Getting started

This chapter introduces the user interfaces, menu structure and security
levels of the drive.
5.1

Understanding the display

5.1.1 Keypad
The keypad display consists of a 6 digit LED display. The display shows
the drive status or the menu and parameter number currently being
edited.
The option module Unidrive menu (S.mm.ppp) is only displayed if the
option module is installed. Where S signifies the option module slot
number and the mm.ppp signifies the menu and parameter number of
the option module's internal menus and parameter.
The display also includes LED indicators showing units and status as
shown in Figure 5-1. When the drive is powered up, the display will show
the power up parameter defined by Parameter Displayed At Power-Up
(11.022).
NOTE
The values in the Status Mode Parameters (Pr 22 and Pr 23) shown on
the display when the drive is running, can be toggled by using the
escape button.
Figure 5-1 Unidrive M200 keypad detail
7
8
9
1
2
3
1. Escape button
2. Down button
3. Start button (green)
4. Stop / Reset button (red)
5. Up button
6. Enter button
7. Run forward indicator
8. Run reverse indicator
9. Keypad reference indicator
10. Unit indicators
Unidrive M200 / M201 Control User Guide
Issue Number: 2
Electrical Getting Basic
installation started parameters
10
6
5
4
Running the NV Media
Optimization
motor Card
Figure 5-2 Unidrive M201 keypad detail
1
5
4
1. Run forward indicator
2. Unit indicators
3. Speed reference potentiometer
4. Keypad reference indicator
5. Run reverse indicator
NOTE
The red stop button
The parameter value is correctly displayed on the keypad display as
shown in Table 5-1.
On the Unidrive M201, the speed reference potentiometer is used to
adjust the keypad reference.
Table 5-1 Keypad display formats
Display formats
Standard
Date
Time
Character
Binary
IP Address
MAC Address
Version number
*Alternate display
5.2

Keypad operation

5.2.1 Control buttons
The keypad consists of:
• Up and down button - Used to navigate the parameter structure and
change parameter values.
• Enter button - Used to change between parameter edit and view
mode as well as entering data. This button can also be used to
select between slot menu and parameter display.
• Escape button - Used to exit from parameter edit or view mode. In
parameter edit mode, if parameter values are edited and the escape
button pressed, the parameter value will be restored to the value it
had on entry to edit mode.
• Start button - Used to provide a 'Run' command if keypad mode is
selected.
• Stop / Reset button - Used to reset the drive. In keypad mode can be
used for 'Stop'.
Onboard Advanced
Diagnostics
PLC parameters
2
V A Hz rpm %
1
is also used to reset the drive.
Value
100.99
31.12.11 or 12.31.11
12.34.56
ABCDEF
5
192.168 88.1*
01.02.03 04.05.06*
01.23.45
