auxiliary extender switch Replace unit.
  • Page 330 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2901. HYDRAULIC SYSTEM TROUBLESHOOTING (cont.) Trouble Cause Remedy Landing gear extension Pump extension solenoid Replace solenoid. system fails to operate. inoperative (outboard (cont.) solenoid). —NOTE— If the extension solenoid of the pump can be heard to actuate...
  • Page 331 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2901. HYDRAULIC SYSTEM TROUBLESHOOTING (cont.) Trouble Cause Remedy Pump stops during gear Landing gear actuator Reset circuit breaker and retraction. circuit breaker opens. determine cause for over- load. Landing gear selector Reset circuit breaker and circuit breaker opens.
  • Page 332 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2901. HYDRAULIC SYSTEM TROUBLESHOOTING (cont.) Trouble Cause Remedy Pump fails to shut off Internal leakage of system. Check back-up extension though gear has fully unit valve for internal retracted. (cont.) leakage. Check gear actuating cylinders for internal leakage.
  • Page 333 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2901. HYDRAULIC SYSTEM TROUBLESHOOTING (cont.) Trouble Cause Remedy Pump fails to shut off Main gear down limit switch Adjust switch. (Refer to though the gear has fully out of adjustment. Adjustment of Main Gear extended.
  • Page 334 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2901. HYDRAULIC SYSTEM TROUBLESHOOTING (cont.) Trouble Cause Remedy Gear stops part way up, Pump high pressure relief Replace pump. but pump continues to run. valve out of adjustment. Internal leakage of system.
  • Page 335 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2901. HYDRAULIC SYSTEM TROUBLESHOOTING (cont.) Trouble Cause Remedy Landing gear fails to operate Friction or tight connection Clean, free and lubricate at required speeds. (Gear up at any of the attachment all pivot points.
  • Page 336 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2901. HYDRAULIC SYSTEM TROUBLESHOOTING (cont.) Trouble Cause Remedy With override lever up, Auto extension off switch Adjust switch by moving auto extension off light actuator out of adjustment. mounting bracket at attach- fails to operate.
  • Page 337 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 2902. LEADING PARTICULARS, HYDRAULIC SYSTEM Hydraulic Pump 67509 67509-02 High Pressure 1600 to 2000 psi 2000 to 2500 psi Low Pressure 650 ± 150 psi 650 ± 150 psi Flow Rate @ 1000 psi 45 cu.
  • Page 338 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 2. The pump motor may be removed from the pump and disassembled as-follows: A. Remove the thru bolts from the head of the motor. Using a knife, cut the seal coating between the motor head and case.
  • Page 339 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 29-5. Hydraulic Pump/Reservoir, Exploded View 29-10-05 Page 29-18 2C12 Revised: November 6, 1979...
  • Page 340 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 29-6. Test and Adjustment of Hydraulic Pump 29-10-05 Page 29-19 2C13 Revised: November 6, 1979...
  • Page 341 E. Connect the blue lead to the positive terminal of the power supply. Pump should operate and the high pressure gauge should indicate between 1600 to 2000 psi. (2000 to 2500 psi on Piper P/N 67509-2.) Should the pressure be incorrect, adjust valve “A,” Figure 29-5, in pump reservoir.
  • Page 342 Connect the blue lead to the positive terminal of the power supply. With the high pressure indication within the 1600 to 2000 psi range (2000 to 2500 psi on Piper P/N 67509-2) on the pressure gauge, the ammeter should read between 35 to 60 amperes. Disconnect the electrical lead.
  • Page 343 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL INSTALLATION OF HYDRAULIC PUMP. 1. Install the rubber shock mounts through the mounting holes of the pump. Insert a bushing through the holes of each shock mount. 2. Position the pump on its mounting flange. Install mounting bolt with washer and tighten. (Refer to Figure 29-5.)
  • Page 344 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 29-7. Checking Aligning Brackets of Gear Back-Up Extender Actuator 2. Move the actuator on its mounting brackets to allow the manual control push rod to have maximum clearance from the left stabilator cable and center in the fairlead on the aft face of the main spar box. Check system for sufficient travel and freedom of movement of controls.
  • Page 345 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 29-8. Gear Back-Up Extender Actuator 29-10-10 Page 29-24 2C18 Revised: November 6, 1979...
  • Page 346 B. If it is determined that the diaphragm is defective, then remove the back-up extender per instructions given in Removal of Gear Back-Up Extender Actuator Assembly and install Piper Kit No. 761 138V, Back-Up Gear Extender Diaphragm Replacement. Instructions for installing the diaphragm are included in the kit.
  • Page 347 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL G. With the airplane at a safe altitude, slow the airplane to a glide of 120 KIAS for PA-28RT-201T or 110 KIAS for PA - 2 8 RT-201 with the gear selector handle up and the throttle reduced to power O F F.
  • Page 348 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL OPERATIONAL CHECK OF RETRACTABLE LANDING GEAR SYSTEM. 1. Maximum Gear Extend: Place the gear selector in the down position at 130 KIAS for the 201 and 133 KIAS for the 201T. In approximately 5 to 10 seconds the three green gear lights should be on indicating that the gear is down and locked.
  • Page 349 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 29-9. Nose Gear Actuating Cylinder NOSE GEAR ACTUATING CYLINDER. REMOVAL OF NOSE GEAR ACTUATING CYLINDER. 1. Place the airplane on jacks. (Refer to Jacking, Chapter 7.) 2. Disconnect the hydraulic lines from the actuating cylinder and cover the open line ends to prevent contamination .
  • Page 350 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CLEANING, INSPECTION AND REPAIR OF NOSE GEAR ACTUATING CYLINDER. 1. Clean the cylinder parts with a suitable dry type solvent and dry thoroughly. 2. Inspect the cylinder assembly for the following: A. Interior walls of the cylinder and exterior surfaces of the piston for scratches, burrs, corrosion, etc.
  • Page 351 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 29-10. End Gland Locking Device DISASSEMBLY OF MAIN GEAR ACTUATING CYLINDER. (Refer to Figure 29-11.) 1. With the cylinder removed from the airplane, push the piston rod (by hand) toward the clevis to remove oil from the unit.
  • Page 352 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 29-11. Main Gear Actuating Cylinder 29-10-22 Page 29-31 Revised: August 8, 1984...
  • Page 353 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL ASSEMBLY OF MAIN GEAR ACTUATING CYLINDER. (Refer to Figure 29-11.) 1. Install O-ring on the exterior of the end gland. 2. Install O-ring or T-seal, and back-up ring in the interior of the end gland.
  • Page 354 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 1. Place airplane on jacks. (Refer to Jacking, Chapter 7.) 2. With gear down, master switch ON, and circuit breaker closed, place landing gear selector switch in the UP position. The pump should immediately start operating and the gear retract. The red gear unsafe light on the instrument panel should light up until the gear is fully retracted.
  • Page 355 CHAPTER LANDING GEAR...

  • Page 356: 28-Cont./Effec. Page-1

    PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 32-LANDING GEAR TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 32-00-00 GENERAL 32-00-01 Description and Operation 32-00-02 Troubleshooting 32-10-00 MAIN GEAR 2D15 32-10-01 Disassembly of Main Gear Oleo 2D15 32-10-02 Cleaning, Inspection and Repair of Main Gear Oleo...
  • Page 357 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 32-LANDING GEAR (cont.) TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SECTION EFFECTIVITY 32-40-00 WHEELS AND BRAKES (cont.) — 32-40-03 Assembly and Installation of Nose Wheel 2E24 32-40-04 Removal and Disassembly of Main Wheel...
  • Page 358 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 32-LANDING GEAR (cont.) TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 32-60-00 POSITION AND WARNING (cont.) — 32-60-10 Removal of Landing Gear Up/Power Reduced Warning Switch 2F18 32-60-11 Installation of Landing Gear Up/Power Reduced...
  • Page 359 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GENERAL. This chapter consists of instructions for the overhaul, inspection and adjustment of the various components of the landing gear and brake system. Also are adjustments for the electrical limit, safety and warning switches.
  • Page 360 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL lever to indicate whenever the latch is in use. The latch is disengaged by pulling up on the extension lever. To assist the nose gear to extend under these conditions are two springs, one inside the other, mounted on arms above the gear links.
  • Page 361 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 3201. TROUBLESHOOTING (LANDING GEAR) Trouble Cause Remedy Red gear unsafe light out Indicator lamp burned out. Replace lamp. while gear is in transit. Indicator light ground Check ground circuit. incomplete. Indicator light circuit wire Check wiring.
  • Page 362 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 3201. TROUBLESHOOTING (LANDING GEAR) (cont.) Trouble Cause Remedy Red gear unsafe light Light circuit wire loose. Check wiring. operates on and off after gear has retracted. Hydraulic system losing Refer to Hydraulic System, pressure.
  • Page 363 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 3201. TROUBLESHOOTING (LANDING GEAR) (cont.) Trouble Cause Remedy Red gear unsafe light and Diode in circuit between Replace diode. horn fail to operate when throttle switch and light/ throttle is near closed and horn open.
  • Page 364 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 3201. TROUBLESHOOTING (LANDING GEAR) (cont.) Trouble Cause Remedy Excessive or uneven wear Incorrect operating Inflate tire to correct on nose tire. pressure. pressure. Wear resulting from Refer to proceedings for shimmy. correction.
  • Page 365 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 3201. TROUBLESHOOTING (LANDING GEAR) (cont.) Trouble Cause Remedy Excessive or uneven wear Incorrect operating Inflate tire to correct on main tires. pressure. pressure. Wheel out of alignment (toe Check wheel alignment. in or out).
  • Page 366 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL MAIN GEAR. DISASSEMBLY OF MAIN GEAR OLEO. (Refer to Figure 32-1.) The main gear oleo assembly may be removed and disassembled from the gear oleo housing with the gear removed from or installed on the airplane.
  • Page 367 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 32-1. Main Gear Oleo Strut Assembly 32-10-02 Page 32-09 2D16 Revised: July 13, 1983...
  • Page 368 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 32-2. Main Gear Installation 32-10-02 Page 32-10 2D17 Revised: August 18, 1980...
  • Page 369 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 32-2. Main Gear Installation (cont.) 32-10-02 Page 32-11 2D18 Added: August 17, 1982...
  • Page 370 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 32-3. Main Gear Service Tolerances 32-10-02 Page 32-12 2D19 Revised: August 17, 1982...
  • Page 371 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 3202. MAIN GEAR SERVICE TOLERANCES 32-10-02 2D20 Page -32-13 Revised: August 17, 1982...
  • Page 372 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 3202. MAIN GEAR SERVICE TOLERANCES(cont) 32-10-02 Page 32-14 2D21 Revised: August 17, 1982...
  • Page 373 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL ASSEMBLY OF MAIN GEAR OLEO. (Refer to Figure 32-1.) 1. Ascertain that all parts are cleaned and inspected. 2. To install the piston tube plug, first lubricate the plug O-ring with hydraulic fluid (MIL-H-5606) and install it on the plug.
  • Page 374 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 3. The landing gear housing with components may be removed by the following procedure: A. Disconnect the brake line at its upper end in the wheel well. B. Disconnect the gear door actuating rod at the gear housing.
  • Page 375 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL INSTALLATION OF MAIN LANDING GEAR. (Refer to Figure 32-2.) —NOTE— When assembling components of the landing gear, lubricate bearings, bushings and friction surfaces with proper lubricant as described in Chapter 12. 1. Insert a gear support bearing in each support fitting and secure with snap rings. Check bearing for excess end play, shim as necessary with shim washers (P/N 62833-44).
  • Page 376 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL ADJUSTMENT OF MAIN LANDING GEAR. 1. Place the airplane on jacks. (Refer to Jacking, Chapter 7.) 2. Level the airplane laterally and longitudinally. (Refer to Leveling, Chapter 8.) 3. Disconnect the gear door actuating rods at either the door or the housing, as desired, by removing the rod attachment bolt.
  • Page 377 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL ALIGNMENT OF MAIN LANDING GEAR. Place a straightedge no less than twelve feet long across the front of both main landing gear wheels. Butt the straightedge against the tire at the hub level of the landing gear wheels. Jack the airplane up just high enough to obtain a six and one-half inch dimension between the centerline of the strut piston and the centerline of the center pivot bolt of the gear torque links.
  • Page 378 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 32-3a. Aligning Main Gear 32-10-09 Page 32-20 Revised: August 17, 1982...
  • Page 379 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 3203. TOE-IN—TOE-OUT CORRECTION CHART TOE-IN TOE-OUT SHIM WASHERS WASHERS AN 174 ANGLE WASHERS UNDER HEAD UNDER NUT BOLT 0° AN960-416 AN960-416 (3) 0° 33' AN960-416 AN960-416 AN960-416 (2) 0° 48' AN960-416L AN960-416...
  • Page 380 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL ADJUSTMENT OF MAIN GEAR DOOR ASSEMBLY. 1. Place the airplane on jacks. (Refer to Jacking, Chapter 7.) 2. Ascertain that the main gear is properly adjusted for gear up as given in Adjustment of Main Landing Gear.
  • Page 381 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CLEANING, INSPECTION AND REPAIR OF NOSE GEAR OLEO. 1. Clean all parts with a suitable dry type cleaning solvent. 2. Inspect the landing gear oleo assembly component for the following: A. Bearings and bushings for excess wear, corrosion, scratches and overall damage.
  • Page 382 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 32-4. Nose Gear Oleo Strut Assembly 32-20-03 Page 32-24 December 1, 1978...
  • Page 383 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 12. Install the shimmy dampener and safety. 13. Lubricate the gear assembly (refer to Lubrication Chart, Chapter 12). 14. Compress and extend the strut several times to ascertain that the strut will operate freely. Weight of the gear wheel and fork should allow the strut to extend.
  • Page 384 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 32-5. Nose Gear Installation 32-20-05 Page 32-26 Interim Revision: February 27, 1995...
  • Page 385 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 32-5a. Nose Gear Service Tolerances 32-20-05 2E10 Page 32-27 Revised: August 17, 1982...
  • Page 386 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 3204. NOSE GEAR SERVICE TOLERANCES Refer to Fig. 32-5a Manufactures Service Service Part No. Nomenclature Dimension Dimension Tol. Remark Fig. No. 67146-00 Draglink, upper ID.6235 ID.6230 .002 .6245 .6250 87319-03 Bearing, upper drag ** ID.4385...
  • Page 387 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 3204. NOSE GEAR SERVICE TOLERANCES (cont) Refer to Fig. 32-5a Manufactures Service Service Part No. Nomenclature Dimension Dimension Tol. Remarks Fig. No. 67054-03 Trunnion assembly ID.302 ID.302 .0015 assist spring fitting .303 .3035...
  • Page 388 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL C. Check the gear downlock hook spring for load tension below minimum allowable tolerance. The minimum tension of the spring is 10.5 pounds pull at 4.5 inches. Measurement is also taken from the inner side of each hook.
  • Page 389 Dye penetrant may be required. If any of these parts are cracked, remove and replace in accordance with the latest revisions of Piper Service Bulletin 724. 3. Loosen the jam nut on the hydraulic actuator rod end bearing and disconnect from downlock hook.
  • Page 390 Dye penetrant may be required. If any of these parts are cracked, remove and replace in accordance with the latest revision of Piper Service Bulletin No. 724. 3. Loosen the jam nut on the gear up stop, and turn stop in as far as possible.
  • Page 391 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 32-6. Nose Gear Adjustment (PA-28RT-201) 32-20-08 Page 32-33 2E16 Revised: July 13, 1983...
  • Page 392 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 32-7. Nose Gear Adjustment (PA-28RT-201T) 32-20-08 Page 32-34 2E17 December 1, 1978...
  • Page 393 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL ALIGNMENT OF NOSE LANDING GEAR. 1. Place the airplane on a smooth level floor that will accommodate the striking of a chalk line. 2. Ascertain that the nose gear is properly adjusted. 3. With the landing gear in the down-locked position, weight proportionally on the nose gear and the nose wheel facing forward, adjust the steering bellcrank.
  • Page 394 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 32-8. Clamping Rudder Pedals in Figure 32-9. Rudder Pedals at Neutral Neutral Position Angle 14. One end of each rod must be disconnected and the jam nuts loosened to make any adjustments. Do not attempt to make the adjustment by means of one rod end bearing, but divide the adjustment between the bearings at each end of each rod.
  • Page 395 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 32-10. Nose Gear Door Retraction Mechanism (PA-28RT-201) 32-20-10 Page 32-37 2E20 December 1, 1978...
  • Page 396 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 32-11. Nose Gear Door Retraction Mechanism (PA-28RT-201T) 32-20-10 Page 32-38 2E21 December 1, 1978...
  • Page 397 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 2. The nose gear door assembly on the PA-28RT-201T may be removed as follows: A. With nose gear extended, disconnect the door retraction rods from the doors by removing nut, bolt and washers.
  • Page 398 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL ADJUSTMENT OF NOSE GEAR DOORS. 1. Adjust PA-28RT-201 nose gear doors as follows: A. Place the airplane on jacks. (Refer to Jacking, Chapter 7.) B. Adjust the door retraction rods so that the gear will swing through the door opening with a .12 ±...
  • Page 399 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 32-12. Nose Wheel Assembly ASSEMBLY AND INSTALLATION OF NOSE WHEEL. (Refer to Figure 32-12.) 1. Ascertain that the bearing cup for each wheel half is properly installed. Install the tire with tube on the wheel half with the valve stem hole and then join the two wheel halves.
  • Page 400 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 32-13. Main Wheel Assembly REMOVAL AND DISASSEMBLY OF MAIN WHEEL. (Refer to Figure 32-13.) 1. Place the airplane on jacks. (Refer to Jacking, Chapter 7.) 2. To remove the main wheel, remove the four cap bolts that join the brake cylinder housing and the lining back plate assemblies.
  • Page 401 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 32-14. Wheel Brake Assembly (30-55) ASSEMBLY AND INSTALLATION OF MAIN WHEEL. (Refer to Figure 32-13.) 1. Ascertain that the bearing cup for each wheel is properly installed. Install the tire with tube on the outer wheel half and then join the two wheel halves.
  • Page 402 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL REMOVAL AND DISASSEMBLY OF WHEEL BRAKE ASSEMBLY. (Refer to Figure 32-14.) 1. To remove the brake assembly, first disconnect the brake line from the brake cylinder at the tube fitting. 2. Remove the cap bolts that join the brake cylinder housing and the lining back plate assembly. Remove the back plate from between the brake disc and whee1.
  • Page 403 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 32-15. Removal of Anchor Bolt 32-40-10 Page 32-45 December 1, 1978...
  • Page 404 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 32-16. Installation of Anchor Bolt 32-40-10 Page 32-46 December 1, 1978...
  • Page 405 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL BRAKE MASTER CYLINDER. (Hand Parking Brake) REMOVAL OF BRAKE MASTER CYLINDER. (Refer to Figure 32-17.) 1. To remove the brake master cylinder, first disconnect the inlet supply line from the fitting at the top of the cylinder and allow fluid to drain from the reservoir and line into a suitable container.
  • Page 406 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 32-17. Brake System Installation 32-40-15 Page 32-48 December 1, 1978...
  • Page 407 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 32-18. Brake Master Cylinder (Hand Parking Brake) 2. To assemble the piston rod assembly, install on the rod, in order, the roll pin, return spring retainer washer, return spring, packing gland with O-rings, seal, piston with O-ring, spring and retainer bushing. Secure these pieces with the small ring on the end of the rod.
  • Page 408 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 32-19. Toe Brake Installation 32-40-16 Page 32-50 December 1, 1978...
  • Page 409 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 32-20. Brake Cylinder (17000) (Toe Brake) BRAKE CYLINDER. (Toe Brake) REMOVAL OF BRAKE CYLINDER. (Refer to Figure 32-19.) 1. Disconnect the upper and lower lines from the cylinder to be removed and cap the lines to prevent fluid leakage or drain the fluid from the brake reservoir and master cylinder.
  • Page 410 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 32-21. Brake Cylinder (10-30) (Toe Brake) INTENTIONALLY LEFT BLANK 32-40-19 Page 32-52 2F11 Added: November 6, 1979...
  • Page 411 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 2. Cleveland cylinder number 10-30 (Refer to Figure 32-21). a. Remove the cylinder from its mounting bracket as per Removal of Brake Cylinder. b. To disassemble the cylinder, first remove the piston rod assembly by removing the retaining ring from the annular slot in the cylinder housing.
  • Page 412 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 3. Bleed the brakes per Bleeding Brakes. BLEEDING BRAKES. BRAKE BLEEDING PROCEDURE. (Gravity) 1. On both main landing gear wheel brake assemblies, attach a clear plastic hose to the brake bleeders and extend into container partially filled with hydraulic fluid, MIL-H-5606. The ends of this hose should be submerged in the fluid.
  • Page 413 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 4. Close the open bleeder fitting on the gear being bled. Close the open bleeder fitting to which the pressure hose is attached; then close the pressure unit and remove the hoses from the bleeder fittings. Check the brakes for proper pedal pressure.
  • Page 414 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 32-22. Adjustment of Nose Figure 32-23. Adjustment of Main Gear Gear Down Limit Switch Down Limit Switch —NOTE— Do not bend the actuator springs mounted on the limit switches. ADJUSTMENT OF NOSE GEAR UP LIMIT SWITCH.
  • Page 415 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 7. Retract the gear electrically and ascertain that the red gear unsafe light will go out when the gear has retracted and the pump has shut off. ADJUSTMENT OF NOSE GEAR DOWN LIMIT SWITCH.
  • Page 416 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 32-24. Throttle Warning Switches 7. Retract and extend the gear by turning the master switch on, raising the emergency gear extension lever and moving the gear selector handle to the up position. As the gear begins to retract, the green light below the selector should go out and the red gear unsafe light at the top of the instrument panel should come ADJUSTMENT OF LANDING GEAR SAFETY SWITCH.
  • Page 417 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL LANDING GEAR WARNING SWITCHES. (Throttle Switches) LANDING GEAR UP/POWER REDUCED WARNING SWITCH. The gear up/power reduced warning switch is within the control quadrant below the throttle control lever. (Refer to Figure 32-24.) This switch will actuate the warning horn and red light simultaneously when the landing gear is not down and locked, and the throttle is reduced to the below 14 inches of manifold pressure.
  • Page 418 CHAPTER LIGHTS 2F19...
  • Page 419 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 33- LIGHTS TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 33-00-00 GENERAL 2F21 2-79 33-00-01 Description and Operation 2F21 2-79 33-00-02 Troubleshooting D 7-81 33-10-00 FLIGHT COMPARTMENT 2F22 33-10-01 Instrument Panel Lights...
  • Page 420 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GENERAL. The lighting system available for the Arrow IV is optional but enables the aircraft to fly at night and in instrument weather conditions. DESCRIPTION AND OPERATION. External lighting attainable on the Arrow IV involves navigation lights, strobe lights, position lights, and a landing/taxi light.
  • Page 421 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL FLIGHT COMPARTMENT. INSTRUMENT PANEL LIGHTS. The instrument panel lights are controlled by a 5 amp circuit breaker through a switch and transistorized dimmer control unit located to the right of center of the instrument panel. There are two control knobs, one for the panel lights and the other for the radio lights.
  • Page 422 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL The test button is used to check the operation of the lights when the engine is running. The lights will work when the engine is not running with the master switch turned on.
  • Page 423 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 3301. TROUBLESHOOTING (ELECTRICAL SYSTEM) (cont.) Trouble Cause Remedy ANNUNCIATOR PANEL (cont.) VAC warning light fails to Sensor activates at a too Replace. extinguish. high setting. Sensor terminals bridged. Remove material between terminals.
  • Page 424 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 33-1. Annunciator Panel 33-10-06 Page 33-05 Added: July 24, 1981...
  • Page 425 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL REPLACEMENT OF ANNUNCIATOR PANEL LIGHT BULBS. Replacement of a bulb does not require removal of the annunciator panel. The lenses are designed to be a friction fit with the bulbs inserted into the back side of the lens. To replace a defective bulb, simply pull the corresponding lens out of the annunciator panel.
  • Page 426 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL ANTI-COLLISION LIGHT. (Strobe) DESCRIPTION. The lights are located on each wing tip in the same assembly with the navigation lights. They are rated to flash at approximately 50 times a minute. REMOVAL OF WING TIP STROBE LIGHT.
  • Page 427 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 33-2. Strobe Light Connections 33-40-06 Page 33-08 December 1, 1978...
  • Page 428 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL REMOVAL OF STROBE POWER SUPPLY. The strobe power supply is in the aft section of the fuselage. 1. Remove access panel to the aft section of the fuselage in the rear baggage compartment to gain access to power supply.
  • Page 429 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 2. Check for malfunction in interconnecting cables. A. Ascertain Pins 1 and 3 of interconnecting cable are not reversed. B. Using an ohmmeter, check continuity between Pin 1 and 3 of interconnecting cable. If a reading is obtained on the meter, the cable is shorted and should be replaced.
  • Page 430 CHAPTER NAVIGATION AND PITOT/ STATIC...

  • Page 431: Navigation & Pitot/Static

    PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 34 - NAVIGATION AND PITOT/STATIC TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 34-00-00 GENERAL 34-00-01 Description and Operation 34-00-02 Removal and Replacement of Face Mounted Instruments 34-00-03 Removal and Replacement of Cluster Mounted...
  • Page 432 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GENERAL. The instrument air system consists of pitot air and static air sources. The system supplies both pitot and static air pressure for the airspeed indicator, altimeter and vertical speed indicator. These instruments are face mounted.
  • Page 433 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 34-1. Pitot-Static System Installation 34-00-02 Page 34-02 2G10 Revised: February 23, 1979...
  • Page 434 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL REMOVAL AND REPLACEMENT OF CLUSTER MOUNTED INSTRUMENTS. A cluster, located on the instrument panel, contains six individual instruments. Removal of these instruments can be accomplished by the following procedure: 1. Remove the face panel by removing the screws from around the perimeter of the panel.
  • Page 435 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL FLIGHT. RATE OF CLIMB INDICATOR. The rate of climb indicator measures the rate of change in static pressure when the airplane is climbing or descending. By means of a pointer and dial this instrument will indicate the rate of ascent or descent of the airplane in feet per minute.
  • Page 436 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 3401. TROUBLESHOOTING (RATE OF CLIMB INDICATOR) (cont) Trouble Cause Remedy Pointer oscillates. Leaks in static lines. Disconnect all instruments connected to the static line. Check individual instru- ments for leaks. Reconnect instruments to static line and test installation for leaks.
  • Page 437 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 3402. TROUBLESHOOTING (ALTIMETER) Trouble Cause Remedy Excessive scale error. Improper calibration ad- Replace instrument. justment. Excessive pointer oscil- Defective mechanism. Replace instrument. lation. High or low reading. Improper venting. Eliminate leak in static pressure system and check alignment of airspeed tube.
  • Page 438 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 3402. TROUBLESHOOTING (ALTIMETER) (cont) Trouble Cause Remedy Altimeter changes reading Water in static line. Remove static lines from all as aircraft is banked. instruments, and blow line clear from cockpit to pitot head.
  • Page 439 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 3403. TROUBLESHOOTING (AIRSPEED TUBES AND INDICATOR) (cont) Trouble Cause Remedy Instrument reads low. Pointer not on zero. Replace instrument. Leaking static system. Find leak and correct. Pitot head not aligned Realign pitot head.
  • Page 440 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 3404. TROUBLESHOOTING (GYRO HORIZON INDICATOR) (cont) Trouble Cause Remedy Bar oscillates or shimmies Instrument loose in panel. Tighten mounting screws. continuously. Vacuum too high. Adjust valve. Defective mechanism. Replace instrument. Instrument does not indi-...
  • Page 441 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 3405. TROUBLESHOOTING (DIRECTIONAL GYRO INDICATOR) Trouble Cause Remedy Excess drift in either Setting error. Review paragraph titled direction. “General” for gyro op- eration. Defective instrument. Replace instrument. High or low vacuum. If...
  • Page 442 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 3. Head aircraft on a magnetic East heading and do the same as Step 2, adjusting E-W adjusting screw. 4. Head aircraft on a magnetic South heading and note resulting South error. Adjust N-S adjusting screw until one-half of this error has been removed.
  • Page 443 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL TURN AND BANK INDICATOR. The turn and bank indicator can be either vacuum driven or electric. The turn portion of the indicator is a gyroscope, while the bank portion of the indicator is a ball sealed in a curved glass tube filled with damping fluid.

  • Page 444: Oxygen System

    CHAPTER OXYGEN SYSTEM 2G21...
  • Page 445 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 35 - OXYGEN SYSTEM TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 35-00-00 GENERAL 2G23 35-00-01 Description and Operation 2G23 35-00-02 Troubleshooting 35-10-00 CREW/PASSENGER SYSTEM 35-10-01 FIXED OXYGEN SYSTEM 35-10-02 Inspection and Maintenance...
  • Page 446 A fixed and/or portable oxygen system is available on this aircraft. Scott Aviation manufactures the major components for these systems and should be contacted along with Piper Customer Services for any further information not covered herein. For specific parts information refer to the Piper Parts Catalog.
  • Page 447 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 35-1. Fixed - Oxygen System 35-00-01 Page 35-02 2G24 Added: November 6, 1979...
  • Page 448 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 35-2. Portable - Oxygen System TROUBLESHOOTING. (Refer to Chart 3501.) CHART 3501. TROUBLESHOOTING (OXYGEN SYSTEM) Trouble Cause Remedy No indication of pressure on Cylinder empty and/or leak in Purge, charge, and check pressure gauge.
  • Page 449 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 3501. TROUBLESHOOTING (OXYGEN SYSTEM) (cont) Trouble Cause Remedy Effective pressure indicated but Oxygen cylinder regulator Vacate bottle and replace no oxygen flow with clear lines. assembly defective. regulator assembly. Return to manufacturer or have repaired by an approved shop.
  • Page 450 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL FIXED-OXYGEN SYSTEM. INSPECTION AND MAINTENANCE. Due to the nature of the process used to test compressed gas tanks, servicing and hydrostatic tests must be conducted by a DOT or manufacturer (Scott Aviation) approved shop. The following material gives recommended inspection and maintenance information for the various parts of the oxygen systems.
  • Page 451 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 35-3. Test Apparatus For Testing Oxygen System 35-10-02 Page 35-06 Added: November 6, 1979...
  • Page 452 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 35-4. Oxygen Tubing Installations 35-10-02 Page 35-07 Added: November 6, 1979...
  • Page 453 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 9. Make sure to check the oxygen lines for proper clearance as follows: (Refer to Figure 35-4.) A. Two inch minimum between oxygen tubes and all flexible moving parts of the aircraft (flexible control cables, etc.).
  • Page 454 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL E. Dry with air as described in previous caution or by heating at a temperature of 250° to 300° F for one half hour. —NOTE— Solvents can be reused provided they do not become badly contaminated with oil.
  • Page 455 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 35-5. Installation of Swageloc Fittings 35-10-04 Page 35-10 Added: November 6, 1979...
  • Page 456 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 2. Preswaged swageloc fittings are fabricated and installed as follows: A. Assemble the nut and ferrules finger tight on the pre-swaging tool and insert the tube until it firmly bottoms on the shoulder in the tool. The pre-swaging tool can be attained from Crawford Fitting Company, refer to List of Consumable Materials in Chapter 91.
  • Page 457 Ports on regulators, indicators, and other opened components must also be kept capped or plugged to prevent ingestion of foreign material. Adjustments or modifications should only be initiated under the auspicious of the FAA, Piper, or Scott Aviation. REMOVAL OF OXYGEN CYLINDER. (Refer to Figure 35-1.) —NOTE—...
  • Page 458 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 2. It is recommended that when working in the rear of the aircraft an appropriate tailstand be properly attached to the tail. 3. With the immediate area clear of flammables (grease, hydraulic fluid, fuel) and oxygen system off , connect a mask or tube to an outlet to exhaust any pressure in the system.
  • Page 459 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL INSTALLATION OF OXYGEN CYLINDER. 1. Before mounting the cylinder to the shelf, connect the control cable to the control valve-regulator. If the shelf has been removed reinstall it before continuing. Install teflon tape per prior instructions in this chapter.
  • Page 460 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL INSTALLATION OF OUTLETS. 1. Apply teflon tape to male threads of the affected fitting. Refer to appropriate procedure in this chapter. 2. Connect the outlet to the low pressure line. 3. Position the trim panel and secure with screws.
  • Page 461 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 3503. FILLING PRESSURE FOR CERTAIN AMBIENT TEMPERATURES Ambient Temperature Filling Pressure Ambient Temperature Filling Pressure 1650 (PSI) 1975 (PSI) 1700 2000 1725 2050 1775 2100 1825 2150 1875 2200 1925 2250 NOTE: Filling pressures are for 1850 PSI at 70°F. Table assumes 25°F rise due to heat of compression with max fill rate.
  • Page 462 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL (4) A good deal of oxygen will remain in the large cylinders used in the cascade system after filling only one of the cylinders but such remaining oxygen will be a pressure something less than the 1850 psi which is not sufficient pressure to completely refill another aircraft cylinder although it will refill several smaller cylinders.
  • Page 463 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL MAINTENANCE. 1. Check the cylinder to be sure it is securely mounted. 2. Check the cylinder for the ICC identification number and for the date of the last FAA inspection and test. 3. If cylinder is completely empty it must be completely disassembled and inspected in an FAA or manufacturer approved facility before recharging.

  • Page 464: Vacuum System

    CHAPTER VACUUM SYSTEM 2H17...
  • Page 465 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 37 - VACUUM SYSTEM TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 37-00-00 GENERAL 2H19 37-00-01 Description and Operation 2H19 37-00-02 Troubleshooting 2H19 37-10-00 DISTRIBUTION 2H21 37-10-01 Vacuum System Service Tips...
  • Page 466 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GENERAL. The instrumentation in this airplane is designed to give a quick and actual indication of the attitude, performance and condition of the airplane. Maintenance, other than described, shall be done by the instrument manufacturer or an authorized repair station.
  • Page 467 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 3701. TROUBLESHOOTING (VACUUM SYSTEM) (cont.) Trouble Cause Remedy Normal pressure indica- Faulty instrument. Replace instrument. tion but sluggish operation of instruments. High system pressure. Vacuum regulator in- Adjust regulator. correctly adjusted. Vacuum regulator sticking Clean and check operation or dirty screen.
  • Page 468 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL DISTRIBUTION . VACUUM SYSTEM SERVICE TIPS. The following information is intended to acquaint field service personnel with a means to diagnose vacuum system service symptoms on those components which are serviced by removal and replacement.
  • Page 469 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 3. Gyro Filters: A. Gyro filters must be serviced on a scheduled basis, not to exceed 100 hours, or sooner as condition indicates. B. The system installation employs a large central filter and differential vacuum gauge that continuously monitors the filter condition while indicating vacuum readings.
  • Page 470 The only pump mounting gasket authorized and approved for use on the Airborne vacuum pump is the Airborne gasket B3-1-2, Piper part number 751 859. Use of any other gasket may result in oil seepage or leakage at the mounting surface.
  • Page 471 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 2. Secure the pump to the engine with four plain washers, lock washers and retaining nuts. Torque the nuts 40 to 50 inch-pounds. 3. Connect the hoses to the pump and secure with hose clamps.
  • Page 472 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 2. Start the engine and operate at a medium RPM with the suction gauge indicating 5.0 with central air filter. If adjustment is necessary, refer to Adjustment of Vacuum Regulator Valve. 3. With the suction gauge reading within the stated range, the gauge attached to the turn and bank should indicate 2.0 inches of mercury.
  • Page 473 CHAPTER ELECTRICAL/ELECTRONIC PANELS AND MULTI-PURPOSE PARTS...
  • Page 474 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 39 - ELECTRICAL/ELECTRONIC PANELS AND MULTI-PURPOSE PARTS TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 39-40-00 MULTIPURPOSE ELECTRICAL PARTS 39-40-01 Stall Warning Horn, Indicator and Detector D 7-83 Removal of Lift Detector...
  • Page 475 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL ELECTRICAL SWITCHES AND CIRCUIT BREAKERS. The switches are of the rocker type. The switches are mounted in the middle of the instrument panel. The circuit breakers are single hole mounting, pushbutton type with manual reset; they must reset be the pilot whenever tripped.
  • Page 476 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 477 CHAPTER STRUCTURES...
  • Page 478 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 51 - STRUCTURES TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 51-00-00 GENERAL 51-00-01 Description 51-10-00 STRUCTURAL REPAIRS 51-10-00 Baggage Compartment Inspection Hole and Cover Plate 2I11 A 2-95 51-10-01 Fiberglas Repairs...
  • Page 479 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GENERAL. DESCRIPTION The PA - 2 8 RT-201/201T is an all metal semi-monocoque structure. The fuselage is constructed of bulkheads, stringers and stiffeners, to which all of the outer skin is riveted. The cabin entrance door is located on the right side of the fuselage above the wing.
  • Page 480 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 51-1. Skin Materials and Thickness 51-10-01 Page 51-02 Reissued: August 1, 1987...
  • Page 481 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 51-1. Skin Materials and Thickness (cont) 51-10-01 2I10 Page 51-03 Reissued: August 1, 1987...
  • Page 482 PA-28RT-201 / 201T MAINTENANCE MANUAL BAGGAGE COMPARTMENT INSPECTION HOLE AND COVER PLATE. (See latest revision of Piper Service Bulletin 977.) a. General. Airplanes manufactured before 1979 may not have had control cable inspection access holes in the baggage compartment floor. The following is a method of fabricating inspection access holes in the floor of the baggage compartment, if desired.
  • Page 483 TYP;M 0.120” HOLE THRU N0.8 X 38 CRES TRUSS RECESSED HEAD SHEET METAL SCREWS (16 REQD.) 2.50” COVER (2 REQD) 30° TYP PIPER P/N 62109-0 10.98” 8.48” 19.11” Figure 51-1a. Baggage Compartment Inspection Holes Cutout Details 51-10-01 2I12 Page 51-03b...
  • Page 484 Fiberglas Fracture and Patch Repairs as puncture, breaks and holes that have penetrated through the structure and damaged the fiberglas cloth. A repair kit, part number 756 729 will furnish necessary material for such repairs, and is available through Piper Aircraft Dealers.
  • Page 485 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 5. Cover a piece of cardboard or metal with cellophane. Tape it to the outside of the structure covering the hole completely. The cellophane should face toward the inside of the structure. If the repair is on a sharp contour or shaped area, a sheet of aluminum formed to a similar contour may be placed over the area.
  • Page 486 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 5101. LIST OF MATERIALS (THERMOPLASTIC REPAIR) ITEMS DESCRIPTIONS SUPPLIERS Buffing and Rubbing Automotive Type - DuPont DuPont Company Compounds Wilmington, Del. 19898 Ram Chemical #69 x 1 Ram Chemicals Gardena, Cal. 90248 Mirror Glaze #1 Mirror Bright Polish Co., Inc.
  • Page 487 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 51-2. Surface Scratches, Abrasions or Ground-in-Dirt 1. Surface Preparation: A. Surface dirt and paint if applied must be removed from the item being repaired. Household cleaners have proven most effective in removing surface dirt.
  • Page 488 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 51-3. Deep Scratches, Shallow Nicks and Small Holes Figure 51-4. Mixing of Epoxy Patching Compound 51-10-04 Page 51-08 2I17 December 1, 1978...
  • Page 489 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL D. For larger damages an epoxy patching compound is recommended. This type material is a two part, fast curing, easy sanding commercially available compound. E. Adhesion can be increased by roughing the bonding surface with sandpaper and by utilizing as much surface area for the bond as possible.
  • Page 490 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 51-5. Welding Repair Method Figure 51-6. Repairing of Cracks 51-10-04 Page 51-10 2I19 Revised: August 17, 1982...
  • Page 491 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 51-7. Various Repairs 51-10-04 Page 51-11 2I20 Revised: August 17, 1982...
  • Page 492 PRODUCT LISTING FOR LIQUID SAFETY WALK COMPOUND. 1. Suggested Solvents: Safety Solvent per MIL-S-18718 Sherwin Williams Lacquer Thinner R7KC120 Glidden Thinner No. 207 2. Safety Walk Material: Walkway Compound and Matting Nonslip (included in Piper Part No. 179872) 51-10-07 Page 51-12 2I21 December 1, 1978...
  • Page 493 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 51-8. Repair of Stress Lines Figure 51-9. Repair of Impacted Damage 51-10-07 Page 51-13 2I22 Revised: August 17, 1982...
  • Page 494 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL APPLICATION OF LIQUID SAFETY WALK COMPOUND. Liquid safety walk compound shall be applied in an area, free of moisture for a period of 24 hours minimum after application. Do not apply when surface to be coated is below 50°F. Apply liquid safety walk compound as follows: 1.
  • Page 495 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK 2I24...
  • Page 496 CHAPTER DOORS...
  • Page 497 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 52 - DOORS TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 52-00-00 GENERAL 52-10-00 PASSENGER/CREW 52-10-01 Removal of Door 52-10-02 Installation of Door 52-10-03 Adjustment of Door 52-10-04 Removal of Door Latch Mechanism...
  • Page 498 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GENERAL. This airplane has one entrance door located on the right side of the fuselage and a baggage door also on the right side aft of the entrance door and wing trailing edge.
  • Page 499 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL INSTALLATION OF DOOR LATCH MECHANISM. 1. Place the latch assembly into position on the door. 2. Connect the latch pull rod to the inside door handle. 3. Replace the screws that attach the latch plate and mechanism to the door. Install the door trim upholstery and secure with screws.
  • Page 500 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL REMOVAL AND INSTALLATION OF DOOR SEAL SNUBBER. (Refer to Figure 52-1.) If installed, the neoprene rubber door snubber is incorporated in the cabin door jamb to improve door sealing. Installation on aircraft not equipped with the snubber may be accomplished per “Field Service Kit For Improved Door Sealing”...
  • Page 501 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL To effect a clean installation, it is recommended that the jamb be masked off as shown in Figure 52-l. —CAUTIONS— Do not pre-stretch the snubber, as this can induce cracks in the snubber.
  • Page 502 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 52-1. Installation of Door Snubber 52-10-12 Page 52-05 Revised: July 24, 1981...
  • Page 503 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CARGO. REMOVAL OF BAGGAGE DOOR. With the door open remove the hinge pin from the hinge and remove the door. INSTALLATION OF BAGGAGE DOOR. Place the door in position so that the hinge halves are properly matched and install the hinge pin. It will not be necessary to replace the hinge pin with a new pin if it is free of bends and wear.
  • Page 504 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 505 CHAPTER STABILIZERS 2J10...
  • Page 506 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 55 - STABILIZERS TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 55-00-00 GENERAL 2J12 55-20-00 STABILATOR 2J12 55-20-01 Removal and Installation of Stabilator 2J12 55-20-02 Removal and Installation of Stabilator Trim Tab...
  • Page 507 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GENERAL. STABILATOR. REMOVAL AND INSTALLATION OF STABILATOR. (Refer to Figure 55-1.) The stabilator assembly can be removed by following the procedure given below. 1. Remove the fin tip attachment screws and disconnect the light at quick disconnect, then remove tip assembly.
  • Page 508 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 55-1. Stabilator Installation 55-20-04 Page 55-02 2J13 Revised: February 23, 1979...
  • Page 509 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 55-2. Stabilator Balance Configuration 1. If the stabilator is out of limits on the leading edge heavy side, remove balance plates from the mass balance weight until the static balance is within limits. Do not attempt to adjust the stabilator tip balance weight.
  • Page 510 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 55-3. Vertical Fin Installation 55-30-01 Page 55-04 2J15 Revised: February 23, 1979...
  • Page 511 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 6. Remove stabilator control push rod from the fin by disconnecting attachment hardware at the balance weight arm and at bellcrank. 7. Remove the two bolts at the leading edge of the fin.
  • Page 512 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 55-4. Rudder Installation 55-40-03 Page 55-06 2J17 Revised: July 13, 1983...
  • Page 513 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 55-5. Rudder Balancing —END— 55-40-03 Page 55-07 2J18 Revised: August 17, 1982...
  • Page 514 CHAPTER WINDOWS 2J19...
  • Page 515 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 56- WINDOWS TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 56-10-00 FLIGHT COMPARTMENT 2J21 56-10-01 Removal of Windshield 2J21 56-10-02 Installation of Windshield 2J21 7-81 56-20-00 CABIN 2J21 56-20-01 Removal of Side Windows...
  • Page 516 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL FLIGHT COMPARTMENT. REMOVAL OF WINDSHIELD. 1. Remove the collar molding from around the bottom of the windshield and the trim strip from between the windshield halves by removing the attaching screws. 2. Remove the windshield by raising the lower portion of the windshield and carefully pulling it out and downward to release the top and side edges.
  • Page 517 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 56-1. Windshield Installation (Typical) 56-20-01 Page 56-02 2J22 Revised: July 24, 1981...
  • Page 518 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 56-2. Side Window Installation, Single Pane (Typical) 2. Carefully remove the window from the frame. —NOTE— A damaged window should be saved to provide a pattern for shaping the new window. 3. Remove excess tape and sealer from the window frame and molding.
  • Page 519 CHAPTER WINGS 2J24...
  • Page 520 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 57 - WINGS TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 57-00-00 GENERAL 57-00-01 Description 57-20-00 AUXILIARY STRUCTURE 57-20-01 Removal of Wing Tip 57-20-02 Installation of Wing Tip 57-20-03 Repair of Wing Tip...

  • Page 521: General

    PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GENERAL. This chapter explains the removal and installation procedures for the wings and related components installed on this aircraft. DESCRIPTION. Each wing panel is an all metal, full cantilever, semi-monocoque type structure with removable tips and access panels.
  • Page 522 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 57-1. Wing Installation 57-20-03 Page 57-02 Revised: February 23, 1979...
  • Page 523 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 57-1. Wing Installation (cont.) 57-20-03 Page 57-03 Revised: August 18, 1980...
  • Page 524 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 57-1. Wing Installation (cont.) 57-20-03 Page 57-04 Revised: August 18, 1980...

  • Page 525: Attach Fittings

    PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL ATTACH FITTINGS. REMOVAL OF WING. (Refer to Figure 57-1.) 1. Close the fuel valve and drain the fuel from the wing to be removed . (Refer to Draining Fuel System, Chapter 12.) 2. Drain the brake lines and reservoir. (Refer to Draining Brake System, Chapter 12.) 3.

  • Page 526: Installation Of Wing

    PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL INSTALLATION OF WING. (Refer to Figure 57-1.) —NOTES— New Service wings are not drilled for the aft attachment point. This win necessitate drilling a .375/.376 hole to allow for the new hardware to be installed.
  • Page 527 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 57-2. Aileron and Flap Installation 57-40-02 Page 57-07 Revised: February 23, 1979...
  • Page 528 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 57-2. Aileron and Flap Installation (cont.) 57-40-02 Page 57-08 December 1, 1978...

  • Page 529: Flight Surfaces

    PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 13. Connect the leads to the appropriate posts on the terminal strip and install the washers and nuts. (For assistance in connecting the electrical lead, refer to the Electrical Schematics in Chapter 91.) Place the clamps along the electrical harness to secure it in position and install the terminal strip dust cover.

  • Page 530: Balancing Aileron

    PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 57-3. Aileron Balance Configuration CHECKING AILERON FREE PLAY. The following checks are recommended before balancing to ascertain the amount of “free play” in the aileron: Set the aileron in its neutral position and secure. Obtain a straightedge long enough to extend from the ground up to a few inches above the aileron trailing edge.
  • Page 531 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL REMOVAL OF WING FLAP. (Refer to Figure 57-2.) 1. Extend the flaps to their fullest degree and remove the bolt and bushing from the rod end bearing by use of an angle or offset screwdriver.
  • Page 532 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 2K13 THRU 2L24 INTENTIONALLY LEFT BLANK 2K13...
  • Page 533 Courtesy of Bomar Flying Service www.bomar.biz ARROW IV MAINTENANCE MANUAL CARD 3 OF 3 PA-28RT-201 ARROW IV PA-28RT-201T TURBO ARROW IV PIPER AIRCRAFT CORPORATION (PART NUMBER 761 694)
  • Page 534 PA-28RT-201 / 201T MAINTENANCE MANUAL INTRODUCTION. This PIPER AIRCRAFT Maintenance Manual is prepared in accordance with the GAMA (General Aviation Manufacturers Association) format. This maintenance manual is divided into various Groups which enable a broad separation of contents (Chapters) within each group.
  • Page 535 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL VENDOR PUBLICATIONS. ENGINE (LYCOMING): Overhaul Manual = AVCO LYCOMING - OVERHAUL MANUAL DIRECT DRIVE ENGINE - P/N 60294-7 Avco Lycoming Division Williamsport, Pa. 17701 Parts Catalog = AVCO LYCOMING - P/N PC-102 Avco Lycoming Division Williamsport, Pa.
  • Page 536 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL PIPER PUBLICATIONS. ELECTRONICS: AutoFlight II Service Manual = Piper P/N 761 481 Pitch Trim Service Manual = Piper P/N 753 771 AutoControl III B and Altimatic III B Service Manual = Piper P/N 753 502...
  • Page 537 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL AEROFICHE EXPLANATION AND REVISION STATUS The Maintenance Manual information incorporated in this set of Aerofiche cards has been arranged in accordance with the general specifications of Aerofiche adopted by the General Aircraft Manufacturer’s Association, (GAMA).
  • Page 538 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Revisions to Maintenance Manual 761 694 issued December 1, 1978 are as follows: Revisions Date Aerofiche Card Effectivity ORG 781201 December 1, 1978 1, 2, and 3 PR790223 February 23, 1979 1, 2, and 3...
  • Page 539 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GAMA SYSTEM/CHAPTER INDEX GUIDE SYST SUB-SYST AEROFICHE CHAP SECTION TITLE GRID NO. AIRWORTHINESS LIMITATIONS 1A18 TIME LIMITS/MAINT CHECKS 1A22 DIMENSIONS AND AREAS 1B16 LIFTING AND SHORING LEVELING AND WEIGHING TOWING AND TAXIING 1C14...
  • Page 540 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GAMA SYSTEM/CHAPTER INDEX GUIDE (cont) SYST SUB-SYST AEROFICHE CHAP SECTION TITLE GRID INO. ELECTRICAL/ELECTRONIC PANELS AND MULTI-PURPOSE PARTS STRUCTURES DOORS STABILIZERS 2J10 WINDOWS 2J19 WINGS 2J24 PROPELLER 3A18 STANDARD PRACTICES - ENGINE POWER PLANT...
  • Page 541 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL LIST OF ILLUSTRATIONS FIGURE NO. SUBJECT GRID NO. 6-1. Three View of PA-28RT-201T 1B22 6-2. Three View of PA-28RT-201 1B23 6-3. Station Reference Lines of PA-28RT-201/201T 6-4. Access Plates and Panels 7-1. Jacking Arrangements 8-1.
  • Page 542 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL LIST OF ILLUSTRATIONS (cont) FIGURE NO. SUBJECT GRID NO. 21-17. Condenser Air Scoop Installation 1G14 21-18. Expansion Valve 1G15 21-19. Components Installation 1G17 21-20. Adjustment of Air Conditioning Throttle Switch (PA-28RT-201) 1G17 21-21.
  • Page 543 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL FIGURE NO. SUBJECT GRID NO. 24-35. Installation of Drive End Head 24-36. Installation of Rectifier 24-37. Terminal Assembly (Prestolite) 24-38. Slip Ring End Bearing Assembly 24-39. Testing Alternator 24-40. Brush Installation 24-41. Internal Wiring Diagram 27-1.
  • Page 544 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL LIST OF ILLUSTRATIONS (cont) FIGURE NO. SUBJECT GRID NO. 29-10. End Gland Locking Device 2C24 29-11. Main Gear Actuating Cylinder 32-1. Main Gear Oleo Strut Assembly 2D16 32-2. Main Gear Installation 2D17 32-3.
  • Page 545 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL LIST OF ILLUSTRATIONS (cont) FIGURE NO. SUBJECT GRID NO. 55-1. Stabilator Installation 2J13 55-2. Stabilator Balance Configuration 2J14 55-3. Vertical Fin Installation 2J15 55-4. Rudder Installation 2J17 55-5. Rudder Balancing 2J18 56-1. Windshield Installation (Typical) 2J22 56-2.
  • Page 546 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL LIST OF ILLUSTRATIONS (cont) FIGURE NO. SUBJECT GRID NO. 74-12. Assembly Tool 3D21 74-13. Assembly Tool Application 3D22 74-14. Measuring Lead Assembly Length 3D23 74-15. Ferrule Seating Tool 3D24 74-16. Measuring Wire From Top of Ferrule 3D24 74-17.
  • Page 547 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL LIST OF ILLUSTRATIONS (cont) FIGURE NO. SUBJECT GRID NO. ELECTRICAL SCHEMATICS —NOTE— Refer to Grid 313 for Electrical Schematic Index. 95-1. Tire Balancer Fixture 95-2. Control Surface Balancing Tool 95-3. Ignition Harness Ferrule Seating Tool 95-4.
  • Page 548 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL LIST OF CHARTS CHART NO. SUBJECT GRID NO. Leading Particulars and Principal Dimensions 1B18 2101 Troubleshooting (Air Conditioner) 2102 Troubleshooting (Air Conditioning System) 2103 Temperature Pressure Chart 1F12 2104 Aluminum Tubing Torque 1F15...
  • Page 549 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL LIST OF CHARTS (cont) CHART NO. SUBJECT GRID NO. 7101 Troubleshooting Chart (Engine) 3B14 7102 Engine Troubleshooting 7301 Metered Fuel Assembly Calibration 3C22 7302 Limits—Fuel Flow Vs. Brake H.P. 3C22 7401 Troubleshooting (Magneto)
  • Page 550 CHAPTER PROPELLER 3A18...
  • Page 551 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 61 - PROPELLER TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 61-00-00 GENERAL (PA-28RT-201T) 3A20 61-10-00 PROPELLER ASSEMBLY (HARTZELL) 3A20 8-82 61-10-01 Removal of Propeller 3A20 2-79 61-10-02 Cleaning, Inspection and Repair of Propeller...
  • Page 552 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GENERAL. (PA-28RT-201T) PROPELLER ASSEMBLY. (HARTZELL) REMOVAL OF PROPELLER. (Refer to Figure 61-1.) —WARNING— Before performing any work on the propeller, be sure the magneto and master switch is OFF and the mixture control is in the IDLE CUT-OFF position.
  • Page 553 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 61-1. Propeller Installation (Hartzell) Effectivity 61-10-02 PA-28RT-201T Page 61-02 3A21 Revised: August 17, 1982...
  • Page 554 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 9. Each blade face should be sanded lightly with fine sandpaper and painted, when necessary, with a flat black paint to retard glare. A light application of oil or wax may be applied to the surfaces to prevent corrosion.
  • Page 555 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 61-2. Propeller Blade Minor Repair CHART 6101. PROPELLER SPECIFICATIONS 2 Blade 3 Blade Blade Angle Low Pitch (High RPM) 14.4° ± 0.2° 13.2° ± 0.2° High Pitch (Low RPM) 29° ± 1.0°...
  • Page 556 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 61-3. Propeller Governor CHECKING PROPELLER BLADE TRACK. Blade track is the ability of one blade tip to follow the other, while rotating, in almost the same plane. Excessive difference in blade track - more than .0625 inch - may be an indication of bent blades or improper propeller installation.
  • Page 557 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CONTROLLING. REMOVAL OF PROPELLER GOVERNOR. The propeller governor is mounted on the lower left forward portion of the engine crankcase. Remove the governor as follows: 1. Remove the lower cowl to gain access to the governor.
  • Page 558 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 61-4. Propeller Controls 4. With the high RPM adjustment complete, the control system should be adjusted so that the governor control arm will contact the high RPM stop when the cockpit control knob is .032 to .047 of an inch from its full forward stop.
  • Page 559 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GENERAL. (PA-28RT-201) PROPELLER ASSEMBLY. REMOVAL OF PROPELLER. 1. Insure master and magneto switches are off. 2. Move fuel selector to off position. 3. Place mixture control in idle cut-off. —NOTE— Before removing spinner components, reference each mating part to facilitate in alignment for reassembly.
  • Page 560 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 61-5. Propeller Installation (Hartzell) Effectivity PA-28RT 201 61-10-02 Page 61-09 December 1, 1978...
  • Page 561 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 61-6. Propeller Blade Minor Repair CHART 6102. PROPELLER SPECIFICATIONS Hartzell McCauley Blade Angles Low Pitch (High RPM) 14.0° ± 0.2° 12.5° ± 0.2° High Pitch (Low RPM) 29.0° ± 2° 27.5° ± 0.5°...
  • Page 562 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL INSTALLING PROPELLER. 1. Assure master switch and magneto switches are in the off position. 2. Make certain the fuel selector is in the off position and the mixture control is in idle cut-off.
  • Page 563 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 61-7. Propeller Governor INSTALLATION OF PROPELLER GOVERNOR. 1. Clean the mounting pad thoroughly, making very certain that there are no foreign particles in the recess around the drive shaft. 2. Place the governor mounting gasket in position with the raised portion of the screen facing away from the engine.
  • Page 564 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 3. Should engine RPM not be as required, the high RPM setting should be adjusted as follows: A. Shut down the engine and remove the upper engine cowl. B. Adjust the governor by means of the fine adjustment screw for 2700 RPM. To do this, loosen the high RPM fine adjustment screw locknut and turn the screw in a clockwise direction to decrease engine speed or in a counterclockwise direction to increase engine speed.
  • Page 565 CHAPTER STANDARD PRACTICES ENGINE...
  • Page 566 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 70- STANDARD PRACTICES - ENGINES TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 70-00-00 STANDARD PRACTICES - ENGINE 3B11 A 11-79 70 - Cont./Effec. Page- 1 3B10 Added: November 6, 1979...
  • Page 567 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL STANDARD PRACTICES - ENGINE. The following suggestions should be applied wherever they are needed when working on the power plant. 1. To insure proper reinstallation and/or assembly, tag and mark all parts, clips, and brackets as to their location prior to their removal and/or disassembly.
  • Page 568 CHAPTER POWER PLANT 3B12...
  • Page 569 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 71 - POWER PLANT TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 71-00-00 GENERAL (PA-28RT-201T) (CONTINENTAL) 3B14 8-82 71-00-01 Description 3B14 2-79 71-00-02 Troubleshooting 3B14 71-00-03 Removal of Engine 3B20 71-00-04...
  • Page 570 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GENERAL. (PA-28RT-201T) (CONTINENTAL) The purpose of this section is to provide instructions for the removal, minor repair, service and installation of the engine and components. For instructions on major repairs and overhauls, consult the appropriate publication of the component manufacturer.
  • Page 571 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 7101. TROUBLESHOOTING CHART (ENGINE) (cont.) Trouble Cause Remedy Engine starts but fails to Inadequate fuel to fuel mani- Set fuel control in “FULL keep running. fold valve. RICH” position; turn aux- iliary pump “ON,” check to be sure feed lines and filters are not restricted.
  • Page 572 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 7101. TROUBLESHOOTING CHART (ENGINE) (cont.) Trouble Cause Remedy Engine runs rough at speeds Improper fuel-air mixture. Check manifold connections above idle. for leaks. Tighten loose con nections. Check fuel control for setting and adjustment.
  • Page 573 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 7101. TROUBLESHOOTING CHART (ENGINE) (cont.) Trouble Cause Remedy Engine lacks power, reduc- Loose or damaged intake Inspect entire manifold systion tion in maximum manifold manifolding. tem for possible leakage at pressure or critical altitude.
  • Page 574 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 7101. TROUBLESHOOTING CHART (ENGINE) (cont.) Trouble Cause Remedy Low fuel pressure. (cont.) Incorrect fuel injector pump Check and adjust using ap adjustment and operation. propriate equipment. Re place defective pump. Defective fuel injector pump Replace pump if cleaning relief valve.
  • Page 575 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 7101. TROUBLESHOOTING CHART (ENGINE) (cont.) Trouble Cause Remedy Low oil pressure on engine High oil temperature. Defective vernatherm valve gauge. (cont.) in oil cooler; oil cooler re- striction. Replace valve or clean oil cooler.
  • Page 576 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL REMOVAL OF ENGINE. (Refer to Figure 71-1) 1. Turn off all electrical switches in the cockpit and disconnect the battery ground wire at the battery. 2. Move the fuel selector valve in the cockpit to the OFF position.
  • Page 577 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 71-1. Engine Installation (PA-28RT-201T) Effectivity 71-00-03 PA-28RT-201T Page 71-08 3B21 Revised: December 21, 1981...
  • Page 578 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 71-1. Engine Installation (PA-28RT-201T) (cont.) INSTALLATION OF ENGINE. (Refer to Figure 71-1.) Prior to installing the engine, be sure to install all items that were removed after the engine was removed from the aircraft.
  • Page 579 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 7. Route and connect the electrical Ieads to the appropriate connections on the engine. 8. Connect the tachometer drive cable. 9. Connect exhaust manifold at the turbocharger turbine inlet (“Y” connection) and at each exhaust manifold slip joint adjacent to No.
  • Page 580 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 71-2. Engine Cowling Installation MOUNTS. REPLACEMENT OF ENGINE SHOCK MOUNTS. (Refer to Figure 71-1.) 1. Remove the engine cowling. 2. Relieve the engine weight on the mounts using a one-half ton hoist attached to the engine lifting points.
  • Page 581 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GENERAL. (PA-28RT-201) (LYCOMING) This section covers the power plant used in PA-28RT-201 airplanes and is comprised of instructions for the removal, minor repairs, service and installation. For further instructions on major repairs, consult the appropriate publication of the engine or component manufacturer.
  • Page 582 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 7102. ENGINE TROUBLESHOOTING Trouble Cause Remedy Failure of engine to start. Lack of fuel. Check fuel system for leaks. Fill fuel tank. Clean dirty lines, strainers or fuel valves. Check fuel selector valve for proper tank.
  • Page 583 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 7102. ENGINE TROUBLESHOOTING Trouble Cause Remedy Failure of engine to idle Incorrect idle mixture. Adjust mixture. properly. Leak in the induction system. Tighten all connections in the induction system. Re- place any parts that are de- fective.
  • Page 584 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 7102. ENGINE TROUBLESHOOTING Trouble Cause Remedy Low power and uneven Defective ignition wire. Check wire with electric running. (cont.) tester. Replace defective wire. Defective spark plug Replace connectors on spark terminal connectors.
  • Page 585 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 7102. ENGINE TROUBLESHOOTING Trouble Cause Remedy Low oil pressure. (cont.) Stoppage in oil pump intake Check line for obstruction. passage. Clean suction strainer. High oil temperature. See “High Oil Temperature” in “Trouble” column.
  • Page 586 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL REMOVAL OF ENGINE. 1. Turn off all electrical switches in the cockpit and then disconnect the battery ground wire at the battery. 2. Move the fuel selector lever in the cockpit to “OFF.”...
  • Page 587 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 71-3. Engine Installation (PA-28RT-201) Effectivity 71-00-03 PA-28RT-201 Page 71-18 Revised- December 21, 1981...
  • Page 588 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 71-3. Engine Installation (PA-28RT-201) (cont.) Effectivity 71-00-03 PA-28RT-201 Page 71-19 Revised: August 17, 1982...
  • Page 589 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL INSTALLATION OF ENGINE. 1. Attach a one-half ton (minimum) hoist to the engine hoisting straps and swing the engine into alignment with its attaching points. 2. Insert an engine mount bolt, with washer against head, in the engine mount and slide half of the mount assembly on the bolt.
  • Page 590 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL COWLING. REMOVAL OF ENGINE COWLING. 1. Release the cowl fasteners, two on each side of the cowl. 2. Lift the aft end of the cowl and then slide it forward to release the two stud type front fasteners.
  • Page 591 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 1. UPPER COWL ASSEMBLY 2. LOWER COWL ASSEMBLY 3. OIL FILLER DOOR ASSEMBLY 4. FASTENER ASSEMBLY 5. PIN PLATE ASSEMBLY 6. PLATE ASSEMBLY, BUSHING, RETAINING RING, WASHERS, NUTS Figure 71-4. Engine Cowling Installation INSTALLATION OF ENGINE COWLING.
  • Page 592 CHAPTER ENGINE FUEL AND CONTROL 3C12...
  • Page 593 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 73 -ENGINE FUEL AND CONTROL TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 73-00-00 GENERAL (PA-28RT-201T) 3C14 73-10-00 DISTRIBUTION 3C14 73-10-01 Fuel Injection System Maintenance 3C14 73-10-02 Fuel Injector Nozzle Assembly...
  • Page 594 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GENERAL (PA-28RT-201T). DISTRIBUTION. The fuel injection system is a multi-nozzle, continuous flow, altitude compensating system that regulates fuel flow to match engine operating conditions. The system consists of an engine driven fuel pump, a throttle body, a fuel manifold valve and fuel discharge nozzles.
  • Page 595 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 73-1. Schematic Diagram of Fuel Injection System Effectivity 73-10-03 PA-28RT-201T Page 73-02 3C15 Revised: August 17, 1982...
  • Page 596 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CLEANING AND INSPECTION OF FUEL INJECTOR NOZZLES. 1. To clean the nozzles immerse in fresh cleaning solvent, use compressed air to dry. —CAUTION— Do not use wire or other objects to clean orifices.
  • Page 597 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 73-2. Fuel Injector Nozzle Assembly Figure 73-3. Engine Controls Effectivity 73-20-02 PA-28RT-201T Page 73-04 3C17 Revised: August 17, 1982...
  • Page 598 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL B. Connect surgical tubing to the fuel flow (deck pressure) bulkhead fitting and evacuate the line until a 10 gallon per hour (maximum) positive indication on the fuel flow gauge is obtained. Clamp off the tubing and observe the gauge for a steady reading. Any change of this reading would indicate a leak in the system, which must be repaired prior to continuing with the setup procedures.
  • Page 599 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 73-4. Idle Speed and Mixture Adjustment Points Figure 73-5. Sectional View of Altitude Compensating Fuel Pump Assembly Effectivity 73-20-02 PA-28RT-201T Page 73-06 3C19 December 1, 1978...
  • Page 600 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 4. Check and Adjustment of Idle Fuel Pressure: —NOTE— The following setup procedure is accomplished with the boost pump OFF and the engine thoroughly warmed up. A. Back off the idle speed adjusting screw two turns. (Refer to Figure 73-4.) B.
  • Page 601 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 73-6. Exhaust Bypass Screw A. Set the engine at 40.8 to 41.0 in. Hg manifold pressure (overboost light activated) and engine at 2575 + 25 RPM. Readjust the throttle as required to maintain 40.8 to 41.0 in. Hg manifold.
  • Page 602 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 7301. METERED FUEL ASSEMBLY CALIBRATION CHART 7302. LIMITS -FUEL FLOW VS. BRAKE H.P. Effectivity 73-20-02 PA-28RT-201T Page 73-09 3C22 December 1, 1978...
  • Page 603 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL D. With engines operating at 2575 RPM and 40.8 to 41.0 in. Hg manifold pressure, mixture control full rich, reduce RPM and increase throttle until throttle is open. 41.0 in. Hg manifold pressure should be obtained at approximately 2225 + 25 RPM.
  • Page 604 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GENERAL (PA-28RT-201). DISTRIBUTION. FUEL INJECTOR MAINTENANCE. 1. In general, little attention is required between injector overhauls. However, it is recommended that the following items be checked during periodic inspection of the engine: A. Check tightness and lock of all nuts and screws which fasten the injector to the engine, torquing all nuts to 135-150 inch-pounds.
  • Page 605 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 73-7. Fuel Injector THIS SPACE INTENTIONALLY LEFT BLANK Effectivity 73-10-04 PA-28RT-201 Page 73-12 December 1, 1978...
  • Page 606 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 73-8. Schematic Diagram of RSA Fuel Injection System 73-10-04 Effectivity Page 73-13 PA-28RT-201 December 1, 1978...
  • Page 607 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL ADJUSTMENT OF IDLE SPEED AND MIXTURE. 1. Start the engine and warm up in the usual manner until oil and cylinder head temperatures are normal. 2. Check magnetos. If the “mag-drop” is normal, proceed with idle adjustment.
  • Page 608 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 73-9. Fuel-Air Bleed Nozzle Figure 73-10. Adjustment of Engine Controls Effectivity PA-28RT-201 73-20-01 Page 73-15 December 1, 1978...
  • Page 609 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 2. The mixture may be adjusted as follows: A. At the fuel injector, disconnect the clevis end of the mixture control cable from the control arm. Loosen the jam nut that secures the clevis end.
  • Page 610 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 611 CHAPTER IGNITION...
  • Page 612 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 74-IGNITION TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 74-00-00 GENERAL (PA-28RT-201T) 3D10 74-01-00 Description and Operation 3D10 74-02-00 Troubleshooting 3D10 74-10-00 ELECTRICAL POWER SUPPLY 3D11 74-11-00 Magnetos 3D11 74-11-01 Inspection of Magnetos...
  • Page 613 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 74-IGNITION (cont.) TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 74-00-00 GENERAL (PA-28RT-201) (cont.) 74-20-00 DISTRIBUTION 3E15 74-21-00 Inspection of Harness 3E15 74-21-01 Removal of Harness 3E15 74-21-02 Maintenance of Harness...
  • Page 614 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GENERAL. (PA-28RT-201T) DESCRIPTION AND OPERATION. The magneto used on this engine is a completely self-contained unit featuring a rotating magnet and a two lobe cam which operates the main breaker points. This magneto uses an impulse coupling to provide reliable ignition at engine cranking speed.
  • Page 615 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL ELECTRICAL POWER SUPPLY. MAGNETOS. —CAUTION— Ascertain that the primary circuits of both magnetos are grounded before working on the engine. —NOTE— The magneto service instructions in this manual cover minor repairs and timing. For further repairs and adjustments of the magnetos, it is recommended that the magneto manufacturer’s...
  • Page 616 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 74-1. Magneto Assembly Effectivity 74-11-01 PA-28RT-201T Page 74-03 3D12 December 1, 1978...
  • Page 617 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 74-2. Contact Spring Inspection 8. Minor irregularities or roughness of point surfaces are not harmful (refer to Figure 74-3, center), neither are small pits or mounds, if not too pronounced. If there is a possibility of pit becoming deep enough to penetrate pad, Figure 74-3, right, reject contact assembly.
  • Page 618 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 74-3. Contact Points 12. Inspect coil leads for damaged insulations and terminals for tightness and soldered connection. 13. Inspect impulse coupling parts for excessive wear. Particularly check clearance between cam and flyweights of the cam assembly. Measure the clearance between the cam flyweights using the shank of a new No.
  • Page 619 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 74-4. Impulse Coupling Figure 74-5. Flyweight Clearance of Impulse Coupling Figure 74-6. Rotor Holding Tool Installed Figure 74-7. Timing Kit Installed Effectivity 74-11-01 PA-28RT-201T Page 74-06 3D15 December 1, 1978...
  • Page 620 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL REMOVAL OF MAGNETO. 1. Remove the engine cowl. 2. Disconnect the “P” lead from the magneto. 3. Remove the harness outlet plate from the magneto by removing the four attaching screws. 4. Remove the two nuts and washers securing the magneto to the engine accessory housing.
  • Page 621 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 74-8. Cast-In Timing Marks Figure 74-9. Fabricated Pointer Figure 74-10. Engine Timing Marks Effectivity 74-11-03 PA-28RT-201T Page 74-08 3D17 Revised: February 23, 1979...
  • Page 622 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 2. The internal timing can be checked without a timing kit using the cast-in marks in the breaker compartment. These marks indicate “E” gap and limits (refer to Figure 74-8). The point in the center of the “E”...
  • Page 623 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL rubber bushings and insert the bushings into the retainers, rounded long edges first. F. Place a new gasket on the magneto flange. Install the magneto carefully so the drive coupling lugs mate with the slots of the drive bushings. Install and snug down the two sets of attaching screws.
  • Page 624 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL F. When testing leads which are installed on an engine, it may be found that distributed capacitance causes the tester to reject good leads if the tester and red test lead are allowed to lay in close physical contact with the engine parts.
  • Page 625 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 74-12. Assembly Tool MAINTENANCE OF HARNESS. 1. To replace contact springs, spring retainer assemblies or insulating sleeves, proceed as follows: A. Using a Bendix 11-7073 Needle or a mechanical pencil with the lead retracted, hook the end of the contact spring as shown in Figure 74-11.
  • Page 626 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 2. To replace one of the lead assemblies, proceed as follows: A. Remove the clamps and brackets from the applicable lead assembly. Cut the cable ties from the assembly and discard them. B. Cut off the condemned lead flush with the outer surface of the cable outlet plate.
  • Page 627 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 74-14. Measuring Lead Assembly Length F. Cut the lead assembly to the length determined in Step E. Mark the ferrule on the spark plug end of the lead with a metal stamp, scribe or rubber stamp to correspond with the correct cylinder number.
  • Page 628 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 74-15. Ferrule Seating Tool Figure 74-16.Measuring Wire From Top of Ferrule Figure 74-17.Needle Figure 74-18. Installing Grommet Over Lead Assemblies Effectivity 74-21-02 PA-28RT-201T Page 74-16 3D24 December 1, 1978...
  • Page 629 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL J. Pass the lead through the proper hole in outlet plate. Position the Bendix l l-9596 or equivalent Braid Cutting Back-up Tube between the braided shielding and insulation to protect the insulation. Cut enough braid from the lead to have 1-1/4 inch of insulation extending from end of braid.
  • Page 630 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 74-l9. Lead Assembly Installed in Figure 74-20. Wire Doubled Over For Grommet Installation of Eyelet P. Using a suitable crimping tool or equivalent, crimp the eyelet to the wire. Approximately 1/32 inch of wire should extend from the end of the eyelet after crimping.
  • Page 631 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 74-21. Ignition Schematic Effectivity 74-21-02 PA-28RT-201T Page 74-18 December 1, 1978...
  • Page 632 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL INSTALLATION OF HARNESS. Before installing the harness plate on the magneto, check the mating surfaces for cleanliness. Spray the entire face of the grommet with a light coat of Plastic Mold Spray, SM-O-O-TH Silicone Spray or equivalent.
  • Page 633 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 74-22. Removing Frozen Spark Plug 4. Removal of seized spark plugs in the cylinder may be accomplished by application of liquid carbon dioxide by a conical metal funnel adapter with a hole at the apex just large enough to accommodate the funnel of a CO2 bottle.
  • Page 634 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL INSTALLATION OF SPARK PLUGS. Before installing spark plugs, ascertain that the threads within the cylinder are clean and not damaged. 1. Apply anti-seize compound sparingly on the threads and install gasket and spark plugs. Torque 360 to 420 inch-pounds.
  • Page 635 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GENERAL. (PA-28RT-201) DESCRIPTION AND OPERATION. The S-1200 series magneto used on this engine is a completely self-contained unit featuring a rotating magnet and a two lobe cam which operates the main breaker points. This magneto uses an impulse coupling to provide reliable ignition at engine cranking speed.
  • Page 636 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL ELECTRICAL POWER SUPPLY. MAGNETO. —CAUTION— Ascertain that the primary circuit of both magnetos is grounded before working on the engine. INSPECTION OF MAGNETO. —NOTE— Comply with the latest revision to Bendix Service Bulletin No.
  • Page 637 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 74-23. Contact Points 7. Check the condition of the cam follower felt. Squeeze felt tightly between thumb and forefinger. If fingers are not moistened with oil, re-oil using 2 or 3 drops of Scintilla 10-391200 lubricant. Allow approximately 30 minutes for felt to absorb the oil.
  • Page 638 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 74-24. Rotor Holding Tool Installed Figure 74-25. Timing Kit Installed Figure 74-26. Aligning Timing Marks Figure 74-27. Checking Flyweight Clearance of Impulse Coupling Effectivity 74-11-01 PA-28RT-201 Page 74-25 3E10 December 1, 1978...
  • Page 639 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL REMOVAL OF MAGNETO. Before removing the magneto, make sure magneto switches are off. 1. Remove the harness assembly terminal plate from the magneto. —WARNING— The magneto is not internally grounded; when the ground lead is disconnected, the magneto is hot.
  • Page 640 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 4. If the distributor block was removed from the housing, the distributor gear alignment and internal check may be accomplished as follows: A. Turn rotating magnet in direction of rotation until it is located in firing position (keyway up and points just opening).
  • Page 641 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 74-28. Engine Timing Marks Figure 74-29. Magneto Adjustment Limits INSTALLATION AND TIMING PROCEDURE. (Timing Magneto To Engine) Although only the left magneto is equipped with an impulse coupling, the timing procedure, in the following paragraphs, is the same for both magnetos.
  • Page 642 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 74-30. Magneto Timing Marks 2. At this point, the engine is ready for assembly of the magnetos. Remove the inspection plugs from both magnetos and turn the drive shafts in direction of normal rotation (counterclockwise facing the coupling), until the first painted chamfered tooth on the distributor gear is aligned in the center of the inspection window.
  • Page 643 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL DlSTRIBUTION. INSPECTION OF HARNESS. 1. Check lead assemblies for nicks, cuts, mutilated braiding, badly worn section or any other evidence of physical damage. Inspect spark plug sleeves for chafing or tears and damaged or stripped threads on coupling nuts.
  • Page 644 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 74-32. Assembly Tool Figure 74-33. Using Assembly Tool Effectivity 74-21-01 PA-28RT-201 Page 74-31 3E16 December 1, 1978...
  • Page 645 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 74-34. Measuring Lead Assembly Length Figure 74-35. Cutting Metallic Braid From End Figure 74-36. Unbraiding Metallic Shielding of Lead Effectivity 74-21-01 PA-28RT-201 Page 74-32 3E17 December 1, 1978...
  • Page 646 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL MAINTENANCE OF HARNESS. 1. To replace contact springs, spring retainer assemblies or insulating sleeves, proceed as follows: A. Using a Scintilla 11-7073 Needle or a mechanical pencil with the lead retracted, hook the end of the contact spring as shown in Figure 74-31.
  • Page 647 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 74-37. Forming Shielding Around Ferrule Figure 74-38. Ferrule Seating Tool Figure 74-39. Needle Effectivity 74-21-02 PA-28RT-201 Page 74-34 3E19 December 1, 1978...
  • Page 648 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL I. Using a scribe or similar pointed tool, unbraid 3/8 inch of braided shielding. (Refer to Figure 74- 36.) Wrap a single thickness of electrical tape around unbraided strands to facilitate insertion of lead end through hole in cable outlet plate.
  • Page 649 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 74-40. Measuring Wire From Top of Figure 74-41. Installing Grommet Over Lead Ferrule Assemblies Figure 74-42. Lead Assembly Installed in Figure 74-43. Wire Doubled Over for Installation Grommet of Eyelet Effectivity 74-21-03...
  • Page 650 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 74-44. Removing Spark Plug Frozen to Bushing SPARK PLUGS. REMOVAL OF SPARK PLUGS. 1. Loosen the coupling nut on the harness lead and remove the terminal insulator from the spark plug barrel well.
  • Page 651 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 2. Remove the spark plug from the engine. In the course of engine operation, carbon and other combustion products will be deposited on the end of the spark plug and will penetrate the lower threads to some degree.
  • Page 652 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL INSTALLATION OF SPARK PLUGS. Before installing spark plugs, ascertain that the threads within the cylinder are clean and not damaged. 1. Apply anti-seize compound sparingly on the threads and install gasket and spark plugs. Torque 360 to 420 inch-pounds.
  • Page 653 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL SWITCHING. REMOVAL OF IGNITION SWITCH. 1. Insure the ignition switch is in the OFF position. 2. Gain access to and disconnect the power lead (+) from the battery. 3. Remove the ignition switch retaining nut from the switch on the forward side of the instrument panel and withdraw the switch from the panel.
  • Page 654 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 3F2 THRU 3F15 INTENTIONALLY LEFT BLANK...
  • Page 655 CHAPTER ENGINE INDICATING 3F16...
  • Page 656 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 77- ENGINE INDICATING TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRlD SUBJECT SUBJECT EFFECTIVITY 77-00-00 GENERAL 3F18 77-10-00 POWER 3F18 77-10-01 Manifold Pressure Gauge 3F18 77-10-02 Tachometer Indicator 3F19 77-10-03 Engine Oil Pressure Gauge...
  • Page 657 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GENERAL. POWER. MANIFOLD PRESSURE GAUGE. The manifold pressure gauge is a vapor proof, absolute pressure type instrument. Pressure from the intake manifold of the engine is transmitted to the instrument through a line. A pointer indicates the manifold pressure available at the engine in inches of mercury.
  • Page 658 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL TACHOMETER INDICATOR. The tachometer is connected to the engine accessory by a flexible cable and provides an indication of crankshaft speed in revolutions per minute. The instrument has a recording mechanism for recording the time that the engine is in actual operation.
  • Page 659 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL ENGINE OIL PRESSURE GAUGE. The oil pressure gauge is mounted in the cluster on the instrument panel. This gauge will indicate the amount of oil pressure available at the pressurized engine oil passage.
  • Page 660 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL EXHAUST GAS TEMPERATURE GAUGE. (Alcor) This instrument, which is commonly referred to as EGT, is used to aid the pilot in selecting the economical fuel-air mixture for cruising flight at a power setting of 75% or less. It is a sensing device to monitor the fuel air mixture leaving the engine cylinders.
  • Page 661 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 7705. TROUBLESHOOTING (EXHAUST GAS TEMPERATURE GAUGE) (Alcor) Trouble Cause Remedy Gauge inoperative. Defective gauge, probe or Check probe and lead wires wiring. for chafing, breaks or short- ing between wires and/or metal structure.
  • Page 662 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK 3F23...
  • Page 663 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK 3F24...
  • Page 664 CHAPTER EXHAUST...
  • Page 665 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 78- EXHAUST TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 78-00-00 GENERAL 78-00-01 Inspection of Exhaust System 78 - Cont./Effec. Page - 1 Revised: December 21, 1981...
  • Page 666 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GENERAL. INSPECTION OF EXHAUST SYSTEM. (Refer to Figure 78-1.) The entire exhaust system, including heat exchange shroud, muffler, muffler baffles, stacks and all exhaust connections must be rigidly inspected at each 100 hour inspection. The possibility of exhaust system failure increases with use.
  • Page 667 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 78-1. Exhaust System Inspection Points 78-00-01 Page 78-02 Revised: February 23, 1979...
  • Page 668 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 669 CHAPTER OIL SYSTEM...
  • Page 670 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 79- OIL SYSTEM TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 79-00-00 GENERAL 79-00-01 Installation of Oil Cooler 79-00-02 Engine Oil Quick Drain 79-30-00 INDICATING 79-30-01 Removal of Oil Pressure Sensor...
  • Page 671 6. After installation, inspect the cooler for distorted end cups. 7. Run-up engine. After run-up, check for oil leaks. ENGINE OIL QUICK DRAIN VALVE. When replacing the engine oil quick drain, refer to the Piper Parts Catalog for the correct replacement part number. —CAUTION—...
  • Page 672 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 673 CHAPTER STARTING 3G10...
  • Page 674 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 80 - STARTING TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 80-00-00 GENERAL 3G12 80-00-01 Description and Operation 3G12 80-00-02 Troubleshooting 3G12 80-10-00 CRANKING 3G15 80-10-01 Maintenance of Starting System 3G15...
  • Page 675 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GENERAL. DESCRIPTION AND OPERATION. (Refer to Figure 80-1.) The gear reduction starting motor consists of six major components: The Commutator End Head Assembly, The Armature, The Frame and Field Assembly, The Gear Housing, The Pinion Housing, and The Bendix Drive Assembly.
  • Page 676 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 8001. TROUBLESHOOTING (STARTER) Trouble Cause Remedy Motor fails to operate. Low battery charge. Check and recharge if necessary. Defective or improper Refer to electrical wiring wiring or loose connec- diagram and check all tions.
  • Page 677 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 8001. TROUBLESHOOTING (STARTER) (cont) Trouble Cause Remedy Motor fails to operate. Dirty commutator. If commutator is rough or (cont) dirty, smooth and polish with number 0000 sand- paper. If too rough and pitted, remove and turn down.
  • Page 678 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 80-1. Exploded View of Gear Reduction Starting Motor CRANKING. MAINTENANCE OF STARTING SYSTEM. The starting circuit should be inspected at regular intervals, the frequency of which should be determined by the amount of service and the conditions under which the vehicle is operated. It is recommended that such inspection be made at each 100 hours and include the following: 1.
  • Page 679 5. Check aluminum cables used in the battery circuit for loose or corroded terminals or other unsatisfactory conditions. —NOTE— Should an unsatisfactory condition exist, Piper recommends that the complete cable assembly be replaced. Should this not be practical, it is permissible to replace the aluminum cable...
  • Page 680 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 80-2. Turning Starting Figure 80-3. Testing Motor Armature Motor Commutator for Shorts Figure 80-4. Testing Motor Fields for Grounds 80-10-05 Page 80-06 3G17 December 1, 1978...
  • Page 681 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL BRUSHES. Check the brushes to see that they slide freely in their holders and make full contact on the commutator. If worn to half their original length or less, they should be replaced.
  • Page 682 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 80-5. No-Load Test Hook-up Figure 80-6. Stall-Torque Hook-up ASSEMBLY OF STARTING MOTOR. 1. When assembling the starting motor, always use an arbor press and the proper bearing arbor for installing graphitized bronze and roller bearings. The Bendix shaft should have a thin film of Lubriplate #777 or equivalent on the Bendix portion of the shaft.
  • Page 683 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL BENCH TEST. 1. After the starting motor is reassembled, it should be tested to see that the no-load current at a certain voltage is within specifications as given in Starting Motor Service Test Specifications. To make this test, connect as shown in Figure 80-5.
  • Page 684 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL STARTING MOTOR SERVICE TEST SPECIFICATIONS. Prestolite specifications for 12-volt starting motors installed as standard equipment on PA-28 series airplanes are as follows: CHART 8002. STARTING MOTOR SERVICE TEST SPECIFICATIONS Aircraft Model PA-28RT-201 PA-28RT-201T...
  • Page 685 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK 3G22...
  • Page 686 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK 3G23...
  • Page 687 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK 3G24...
  • Page 688 CHAPTER TURBINES...
  • Page 689 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 81 - TURBINES TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 81-00-00 GENERAL 81-00-01 Description and Operation 81-20-00 TURBOCHARGER 12-81 81-20-01 Removal of Turbocharger 81-20-02 Installation of Turbocharger 81-20-03 Adjustment of Turbocharger...
  • Page 690 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GENERAL. DESCRIPTION AND OPERATION. The turbocharger system consists of a turbine and compressor assembly, ground adjustable exhaust bypass screw and the necessary hose and engine air intake ducts. The ground adjustable exhaust bypass screw allows exhaust gas to bypass the turbine and flow directly overboard.
  • Page 691 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 81-1. Schematic Diagram of Turbocharger System 81-20-02 Page 81-02 December 1, 1978...
  • Page 692 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 4. Place turbine housing insulation blanket in proper position and safety blanket to turbocharger attaching hardware. 5. Position the exhaust tailpipe and exhaust bypass screw to the turbine outlet, aligning the tailpipe with the hole cut out in the lower cowl provided for it.
  • Page 693 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK...
  • Page 694 CHAPTER CHARTS WIRING DIAGRAMS...
  • Page 695 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 91 - CHARTS AND WIRING DIAGRAMS TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 91-00-00 GENERAL A 12-81 91-00-01 TORQUE REQUIREMENTS 7-81 91-00-02 Flare Fitting Torques 3H10 12-81 91-00-03 Recommended Nut Torques...
  • Page 696 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL GENERAL. This chapter contains miscellaneous charts which are applicable to various chapters and systems covered in this manual. All electrical schematics are also included in this chapter. TORQUE REQUIREMENTS. The torque values given in Chart 9102 are derived from oil-free cadmium-plated threads and are recommended for all airframes installation procedures when torquing is required, unless otherwise noted in sections where other values are stipulated.
  • Page 697 PA-28RT-201 / 201T MAINTENANCE MANUAL 7. Unless otherwise specified, parts used on Lycoming engines with Piper furnished or existing Lycoming threaded fasteners, shall be torqued to the specifications listed in the latest revision of Lycoming Service Table of Limits No. SSP-1776.
  • Page 698 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL RECOMMENDED NUT TORQUES. CHART 9102. RECOMMENDED NUT TORQUES TORQUES: The importance of correct application can not be overemphasized. Undertorque can result in unnecessary wear of nuts and bolts as well as the parts they are holding together. When...
  • Page 699 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL CHART 9102. RECOMMENDED NUT TORQUES (cont) 91-00-03 Page 91-04 3H12 Revised- December 21, 1981...
  • Page 700 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CONVERSION CHARTS. CHART 9103. CONVERSION TABLES 1. These charts contain the various conversion data that may be useful when figuring capacities, lengths, temperatures, and various weights and measures from the English system values to the metric system values or back again.
  • Page 701 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 9103. CONVERSION TABLES (cont) 91-00-04 Page 91-06 3H14 Added: November 6, 1979...
  • Page 702 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 9103. CONVERSION TABLES (cont) 91-00-04 Page 91-07 3H15 Added: November 6, 1979...
  • Page 703 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 9103. CONVERSION TABLES (cont) 91-00-04 3H16 Page 91-08 Added: November 6, 1979...
  • Page 704 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS PAGE INTENTIONALLY LEFT BLANK 3H17...
  • Page 705 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL CHART 9103. CONVERSION TABLES (cont) 91-00-04 Page 91-09 3H18 Added: November 6, 1979...
  • Page 706 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL DECIMAL/MILLIMETER EQUIVALENTS OF DRILL SIZES. CHART 9104. DECIMAL/MILLIMETER EQUIVALENTS OF DRILL SIZES 91-00-05 Page 91-10 3H19 Revised: December 21, 1981...
  • Page 707 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL CONSUMABLE MATERIALS. CHART 9105. LIST OF CONSUMABLE MATERIALS MATERIAL SPECIFICATION PRODUCT VENDOR Fuel, Engine 100 octane green/blue (See Note 1) Oil, Engine MIL-L-6082 or MIL-L-22851 (See Note 3) Corrosion Preven- MIL-C-6529 Type II...
  • Page 708 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL CHART 9105. LIST OF CONSUMABLE MATERIALS (cont) MATERIAL SPECIFICATION PRODUCT VENDOR Lubricating Grease Aeroshell No 22 (High Temperature) Shell Oil Co., 50 West 50th (Cont) Street, New York, N Y. Lubricating Grease MIL-G-23827 Supermil Grease No.
  • Page 709 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL CHART 9105. LIST OF CONSUMABLE MATERIALS (cont) MATERIAL SPECIFICATION PRODUCT VENDOR Toluol TT-T-548 Buffing and Rubbing Automotive Type- DuPont Company Compounds DuPont #7 Wilmington, Del. 19898 Ram Chemical #69 x 1 Ram Chemicals Gardena, Cal.
  • Page 710 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL CHART 9105. LIST OF CONSUMABLE MATERIALS (cont) MATERIAL SPECIFICATION PRODUCT VENDOR Teflon Tape Teflon .003 x .50 Minnesota Mining & wide/-1 Manufacturing Co. 3M Center St. Paul, Minnesota 55101 Teflon Tape Teflon .003 x .50 Shamban W.S.
  • Page 711 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL CHART 9105. LIST OF CONSUMABLE MATERIALS (cont) MATERIAL SPECIFICATION PRODUCT VENDOR Rain Repellent FSCM 50159 Repcon Unelko Corporation 727 110th Street Chicago, Illinois 60628 Tube Fitting Swageloc Fitting Crawford Fitting Co. 29500 Solon Road Solon, Ohio 44139 —NOTES—...
  • Page 712 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL ELECTRICAL WIRE CODING AND SYMBOLS. CHART 9106. ELECTRICAL WIRE CODING CIRCUIT FUNCTION LETTER CIRCUITS AUTOPILOT CONTROL SURFACE ENGINE INSTRUMENT FLIGHT INSTRUMENT LANDING GEAR HEATER - VENTILATION & DEICING LIGHTING POWER FUEL & OIL...
  • Page 713 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHART 9107. ELECTRICAL SYMBOLS 91-00-09 Page 91-17 Revised: August 17, 1982...
  • Page 714 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL ELECTRICAL SCHEMATIC INDEX FIGURE NO. SCHEMATIC GRID NO. ANNUNCIATOR SYSTEMS Annunciator 91-1 PA-28RT-201: Early Models 91-2 Later Models w/Panel 91-3 PA-28RT-201T: Early Models 91-4 Later Models w/Panel COMFORT SYSTEMS Cigar Lighter 91-5 PA-28 RT-201/201T...
  • Page 715 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL ELECTRICAL SCHEMATIC INDEX (cont.) FIGURE NO. SCHEMATIC GRID NO. FUEL SYSTEMS Fuel Pump 91-15 PA-28RT-201 3I17 Fuel Pump/Diverter Valve/Aux. Fuel Ind. 91-17 PA-28RT-201T 3I17 INDICATORS Annunciator (See Annunciator Systems) Ammeter (See Alternator Systems)
  • Page 716 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL ELECTRICAL SCHEMATIC INDEX (cont.) FIGIJRE NO. SCHEMATIC GRID NO. LIGHTING - INTERNAL Cabin/Overhead Flood 91-29 PA-28RT-201: S/N’s: 28R-7918001 to 8118039 3I23 91-30 S/N’s: 28R-8118040 and up 3I23 91-29 PA-28RT-201T: S/N’s: 28R-7931001 to 8131041...
  • Page 717 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 91-1. Annunciator, PA-28RT-201 (Early Models) 91-00-09 Page 91-18 Added: August 17, 1982...
  • Page 718 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 91-2. Annunciator, PA-28RT-201 (Later Models w/Panel) 91-00-09 Page 91-19 Added: August 17, 1982...
  • Page 719 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 91-3. Annunciator, PA-28RT-201T (Early Models) 91-00-09 Page 91-20 Added: August 17, 1982...
  • Page 720 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 91-4. Annunciator, PA-28RT-201T (Later Models w/Panel) 91-00-09 Page 91-21 Added: August 17, 1982...
  • Page 721 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS SPACE INTENTIONALLY LEFT BLANK Figure 91-5. Cigar Lighter, PA-28RT-201/201T Figure 91-6. Pitot/Static, PA-28R-201 and 201T Figure 91-7. Avionics Switching/Emergency Bus 91-00-09 Page 91-22 3I10 Revised: August 17, 1982...
  • Page 722 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 91-8. Alternator System/External Power, PA-28RT-201 S/N’s: 28R-7918001 to 7918306, PA-28RT- 201T S/N’s: 28R-7931001 to 7931353 91-00-09 Page 91-23 3I11 Revised: August 17, 1982...
  • Page 723 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 91-9. Alternator System/External Power, PA-28RT-201 S/N’s: 28R-8018001 to 8118005, PA-28RT- 201T S/N’s: 28R-8031001 to 813005 91-00-09 Page 91-24 3I12 Revised: August 17, 1982...
  • Page 724 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 91-10. Alternator System/External Power, PA-28RT-201 S/N’s: 28R-8118006 and up, PA-28RT-201T S/N’s: 28R-8131006 and up 91-00-09 Page 91-25 3I13 Revised: August 17, 1982...
  • Page 725 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 91-11. Starter; PA-28RT-201 S/N’s: 28R-7918001to8018116, PA-28RT-201T S/N’s: 28R-7931001 to 8031188 Figure 91-12. Starter, PA-28RT-201 S/N’s: 28R-8118001 and up, PA-28RT-201T S/N’s: 28R-8131001 and up 91-00-09 Page 91-26 3I14 Added: August 17, 1982...
  • Page 726 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 91-13. Air Conditioning, PA-28RT-201 S/N’s: 28R-7918001 to 8018116, PA-28RT-201T S/N’s: 28R-7931001 to 8031188 91-00-09 Page 91-27 3I15 Revised: August 17, 1982...
  • Page 727 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 91-14. Air Conditioning, PA-28RT-201 S/N’s: 28R-8118001 and up, PA-28RT-201T S/N’s: 28R-8131001 and up 91-00-09 Page 91-28 3I16 Added: August 17, 1982...
  • Page 728 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 91-15. Fuel Pump, PA-28RT-201 Figure 91-16. Turn and Bank, PA-28RT-201 and 201T Figure 91-17. Fuel Pump, Prime Switch, Diverter Valve and Manifold Pressure Switch, PA-28RT-201T 91-00-09 3I17 Page 91-29 Revised: August 17, 1982...
  • Page 729 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 91-18. Electric Clock, Digital Clock and Hourmeter Installation (Optional) Figure 91-19. Engine Gauges and Senders, PA-28RT-201 91-00-09 3I18 Page 91-30 Revised: August 17, 1982...
  • Page 730 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 91-20. Engine Gauges and Senders, PA-28RT-201T Figure 91-21. Engine Gauges and Senders, PA-28RT-201T 91-00-09 Page 91-31 3I19 Revised: August 17, 1982...
  • Page 731 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 91-22. Landing Gear, PA-28RT-201/201T (Early Models) 91-00-09 Page 91-32 3I20 Added: August 17, 1982...
  • Page 732 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 91-23. Landing Gear, PA-28RT-201 S/N’s: 28R-7837025 and up, PA-28RT-201T S/N’s: 28R-7803057 and up 91-00-09 Page 91-33 3I21 Revised: August 17, 1982...
  • Page 733 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 91-24. Anti-Collision Beacon, Figure 91-25. Anti-Collision Strobe, PA-28RT-201 only PA-28RT-201 and 201T Figure 91-26. Landing Light, Figure 91-27. Navigation Lights PA-28RT-201 and 201T 91-00-09 Page 91-34 3I22 Revised: August 17, 1982...
  • Page 734 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 91-28. Navigation Lights, Figure 91-29. Cabin/Overhead Flood Light PA-28RT-201 S/N’s: 28R-8118040 and up, PA-28RT-201T S/N’s: 28R-8131042 and up Figure 91-30. Cabin/Overhead Flood Lights Figure 91-31. Dimmer/Switch and Radio Lights, PA-28RT-201 (Early Models)
  • Page 735 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 91-32. Dimmer/ Instrument Lights Control, PA-28RT-201T (Early Models) Figure 91-33. Dimmer/ Instrument Lights Control, PA-28RT-201T (Later Models) 91-00-09 Page 91-36 3I24 Revised: August 17, 1982...
  • Page 736 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 91-34. Dimmer Control Assembly, PA-28RT-201/201T 91-00-09 Page 91-37 Added: August 17, 1982...
  • Page 737 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL THIS SPACE INTENTIONALLY LEFT BLANK Figure 91-35. Stall Warning, PA-28RT-201 and 201T —END— 91-00-09 Page 91-38 Revised: August 17, 1982...
  • Page 738 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 3J3 THRU 3J24 INTENTIONALLY LEFT BLANK...
  • Page 739 CHAPTER SPECIAL PURPOSE EQUIPMENT...
  • Page 740 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL CHAPTER 95 - SPECIAL PURPOSE EQUIPMENT TABLE OF CONTENTS/EFFECTIVITY CHAPTER SECTION GRID SUBJECT SUBJECT EFFECTIVITY 95-00-00 GENERAL A 12-81 95-10-00 TOOLS AND TEST EQUIPMENT A 12-81 95-10-01 Tire Balancer Building Instructions A 12-81 95- Cont./Effec.
  • Page 741 Some special tools other than normal shop tools will be required to service the aircraft. An illustrated list of tools required follows. —NOTE— Tools with Part Numbers given are available through the Piper Service Department. Specifications for fabricated tools may be found by referring to the appropriate illustration Figure number in the maintenance manual following the list of tools.
  • Page 742 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL Figure 95-1. Tire Balancer Fixture TIRE BALANCER BUILDING INSTRUCTIONS. 1. Chamfer top edges of -3 sides, leaving 1/16 inch flat on top inboard edge. Rivet -2 tee’s to -3 sides using AN 470-AD5 rivets 2” spacing. Use AN 426-AD5 rivets 2” center to center to secure -2 tee’s to -1 base.
  • Page 743 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL Figure 95-2. Control Surface Balancing Tool 95-10-01 Page 95-03 Added: December 21, 1981...
  • Page 744 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 95-3. Ignition Harness Ferrule Figure 95-4. Needle Seating Tool Figure 95-5. Assembly Tool For Ignition Harness Insulating Sleeve Installation 95-10-01 Page 95-04 Added: December 21, 1981...
  • Page 745 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 95-6. Charging Stand Figure 95-7. York Compressor and Fabricated Oil Dipstick (PA-28RT-201) 95-10-01 Page 95-05 Added: December 21, 1981...
  • Page 746 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 95-8. Fabricated Gear Back-Up Extender Actuator Aligning Tool 95-10-01 Page 95-06 Added: December 21, 1981...
  • Page 747 PIPER AIRCRAFT PA-28RT-201 / 201T *MAINTENANCE MANUAL Figure 95-9. Fabricated Stabilator Rigging Tool 95-10-01 Page 95-07 Added: December 21, 1981...
  • Page 748 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 95-l0. Fabricated Aileron and Flap Rigging Tool 95-10-01 Page 95-08 3K10 Revised: August 8, 1984...
  • Page 749 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 95-11. Fabricated Aileron Bellcrank Rigging Tool Figure 95-12. Fabricated Rudder Rigging Tool 95-10-01 Page 95-09 3K11 Added: December 21, 1981...
  • Page 750 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 95-13. Fabricated Tool for Baggage Door Lock Figure 95-14. Retainer Ring Tool 95-10-01 Page 95-10 3K12 Added: December 21, 1981...
  • Page 751 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL Figure 95-15. Orifice Replacement Tool 95-10-01 Page 95-11 3K13 Added: December 21, 1981...
  • Page 752 PIPER AIRCRAFT PA-28RT-201 / 201T MAINTENANCE MANUAL 3K14 THRU 3L24 INTENTIONALLY LEFT BLANK 3K14...
