GENERAL. (PA-28RT-201T) (CONTINENTAL)
The purpose of this section is to provide instructions for the removal, minor repair, service and installation
of the engine and components. For instructions on major repairs and overhauls, consult the appropriate
publication of the component manufacturer.
DESCRIPTION.
The PA-28RT-201T is powered by a Teledyne Continental TS1O-360-FB turbocharged, overhead valve,
air cooled, horizontally opposed, direct drive, wet sump engine rated at 200 hp from sea level to 12,000 feet
density altitude.
The engine is enclosed by a cowling consisting of an upper, lower and nose section.
The propeller is a Hartzell constant speed, controlled by a governor mounted on the engine supplying oil
through the propeller shaft at various pressures. Oil pressure from the governor moves the blades into high
pitch (low RPM ). The centrifugal twisting moment of the blade also tends to move the blades into low pitch.
Refer to Chapter 28 for description of fuel system and primer operation.
TROUBLESHOOTING.
Troubles peculiar to the power plant are listed in Chart 7101, along with the probable causes and suggested
remedies. When troubleshooting engine, propeller or fuel system, always ground the magneto primary circuit
before performing any checks.
Trouble
Engine will not start.
Effectivity
PA-28RT-201T
PIPER AIRCRAFT
PA-28RT-201 / 201T
MAINTENANCE MANUAL
CHART 7101. TROUBLESHOOTING CHART (ENGINE)
No fuel gauge pressure - no
fuel to engine.
Have gauge pressure -
engine flooded.
Have gauge pressure - no
fuel to engine.
Cause
3B14
Remedy
Check fuel control for proper
position, auxiliary pump
"ON" and operating, feed
valves open. Fuel filters
open and tank fuel level.
Turn off auxiliary pump and
ignition switch; set throttle
to "FULL OPEN" and fuel
control to "IDLE CUT-
OFF," and crank engine to
clear cylinders of excess fuel.
Repeat starting procedure.
Check for bent or loose fuel
lines. Loosen line at fuel
nozzle. If no fuel shows, re
place fuel manifold valve
71-00-02
Page 71-01
Revised: August 17, 1982
