Safety Product Mechanical
information information installation
Trip
PSU Internal power supply fault
The PSU trip indicates that one or more internal power supply rails are outside limits or overloaded.
Source
Control
system
Power
5
system
Recommended actions:
• Remove the option module and perform a reset
• There is a hardware fault within the drive – return the drive to the supplier
r.All RAM allocation error
The r.All trip indicates that an option module derivative image has requested more parameter RAM than is allowed. The
RAM allocation is checked in order of resulting sub-trip numbers, and so the failure with the highest sub-trip number is
given. The sub-trip is calculated as (parameter size) + (parameter type) + sub-array number.
227
Derivatives can customize menus 18 and 20.
Application menus
Derivative image
Option slot 1 set-up
Option slot 1 applications
r.b.ht Hot rectifier/brake
Over-temperature detected on input rectifier or braking IGBT.
250 Recommended action:
• Increase ventilation by setting Cooling Fan Control (06.045) > 0.
Reserved Reserved trips
These trip numbers are reserved trip numbers for future use.
01
09
12
01, 09, 12, 14-17, 23, 29, 38, 39 Reserved resettable trip
14 - 17
23, 29
38 - 39
91, 94 - 96
99
101 - 109
111
168 - 172
176 - 177
190 - 198
205 - 217
222 - 224
229 - 230, 233
238 - 244
249
251 - 254
Unidrive M200 / M201 Control User Guide
Issue Number: 2
Electrical Getting Basic
installation started parameters
xx y
00 0
01 1
Parameter size Value
1 bit 1
8 bit 2
16 bit 3
32 bit 4
64 bit 5
Sub-array
Trip Number
91, 94 -96, 99 Reserved resettable trip
101 - 109, 111 Reserved resettable trip
168 - 172, 176-177 Reserved resettable trip
190 – 198 Reserved resettable trip
205 - 217 Reserved resettable trip
222 - 224 Reserved non-resettable trip
229-230, 233 Reserved non-resettable trip
238 - 244, 249 Reserved non-resettable trip
251-254 Reserved non-resettable trip
Running the NV Media
Optimization
motor Card
Diagnosis
zz
00 Internal power supply overload.
Parameter type
Volatile
User save
Power-down save
Menus
18 & 20
29
15
25
Description
Onboard Advanced
Diagnostics
PLC parameters
Description
Value
0
1
2
Value
1
2
4
5
UL Listing
143
