Introduction

Open loop AC drive
Unidrive M200 and Unidrive M201 deliver maximum machine performance with open loop vector and sensorless induction motor control, for dynamic
and efficient machine operation.
Features
• Flexible machine integration through communications
• NV Media Card for parameter copying and data storage
• 24 Vdc backup supply (optional)
• EIA 485 serial communications interface (optional)
2.2

Model number

The way in which the model numbers for the Unidrive M range are formed is illustrated below:
Figure 2-1 Model number
Identification Label
Derivative
M200 -
Unidrive M200/201
Product Line
Frame Size :
Voltage Rating:
±
1 - 100 V (100 - 120 10 %)
± 10 %)
2 - 200 V (200 - 240
±
4 - 400 V (380 - 480 10 %)
± 10 %)
5 - 575 V (500 - 575
6 - 690 V (500 - 690 ± 10 %)
Current Rating:
Heavy Duty current rating x 10
Drive Format:
A - AC in AC out
E - AC in AC out (without internal choke)
Unidrive M200 / M201 Control User Guide
Issue Number: 2
Electrical Getting Basic
installation started parameters
Electrical Specifications
Reserved
03 4 00073 A
1
Running the NV Media
Optimization
motor
Documentation Customer Code
0 1 01
Onboard Advanced
Card PLC parameters
Optional Build
A B 1 0 0
Reserved:
Conformal Coating:
0 = Standard
IP / NEMA Rating:
1 = IP20 / NEMA 1
Brake Transistor:
B = Brake
N = No
Cooling:
A = Air
Customer Code:
00 = 50 Hz
01 = 60 Hz
Documentation:
0 - Supplied separately
1 - English
2 - French
3 - Italian
4 - German
5 - Spanish
