Blade Angles
1
1 Measured at 30 inch station.
Propeller RPM Setting
Propeller Torque Limits
Effectivity
PA-28RT-201
PIPER AIRCRAFT
PA-28RT-201 / 201T
MAINTENANCE MANUAL
Figure 61-6. Propeller Blade Minor Repair
CHART 6102. PROPELLER SPECIFICATIONS
Low Pitch (High RPM)
High Pitch (Low RPM)
Engine Static High RPM
Description
Propeller Mounting Nuts
Forward Bulkhead Attach-
ment Bolts
Aft Bulkhead Attachment
Bolts
Spinner Attachment Screws
3B5
Hartzell McCauley
14.0° ± 0.2° 12.5° ± 0.2°
29.0° ± 2° 27.5° ± 0.5°
2700 RPM Max.
Required Torque (Dry)
60-70 foot-pounds (Hartzell)
55-65 foot-pounds (McCauley)
30-35 inch-pounds (Hartzell)
50-70 inch-pounds
20-25 inch-pounds
