Table 2-1 System Integration Option module identification
Type Option module
Fieldbus
Automation
(I/O expansion)
Table 2-2 Adaptor Interface (AI) option module identification
Type Option module
Communications
Backup
Table 2-3 Keypad identification
Type Keypad
Remote-Keypad
Keypad
Remote-Keypad RTC
14
Electrical Getting Basic
installation started parameters
Color Name
Purple SI-PROFIBUS
Medium
SI-DeviceNet
Grey
Light Grey SI-CANopen
Yellow
SI-PROFINET V2
Green
Beige SI-Ethernet
Brown Red SI-EtherCAT
Orange SI-I/O
Name
AI-485 adaptor
AI-485 24V adaptor
AI-Backup adaptor
AI-Smart adaptor
Name
Remote LCD keypad option
Remote Keypad with a LCD display
Remote LCD keypad option
Remote Keypad with a LCD display and real time clock
Running the NV Media
Optimization
motor Card
Profibus option
PROFIBUS adaptor for communications with the drive
DeviceNet option
DeviceNet adaptor for communications with the drive
CANopen option
CANopen adaptor for communications with the drive
PROFINET V2 option
PROFINET V2 adapter for communications with the drive
External Ethernet module that supports EtherNet/IP, Modbus
TCP/IP and RTMoE. The module can be used to provide global
connectivity and integration with IT network technologies, such as
wireless networking
EtherCAT option
EtherCAT adapter for communications with the drive
Extended I/O
Increases the I/O capability by adding the following combinations:
• Digital I/O
• Digital Inputs
• Analog Inputs (differential or single ended)
• Relays
EIA 485 serial communications option
Provides a EIA 485 serial communications interface via an RJ45
connector or alternative screw terminals.
EIA 485 serial communications option
Provides a EIA 485 serial communications interface via an RJ45
connector or alternative screw terminals. It also provides a 24 V
Backup supply input.
+24 V Backup and SD card interface
Provides a +24 V Backup supply input and SD card interface.
+24 V Backup and SD card interface
Supplied with 4 GB SD Card for parameter copying and an input
for 24 V Backup.
Further Details
Unidrive M200 / M201 Control User Guide
