Figure 38: Source ACLs

The following items are displayed on this page:
◆
◆
◆
◆
◆
The ACL Destination Address Settings page enables traffic filtering based
D
ESTINATION
on the destination MAC address in the data frame.
A S
DDRESS ETTINGS

Figure 39: Destination ACLs

SA Status — Enables network traffic with specific source MAC
addresses to be filtered (dropped) from the access point.
MAC Address — Specifies a source MAC address to filter, in the form
xx.xx.xx.xx.xx.xx, or xx-xx-xx-xx-xx-xx.
Action — Selecting "Add" adds a new MAC address to the filter list,
selecting delete removes the specified MAC address.
Number — Specifies the number associated with the MAC address.
MAC Address — Displays the configured source MAC address.
– 79 –
| Advanced Settings
C 7
HAPTER
Access Control Lists
