Nidec Unidrive M200 User Manual page 22

Safety Product Mechanical
information information installation
14 Digital Input 5
Terminal 14 default function
Type
Voltage range
Absolute maximum applied
voltage range
Impedance
Input threshold
Sample rate
41
Relay contacts
42
Default function
Contact voltage rating
Contact maximum current rating
Contact minimum recommended
rating
Contact type
Default contact condition
Update rate
To prevent the risk of a fire hazard in the event of a fault, a
fuse or other over-current protection must be installed in the
relay circuit.
WARNING
22
Electrical Getting Basic
installation started parameters
Analog INPUT 1 / INPUT 2 select
Positive logic only digital input. Frequency
input or motor thermistor input (bias for
DIN44081 ptc, KTY84, PT1000, PT2000
and other types) mode can be selected.
0 V to +24 V
-18 V to +30 V relative to 0 V
6.8 kΩ
10 V ±0.8 V (IEC 61131-2)
1 ms when routed to destinations Pr 06.035
or Pr 06.036, otherwise 4 ms.
Drive OK indicator
240 Vac, Installation over-voltage category II
2 A AC 240 V
4 A DC 30 V resistive load
0.5 A DC 30 V inductive load (L/R = 40 ms)
12 V 100 mA
Normally open
Closed when power applied and drive OK
1 ms
Running the NV Media
Optimization
motor Card
Onboard Advanced
Diagnostics
PLC parameters
Unidrive M200 / M201 Control User Guide
Issue Number: 2
UL Listing
