C P P
ONSOLE ORT IN
Reduce the number of connectors used in the link.
2.
Reconnect some of the connectors in the link.
3.
A
SSIGNMENTS
The RJ-45 console port on the front panel of the access point is used to
connect to the access point for out-of-band console configuration to a DB-9
connector on a PC. The command-line configuration program can be
accessed from a terminal, or a PC running a terminal emulation program.
The pin assignments and cable wiring used to connect to the console port
are provided in the following table.

Figure 63: DB-9 Connector

W M S
IRING AP FOR ERIAL
Table 34: 10/100BASE-TX MDI and MDI-X Port Pinouts
PIN
a
2 RXD
3 TXD
5 SGND
a. The left hand column pin assignments are for the male DB-9 connector on the access
point. Pin 3 (TXD or "transmit data") must emerge on the management console's end
of the connection as RXD ("receive data").
– 251 –
A
PPENDIX
1 5
6 9
C
ABLE
MDI Signal Name
<---------RXD ------------
-----------TXD ---------->
-----------SGND ----------
| Cables and Pinouts
C

Console Port Pin Assignments

MDI-X Signal Name
3 TxD
2 RxD
5 SGND
