Page 1: User Guide
USER GUIDE SMC2555W-AG2 EliteConnect Universal 802.11a/g 2.4GHz/5GHz Wireless Access Point...
Page 2 EliteConnect™ SMC2555W-AG2 Universal 2.4GHz/5GHz Wireless Dual-Band Access Point The easy way to make all your network connections October 2008 20 Mason Pub.# 149100033500E Irvine, CA 92618 E102008-AP-R03 Phone: (949) 679-8000...
Page 3 No license is granted by implication or otherwise under any patent or patent rights of SMC. SMC reserves the right to change specifications at any time without notice.
Page 4: Limited Warranty
“Active” SMC product. A product is considered to be “Active” while it is listed on the current SMC price list. As new technologies emerge, older technologies become obsolete and SMC will, at its discretion, replace an older product in its product line with one that incorporates these newer technologies.
Page 5 WHICH MAY VARY FROM STATE TO STATE. NOTHING IN THIS WARRANTY SHALL BE TAKEN TO AFFECT YOUR STATUTORY RIGHTS. * SMC will provide warranty service for one year following discontinuance from the active SMC price list. Under the limited lifetime warranty, internal and external power supplies, fans, and cables are covered by a standard one-year warranty from date of purchase.
Page 7: Federal Communication Commission Interference Statement
OMPLIANCES Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 8 OMPLIANCES High power radars are allocated as primary users (meaning they have priority) of the 5250-5350 MHz and 5650-5850 MHz bands. These radars could cause interference and /or damage to the access point when used in Canada. The term “IC” before the radio certification number only signifies that Industry Canada technical specifications were met.
Page 9: Ec Conformance Declaration
OMPLIANCES EC Conformance Declaration Marking by the above symbol indicates compliance with the Essential Requirements of the R&TTE Directive of the European Union (1999/5/ EC). This equipment meets the following conformance standards: • EN 60950-1 (IEC 60950-1) - Product Safety •...
Page 10 OMPLIANCES • The 5 GHz Turbo Mode feature is not allowed for operation in any European Community country. The current setting for this feature is found in the 5 GHz 802.11a Radio Settings Window as described in the user guide. •...
Page 11 OMPLIANCES Operation Using 5 GHz Channels in the European Community The user/installer must use the provided configuration utility to check the current channel of operation and make necessary configuration changes to ensure operation occurs in conformance with European National spectrum usage laws as described below and elsewhere in this document.
Page 12: Declaration Of Conformity In Languages Of The European Community
Festlegungen der Richtlinie 1999/5/EG. (Wien) Μ Ε Τ ΗΝ ΠΑΡΟ ΥΣΑ SMC ΔΗΛΩΝ Ε Ι Ο Τ Ι radio LAN device Greek ΣΥΜ Μ Ο ΡΦΩΝ Ε Τ ΑΙ ΠΡΟ Σ Τ ΙΣ Ο ΥΣΙΩΔΕ ΙΣ ΑΠΑΙΤ ΗΣΕ ΙΣ ΚΑΙ Τ ΙΣ ΛΟ ΙΠΕ Σ...
Page 13 OMPLIANCES Spanish Por medio de la presente Manufacturer declara que el Radio LAN device cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 1999/5/CE Portuguese Manufacturer declara que este Radio LAN device está conforme com os requisitos essenciais e outras disposições da Directiva 1999/5/CE.
Page 14 OMPLIANCES Important! Before making connections, make sure you have the correct cord set. Check it (read the label on the cable) against the following: Power Cord Set U.S.A. and The cord set must be UL-approved and CSA certified. Canada The minimum specifications for the flexible cord are: - No.
Page 15 OMPLIANCES Veuillez lire à fond l'information de la sécurité suivante avant d'installer le access point: AVERTISSEMENT: L’installation et la dépose de ce groupe doivent être confiés à un personnel qualifié. • Ne branchez pas votre appareil sur une prise secteur (alimentation électrique) lorsqu'il n'y a pas de connexion de mise à...
Page 16 OMPLIANCES Cordon électrique - Il doit être agréé dans le pays d’utilisation Suisse: La prise mâle d’alimentation doit respecter la norme SEV/ ASE 1011. Europe La prise secteur doit être conforme aux normes CEE 7/7 (“SCHUKO”) LE cordon secteur doit porter la mention <HAR> ou <BASEC>...
Page 17 OMPLIANCES Stromkabel. Dies muss von dem Land, in dem es benutzt wird geprüft werden: U.S.A und Der Cord muß das UL gepruft und war das CSA Kanada beglaubigt. Das Minimum spezifikation fur der Cord sind: - Nu. 18 AWG - nicht mehr als 2 meter, oder 16 AWG. - Der typ SV oder SJ - 3-Leiter Der Cord muß...
Page 18 OMPLIANCES...
Page 19: Table Of Contents
Table of Contents Chapter 1: Introduction Package Checklist Hardware Description Component Description Features and Benefits System Defaults Chapter 2: Hardware Installation Chapter 3: External Antennas Installation Procedures Chapter 4: Network Configuration Network Topologies Ad Hoc Wireless LAN (no Access Point) Infrastructure Wireless LAN Infrastructure Wireless LAN for Roaming Wireless PCs Infrastructure Wireless Bridge...
Page 20 Contents VLAN 6-20 WDS Settings 6-22 AP Management 6-28 Administration 6-29 System Log 6-34 SNMP 6-38 Configuring SNMP and Trap Message Parameters 6-39 Configuring SNMPv3 Users 6-44 Configuring SNMPv3 Trap Filters 6-46 Configuring SNMPv3 Targets 6-48 Radio Interface 6-50 Radio Settings A (802.11a) 6-51 Radio Settings G (802.11g) 6-66...
Page 21 Contents show history 7-10 show line 7-11 System Management Commands 7-11 country 7-12 prompt 7-14 system name 7-14 username 7-15 password 7-15 ip ssh-server enable 7-16 ip ssh-server port 7-16 ip telnet-server enable 7-17 ip http port 7-17 ip http server 7-18 ip https port 7-18...
Page 22 Contents snmp-server location 7-41 snmp-server enable server 7-41 snmp-server host 7-42 snmp-server trap 7-43 snmp-server engine-id 7-44 snmp-server user 7-45 snmp-server targets 7-47 snmp-server filter 7-48 snmp-server filter-assignments 7-49 show snmp groups 7-49 show snmp users 7-50 show snmp group-assignments 7-50 show snmp target 7-51...
Page 23 Contents mac-authentication server 7-71 mac-authentication session-timeout 7-71 Filtering Commands 7-72 filter local-bridge 7-73 filter ap-manage 7-73 filter uplink enable 7-74 filter uplink 7-74 filter ethernet-type enable 7-74 filter ethernet-type protocol 7-75 show filters 7-76 WDS Bridge Commands 7-76 bridge role (WDS) 7-77 bridge-link parent 7-77...
Page 24 Contents antenna control 7-99 antenna id 7-100 antenna location 7-101 beacon-interval 7-101 dtim-period 7-102 fragmentation-length 7-103 rts-threshold 7-103 super-a 7-104 super-g 7-105 description 7-105 ssid 7-106 closed-system 7-106 max-association 7-107 assoc-timeout-interval 7-107 auth-timeout-value 7-107 shutdown 7-108 show interface wireless 7-109 show station 7-111 Rogue AP Detection Commands...
Page 25 Contents vlan 7-131 management-vlanid 7-132 vlan-id 7-132 WMM Commands 7-133 7-134 wmm-acknowledge-policy 7-134 wmmparam 7-135 Appendix A: Troubleshooting Appendix B: Cables and Pinouts Twisted-Pair Cable Assignments 10/100BASE-TX Pin Assignments Straight-Through Wiring Crossover Wiring Console Port Pin Assignments Wiring Map for Serial Cable Appendix C: Specifications General Specifications Sensitivity...
Page 26 Contents...
Page 27: Chapter 1: Introduction
Chapter 1: Introduction The 2.4 GHz/5 GHz Wireless Access Point is an IEEE 802.11a/g access point that provides transparent, wireless high-speed data communications between the wired LAN and fixed or mobile devices equipped with an 802.11a, 802.11b, or 802.11g wireless adapter. This solution offers fast, reliable wireless connectivity with considerable cost savings over wired LANs (which include long-term maintenance overhead for cabling).
Page 28: Package Checklist
Introduction Package Checklist The 2.4 GHz/5 GHz Wireless Access Point package includes: • One 2.4 GHz/5 GHz Wireless Access Point • One Category 5 network cable • One RS-232 console cable • One AC power adapter and power cord • Four rubber feet •...
Page 29: Component Description
Hardware Description Rear Panel Lock DC 5V POE In Reset Console Console Reset 5 VDC RJ-45 Port, Security Slot Button Port Power Socket PoE Connector Component Description Antennas The access point includes integrated diversity antennas for wireless communications. A diversity antenna system uses two identical antennas to receive and transmit signals, helping to avoid multipath fading effects.
Page 30: Security Slot
Introduction Status Description Indicates that the system is working normally. Flashing Indicates running a self-test or loading the software program. Flashing (Prolonged) Indicates system errors. Link Indicates a valid 10/100 Mbps Ethernet cable link. Flashing Indicates that the access point is transmitting or receiving data on a 10/100 Mbps Ethernet LAN.
Page 31: Features And Benefits
Features and Benefits Note: The RJ-45 port also supports Power over Ethernet (PoE) based on the IEEE 802.3af standard. Refer to the description for the “Power Connector” for information on supplying power to the access point’s network port from a network device, such as a switch, that provides Power over Ethernet (PoE).
Page 32: System Defaults
Introduction System Defaults The following table lists some of the access point’s basic system defaults. To reset the access point defaults, use the CLI command “reset configuration” from the Exec level prompt. Table 1-1. System Defaults Feature Parameter Default Identification System Name Administration User Name...
Page 33 System Defaults Table 1-1. System Defaults Feature Parameter Default MAC Authentication Disabled Authentication Session Timeout 0 minutes (disabled) Local MAC System Default Allowed Local MAC Permission Allowed 802.1X Authentication Status Disabled Broadcast Key Refresh 0 minutes (disabled) Session Key Refresh 0 minutes (disabled) Reauthentication Refresh Rate 0 seconds (disabled)
Page 34 Introduction Table 1-1. System Defaults Feature Parameter Default System Logging Syslog Disabled Logging Host Disabled Logging Console Disabled IP Address / Host Name 0.0.0.0 Logging Level Informational Logging Facility Type System Clock SNTP Server Status Enabled SNTP Server 1 IP 137.92.140.80 SNTP Server 2 IP 192.43.244.18...
Page 35 System Defaults Table 1-1. System Defaults Feature Parameter Default Wireless Interface IAPP Enabled 802.11a SSID Turbo Mode Disabled Status Disabled Auto Channel Select Enabled Closed System Disabled Transmit Power Full Max Station Data Rate 54 Mbps Multicast Data Rate 6 Mbps Beacon Interval 100 TUs Data Beacon Rate (DTIM Interval) 1 beacon...
Page 36 Introduction Table 1-1. System Defaults Feature Parameter Default Wireless Interface IAPP Enabled 802.11b/g SSID Radio Mode Status Disabled Auto Channel Select Enabled Closed System Disabled Transmit Power Full Max Station Data Rate 54 Mbps Multicast Data Rate 5.5 Mbps Preamble Length Long Beacon Interval 100 TUs...
Page 37 System Defaults Table 1-1. System Defaults Feature Parameter Default Link Integrity Status Disabled Ping Interval 30 seconds Fail Retry Count 1-11...
Page 38 Introduction 1-12...
Page 39: Chapter 2: Hardware Installation
Chapter 2: Hardware Installation Select a Site – Choose a proper place for the access point. In general, the best location is at the center of your wireless coverage area, within line of sight of all wireless devices. Try to place the access point in a position that can best cover its Basic Service Set (refer to “Infrastructure Wireless LAN”...
Page 40 Connect the Console Port – Connect the console cable (included) to the RS-232 console port for accessing the command-line interface. You can manage the access point using the console port (Chapter 6), the web interface (Chapter 5), or SNMP management software such as SMC’s EliteView.
Page 41: Chapter 3: External Antennas
Chapter 3: External Antennas The SMC2555W-AG2 provides a variety of external antenna options for extending the radio range and shaping the coverge area. These antennas offer a number of different mounting locations, including indoor or outdoor, wall, ceiling, or radio mast. This chapter shows you how to install an external antenna for your SMC2555W-AG2.
Page 42 External Antennas • Consider the antenna’s radio coverage pattern so that it can properly cover the intended service area. • Omnidirectional Antennas - Consider these factors when selecting a location for these antennas: • Always mount the antenna in a vertical orientation so that the radio coverage pattern fills the intended horizontal space.
Page 43 Installation Procedures Other non-diversity antennas, can be connected to either antenna connector and then configured for usage using the antenna options in the user interface. To connect pigtail cables to the access point, follow these steps: Disable the access point radio using the web browser interface, CLI, or SNMP. Remove power to the access point.
Page 44 External Antennas Antenna pigtail cable Screw onto access point’s Reconnect power to the access point. Note: Before enabling the radio with an external antenna attached, be sure to first configure the access point’s antenna mode.
Page 45: Chapter 4: Network Configuration
Chapter 4: Network Configuration Wireless networks support a stand-alone configuration as well as an integrated configuration with 10/100 Mbps Ethernet LANs. The 2.4 GHz/5 GHz Wireless Access Point also provides repeater and bridging services that can be configured independently on either the 5 GHz or 2.4 GHz radio interfaces. Access points can be deployed to support wireless clients and connect wired LANs in the following configurations: •...
Page 46: Network Topologies
Network Configuration Network Topologies Ad Hoc Wireless LAN (no Access Point) An ad hoc wireless LAN consists of a group of computers, each equipped with a wireless adapter, connected via radio signals as an independent wireless LAN. Computers in a specific ad hoc wireless LAN must therefore be configured to the same radio channel.
Page 47: Infrastructure Wireless Lan
Network Topologies Infrastructure Wireless LAN The access point also provides access to a wired LAN for wireless workstations. An integrated wired/wireless LAN is called an Infrastructure configuration. A Basic Service Set (BSS) consists of a group of wireless PC users, and an access point that is directly connected to the wired LAN.
Page 48: Infrastructure Wireless Lan For Roaming Wireless Pcs
Network Configuration Infrastructure Wireless LAN for Roaming Wireless PCs The Basic Service Set (BSS) defines the communications domain for each access point and its associated wireless clients. The BSS ID is a 48-bit binary number based on the access point’s wireless MAC address, and is set automatically and transparently as clients associate with the access point.
Page 49: Infrastructure Wireless Bridge
Network Topologies Infrastructure Wireless Bridge The IEEE 802.11 standard defines a WIreless Distribution System (WDS) for bridge connections between BSS areas (access points). The access point uses WDS to forward traffic on links between units. The access point supports WDS bridge links on either the 5 GHz (802.11a) or 2.4 GHz (802.11b/g) bands and can be used with various external antennas to offer flexible deployment options.
Page 50: Infrastructure Wireless Repeater
Network Configuration Infrastructure Wireless Repeater The access point can also operate in a bridge “repeater” mode to extend the range of links to wireless clients. The access point uses WDS to forward traffic between the repeater bridge and the root bridge. The access point supports up to six WDS repeater links.
Page 51: Chapter 5: Initial Configuration
Chapter 5: Initial Configuration The 2.4 GHz/5 GHz Wireless Access Point offers a variety of management options, including a web-based interface, a direct connection to the console port, Telnet, Secure Shell (SSH), or using SNMP software. The initial configuration steps can be made through the web browser interface or CLI.
Page 52: Initial Configuration Steps
Initial Configuration ® ® Note: When using HyperTerminal with Microsoft Windows 2000, make sure that you have Windows 2000 Service Pack 2 or later installed. Windows 2000 Service Pack 2 fixes the problem of arrow keys not functioning in HyperTerminal’s VT100 emulation.
Page 53: Logging In
Logging In After configuring the access point’s IP parameters, you can access the management interface from anywhere within the attached network. The command line interface can also be accessed using Telnet from any computer attached to the network. Setting the Country Code – Units sold in the United States are configured by default to use only radio channels 1-11 in 802.11b or 802.11g mode as defined by FCC regulations.
Page 54 Initial Configuration The home page displays the Main Menu.
Page 55: Chapter 6: System Configuration
Chapter 6: System Configuration Before continuing with advanced configuration, first complete the initial configuration steps described in Chapter 4 to set up an IP address for the access point. The access point can be managed by any computer using a web browser (Internet Explorer 5.0 or above, or Netscape Navigator 6.2 or above).
Page 56: Advanced Configuration
System Configuration Advanced Configuration The Advanced Configuration pages include the following options. Table 6-2. Menu Menu Description Page System Configures basic administrative and client access Identification Specifies the host name TCP / IP Settings Configures the IP address, subnet mask, gateway, and domain name servers RADIUS Configures the RADIUS server for wireless client authentication...
Page 57: System Identification
The system name for the access point can be left at its default setting. However, modifying this parameter can help you to more easily distinguish different devices in your network. System Name – An alias for the access point, enabling the device to be uniquely identified on the network. (Default: SMC; Range: 1-32 characters)
Page 58 System Configuration CLI Commands for System Identification – Enter the global configuration mode, and use the system name command to specify a new system name. Then return to the Exec mode, and use the show system command to display the changes to the system identification settings.
Page 59: Tcp / Ip Settings
Advanced Configuration TCP / IP Settings Configuring the access point with an IP address expands your ability to manage the access point. A number of access point features depend on IP addressing to operate. Note: You can use the web browser interface to access IP addressing only if the access point already has an IP address that is reachable through your network.
Page 60 System Configuration • Subnet Mask: The mask that identifies the host address bits used for routing to specific subnets. • Default Gateway: The default gateway is the IP address of the router for the access point, which is used if the requested destination address is not on the local subnet. If you have management stations, DNS, RADIUS, or other network servers located on another subnet, type the IP address of the default gateway router in the text field provided.
Page 61: Radius
Advanced Configuration RADIUS Remote Authentication Dial-in User Service (RADIUS) is an authentication protocol that uses software running on a central server to control access to RADIUS-aware devices on the network. An authentication server contains a database of user credentials for each user that requires access to the network. A primary RADIUS server must be specified for the access point to implement IEEE 802.1X network access control and Wi-Fi Protected Access (WPA) wireless security.
Page 62 System Configuration...
Page 63 Advanced Configuration MAC Address Format – MAC addresses can be specified in one of four formats, using no delimeter, with a single dash delimeter, with multiple dash delimeters, and with multiple colon delimeters. VLAN ID Format – A VLAN ID (a number between 1 and 4094) can be assigned to each client after successful authentication using IEEE 802.1X and a central RADIUS server.
Page 64 System Configuration CLI Commands for RADIUS – From the global configuration mode, use the radius-server address command to specify the address of the primary or secondary RADIUS servers. (The following example configures the settings for the primary RADIUS server.) Configure the other parameters for the RADIUS server. Then use the show show radius command from the Exec mode to display the current settings for the primary and secondary RADIUS servers.
Page 65: Ssh Settings
Advanced Configuration SSH Settings Telnet is a remote management tool that can be used to configure the access point from anywhere in the network. However, Telnet is not secure from hostile attacks. The Secure Shell (SSH) can act as a secure replacement for Telnet. The SSH protocol uses generated public keys to encrypt all data transfers passing between the access point and SSH-enabled management station clients and ensures that data traveling over the network arrives unaltered.
Page 66: Authentication
System Configuration CLI Commands for SSH – To enable the SSH server, use the ip ssh-server enable command from the CLI Ethernet interface configuration mode. To set the SSH server UDP port, use the ip ssh-server port command. To view the current settings, use the show system command from the CLI Exec mode (not shown in the following example).
Page 67 Advanced Configuration MAC Authentication – You can configure a list of the MAC addresses for wireless clients that are authorized to access the network. This provides a basic level of authentication for wireless clients attempting to gain access to the network. A database of authorized MAC addresses can be stored locally on the access point or remotely on a central RADIUS server.
Page 68 System Configuration 802.1X Supplicant – The access point can also operate in a 802.1X supplicant mode. This enables the access point itself to be authenticated with a RADIUS server using a configured MD5 user name and password. This prevents rogue access points from gaining access to the network.
Page 69 Advanced Configuration CLI Commands for Local MAC Authentication – Use the mac-authentication server command from the global configuration mode to enable local MAC authentication. Use the mac-authentication session-timeout command to set the authentication interval. Set the default action for MAC addresses not in the local table using the address filter default command, then enter MAC addresses in the local table using the address filter entry command.
Page 70 System Configuration CLI Commands for RADIUS MAC Authentication – Use the mac-authentication server command from the global configuration mode to enable remote MAC authentication. Set the timeout value for re-authentication using the mac- authentication session-timeout command. Be sure to also configure connection settings for the RADIUS server (not shown in the following example).
Page 71: Filter Control
Advanced Configuration Filter Control The access point can employ network traffic frame filtering to control access to network resources and increase security. You can prevent communications between wireless clients and prevent access point management from wireless clients. Also, you can block specific Ethernet traffic from being forwarded by the access point. Inter Client STAs Communication Filter –...
Page 72 System Configuration • Prevent Inter and Intra VAP client communication: When enabled, clients cannot establish wireless communications with any other client, either those associated to the same VAP interface or any other VAP interface. AP Management Filter – Controls management access to the access point from wireless clients.
Page 73 Advanced Configuration protocol command to define the protocols that you want to filter. To remove an entry from the table, use the address filter delete command. To display the current settings, use the show filters command from the Exec mode. 7-73 Enterprise AP(config)#filter local-bridge 7-73...
Page 74: Vlan
System Configuration VLAN The access point can employ VLAN tagging support to control access to network resources and increase security. VLANs separate traffic passing between the access point, associated clients, and the wired network. There can be a VLAN assigned to each associated client, a default VLAN for each VAP (Virtual Access Point) interface, and a management VLAN for the access point.
Page 75 Advanced Configuration When setting up VLAN IDs for each user on the RADIUS server, be sure to use the RADIUS attributes and values as indicated in the following table. Number RADIUS Attribute Value Tunnel-Type VLAN (13) Tunnel-Medium-Type Tunnel-Private-Group-ID VLANID (1 to 4094 as hexadecimal or string) VLAN IDs on the RADIUS server can be entered as hexadecimal digits or a string (see “radius-server vlan-format”...
Page 76: Wds Settings
System Configuration WDS Settings Each access point radio interface can be configured to operate in a bridge or repeater mode, which allows it to forward traffic directly to other access point units. To set up bridge links between access point units, you must configure the wireless Distribution System (WDS) forwarding table by specifying the wireless MAC address of all units to which you want to forward traffic.
Page 77 Advanced Configuration • Bridge: Operates as a bridge to other access points. The “Parent” link to the root bridge must be configured. Up to five other ”Child” links are available to other bridges. • Repeater: Operates as a wireless repeater, extending the range for remote wireless clients and connecting them to the root bridge.
Page 78 System Configuration Spanning Tree Protocol – STP uses a distributed algorithm to select a bridging device (STP-compliant switch, bridge or router) that serves as the root of the spanning tree network. It selects a root port on each bridging device (except for the root device) which incurs the lowest path cost when forwarding a packet from that device to the root device.
Page 79 Advanced Configuration designated ports. After determining the lowest cost spanning tree, it enables all root ports and designated ports, and disables all other ports. Network packets are therefore only forwarded between root ports and designated ports, eliminating any possible network loops. Once a stable network topology has been established, all bridges listen for Hello BPDUs (Bridge Protocol Data Units) transmitted from the root bridge.
Page 80 System Configuration • Link Path Cost – This parameter is used by the STP to determine the best path between devices. Therefore, lower values should be assigned to ports attached to faster media, and higher values assigned to ports with slower media. (Path cost takes precedence over port priority.) •...
Page 81 Advanced Configuration CLI Commands for STP Settings – If the role of a radio interface is set to Repeater, Bridge or Root Bridge, STP can be enabled on the access point to maintain a valid network topology. To globally enable STP, use the bridge stp enable command from the CLI configuration mode.
Page 82: Ap Management
System Configuration AP Management The Web, Telnet, and SNMP management interfaces are enabled and open to all IP addresses by default. To provide more security for management access to the access point, specific interfaces can be disabled and management restricted to a single IP address or a limited range of IP addresses.
Page 83: Administration
Advanced Configuration CLI Commands for AP Management features. 7-20 Enterprise AP(config)#apmgmtip multiple 192.168.1.50 255.255.255.0 Enterprise AP(config)#apmgmtui SNMP enable 7-21 Administration Changing the Password Management access to the web and CLI interface on the access point is controlled through a single user name and password. You can also gain additional access security by using control filters (see “Filter Control”...
Page 84: Upgrading Firmware
System Configuration Setting the Timeout Interval You can set the timeout interval for web access to the unit, after which the user will have to re-enter the username and password. Session Timeout for WEB – Sets the time limit for an idle web interface session. (Range: 0-1800 seconds;...
Page 85 Advanced Configuration Before upgrading new software, verify that the access point is connected to the network and has been configured with a compatible IP address and subnet mask. If you need to download from an FTP or TFTP server, take the following additional steps: •...
Page 86 System Configuration Firmware Upgrade Local – Downloads an operation code image file from the web management station to the access point using HTTP. Use the Browse button to locate the image file locally on the management station and click Start Upgrade to proceed.
Page 87 Advanced Configuration Upon uploading a new configuration file you will be prompted to either restore factory settings, or reboot the unit. CLI Commands for Downloading Software from a TFTP Server – Use the copy tftp file command from the Exec mode and then specify the file type, name, and IP address of the TFTP server.
Page 88: System Log
System Configuration System Log The access point can be configured to send event and error messages to a System Log Server. The system clock can also be synchronized with a time server, so that all the messages sent to the Syslog server are stamped with the correct time and date.
Page 89 Advanced Configuration Logging Level – Sets the minimum severity level for event logging. (Default: Informational) The system allows you to limit the messages that are logged by specifying a minimum severity level. The following table lists the error message levels from the most severe (Emergency) to least severe (Debug).
Page 90: Configuring Sntp
System Configuration CLI Commands for System Logging – To enable logging on the access point, use the logging on command from the global configuration mode. The logging level command sets the minimum level of message to log. Use the logging console command to enable logging to the console.
Page 91 Advanced Configuration Note: The access point also allows you to disable SNTP and set the system clock manually. Set Time Zone – SNTP uses Coordinated Universal Time (or UTC, formerly Greenwich Mean Time, or GMT) based on the time at the Earth’s prime meridian, zero degrees longitude.
Page 92: Snmp
System Configuration CLI Commands for the System Clock – The following example shows how to manually set the system time when SNTP server support is disabled on the access point. 7-33 Enterprise AP(config)#no sntp-server enable 7-34 Enterprise AP(config)#sntp-server date-time Enter Year<1970-2100>: 2003 Enter Month<1-12>: 10 Enter Day<1-31>: 10 Enter Hour<0-23>: 18...
Page 93: Configuring Snmp And Trap Message Parameters
SNMP Configuring SNMP and Trap Message Parameters The access point SNMP agent must be enabled to function (for versions 1, 2c, and 3 clients). Management access using SNMP v1 and v2c also requires community strings to be configured for authentication. Trap notifications can be enabled and sent to up to four management stations.
Page 94 System Configuration Community Name (Read/Write) – Defines the SNMP community access string that has read/write access. Authorized management stations are able to both retrieve and modify MIB objects. (Maximum length: 23 characters, case sensitive; Default: private) Trap Destination (1 to 4) – Enables recipients (up to four) of SNMP notifications. •...
Page 95 SNMP Trap Configuration – Allows selection of specific SNMP notifications to send. The following items are available: • sysSystemUp - The access point is up and running. • sysSystemDown - The access point is about to shutdown and reboot. • sysRadiusServerChanged - The access point has changed from the primary RADIUS server to the secondary, or from the secondary to the primary.
Page 96 System Configuration • dot11StationDisassociate - A client station no longer associates with the network. • dot11StationAuthenticateFail - A client station has tried and failed to authenticate to the network. • Enable All Traps - Click the button to enable all the available traps. •...
Page 97 SNMP To view the current SNMP settings, use the show snmp command. 7-53 Enterprise AP#show snmp SNMP Information ============================================== Service State : Enable Community (ro) : ***** Community (rw) : ***** Location : WC-19 Contact : Paul EngineId :80:00:07:e5:80:00:00:2e:62:00:00:00:18 EngineBoots:1 Trap Destinations: 192.168.1.9, Community: *****, State: Enabled 0.0.0.0, Community: *****, State: Disabled...
Page 98: Configuring Snmpv3 Users
System Configuration Configuring SNMPv3 Users The access point allows up to 10 SNMP v3 users to be configured. Each user must be defined by a unique name, assigned to one of three pre-defined security groups, and configured with specific authentication and encryption settings. User –...
Page 99 SNMP CLI Commands for Configuring SNMPv3 Users – Use the snmp-server engine-id command to define the SNMP v3 engine before assigning users to groups. Use the snmp-server user command to assign users to one of the three groups and set the appropriate authentication and encryption types to be used.
Page 100: Configuring Snmpv3 Trap Filters
System Configuration Configuring SNMPv3 Trap Filters SNMP v3 users can be configured to receive notification messages from the access point. An SNMP Target ID is created that specifies the SNMP v3 user, IP address, and UDP port. A user-defined notification filter can be created so that specific notifications can be prevented from being sent to particular targets.
Page 101 SNMP Note: Only the New Filter page allows the Filter ID to be configured. Filter ID – A user-defined name that identifies the filter. (Maximum length: 32 characters) Subtree OID – Specifies MIB subtree to be filtered. The MIB subtree must be defined in the form “.1.3.6.1”...
Page 102: Configuring Snmpv3 Targets
System Configuration Configuring SNMPv3 Targets An SNMP v3 notification Target ID is specified by the SNMP v3 user, IP address, and UDP port. A user-defined filter can also be assigned to specific targets to limit the notifications received to specific MIB objects. (Note that the filter must first be configured.
Page 103 SNMP Target ID – A user-defined name that identifies a receiver of notifications. The access point supports up to 10 target IDs. (Maximum length: 32 characters) IP Address – Specifies the IP address of the receiving management station. UDP Port – The UDP port that is used on the receiving management station for notification messages.
Page 104: Radio Interface
System Configuration Enterprise AP(config)#snmp-server targets mytraps 7-47 192.168.1.33 chris Enterprise AP(config)#snmp-server filter-assignment 7-49 mytraps trapfilter Enterprise AP(config)#exit 7-51 Enterprise AP#show snmp target Host ID : mytraps User : chris IP Address : 192.168.1.33 UDP Port : 162 ============================= 7-52 Enterprise AP#show snmp filter-assignments HostID FilterID mytraps...
Page 105: Radio Settings A (802.11A)
Radio Interface Radio Settings A (802.11a) The IEEE 802.11a interface operates within the 5 GHz band, at up to 54 Mbps in normal mode or up to 108 Mbps in Turbo mode. First configure the radio settings that apply to the individual VAPs (Virtual Access Point) and the common radio settings that apply to the overall system.
Page 106 System Configuration Default VLAN ID – The VLAN ID assigned to wireless clients associated to the VAP interface that are not assigned to a specific VLAN by RADIUS server configuration. (Default: 1) Closed System – When enabled, the VAP interface does not include its SSID in beacon messages.
Page 107 Radio Interface CLI Commands for the Configuring the VAPs – From the global configuration mode, enter the interface wireless a command to access the 802.11a radio interface. From the 802.11a interface mode, you can access radio settings that apply to all VAP interfaces.
Page 108 System Configuration The access point can be configured to periodically scan all radio channels and find other access points within range. A database of nearby access points is maintained where any rogue APs can be identified. During a scan, Syslog messages (see “Enabling System Logging”...
Page 109 Radio Interface using the rogue-ap scan command. To view the database of detected access points, use the show rogue-ap command from the Exec level. 7-87 Enterprise AP(config)#interface wireless g Enter Wireless configuration commands, one per line. 7-112 Enterprise AP(if-wireless g)#rogue-ap enable configure either syslog or trap or both to receive the rogue APs detected.
Page 110 System Configuration Configuring Common Radio Settings To configure common radio settings, select the Radio Settings page, and scroll down to below the VAP radio settings. Turbo Mode – The normal 802.11a wireless operation mode provides connections up to 54 Mbps. Turbo Mode is an enhanced mode (not regulated in IEEE 802.11a) that provides a higher data rate of up to 108 Mbps.
Page 111 Radio Interface Radio Channel – The radio channel that the access point uses Normal Mode to communicate with wireless clients. When multiple access points are deployed in the same area, set the channel on neighboring access points at least four channels apart to avoid interference with each other.
Page 112 System Configuration Antenna Control Method - Selects the use of both fixed antennas operating in diversity mode or a single antenna. (Default: Diversity) • Diversity: The radio uses both antennas in a diversity system. Select this method when the Antenna ID is set to "Default Antenna" to use the access point's integrated antennas.
Page 113 Radio Interface Power Save mode to wake up more often and drain power faster. Using higher DTIM values reduces the power used by stations in Power Save mode, but delays the transmission of broadcast/multicast frames. (Range: 1-255 beacons; Default: 1 beacon) Multicast Data Rate –...
Page 114 System Configuration CLI Commands for the Common Radio Settings – From the global configuration mode, enter the interface wireless a command to access the 802.11a radio interface. From the 802.11a interface mode, you can access radio settings that apply to all VAP interfaces. Use the turbo command to enable this feature before setting the radio channel with the channel command.
Page 115 Radio Interface types of traffic, WMM allows the priority levels to be configured to match any network-wide QoS policy. WMM also specifies a protocol that access points can use to communicate the configured traffic priority levels to QoS-enabled wireless clients. Table 6-1.
Page 116 System Configuration CWMin CWMax riority AIFS Random Backoff Minimum Wait Time Random Wait Time CWMin riority Random Backoff AIFS Minimum Wait Time Random Wait Time Figure 6-1. WMM Backoff Wait Times For high-priority traffic, the AIFSN and CW values are smaller. The smaller values equate to less backoff and wait time, and therefore more transmit opportunities.
Page 117 Radio Interface WMM – Sets the WMM operational mode on the access point. When enabled, the parameters for each AC queue will be employed on the access point and QoS capabilities are advertised to WMM-enabled clients. (Default: Support) • Disable: WMM is disabled. •...
Page 118 System Configuration CLI Commands for WMM – Enter interface wireless mode and type wmm required for clients that want to associate with the access point. The wmm-acknowledge-policy command is used to enable or disable a policy for each access category. The wmmparms command defines detailed WMM parameters. Enterprise AP(if-wireless a)#wmm required 7-134 Enterprise AP(if-wireless a)#wmm-acknowledge-policy 0 noack...
Page 119 To view the current 802.11a radio settings for the VAP interface, use the show interface wireless a 0 command. 7-109 Enterprise AP#show interface wireless a 0 Wireless Interface Information ============================================================= --------------------Identification--------------------------- Description : SMC 802.11g Access Point SSID : SMC_A 0 Turbo Mode : DISABLED Channel : 36 (AUTO) Status...
Page 120: Radio Settings G (802.11G)
System Configuration ----------------Quality of Service--------------------------- WMM Mode : SUPPORTED WMM Acknowledge Policy AC0(Best Effort) : Ack AC1(Background) : Acknowledge AC2(Video) : Acknowledge AC3(Voice) : Acknowledge WMM BSS Parameters AC0(Best Effort) : logCwMin: logCwMax: 10 AIFSN: Admission Control: No TXOP Limit: 0.000 ms AC1(Background) : logCwMin: logCwMax: 10...
Page 121 Radio Interface Most of the 802.11g commands are identical to those used by the 802.11a interface. For information on the these commands, refer to the following sections: • “Configuring VAP Radio Settings” on page 6-51 • “Configuring Rogue AP Detection” on page 6-53 •...
Page 122 System Configuration Radio Channel – The radio channel that the access point uses to communicate with wireless clients. When multiple access points are deployed in the same area, set the channel on neighboring access points at least five channels apart to avoid interference with each other.
Page 123: Security
Radio Interface CLI Commands for the 802.11g Wireless Interface – From the global configuration mode, enter the interface wireless g command to access the 802.11g radio interface. The 802.11g radio can be forced to an 802.11g-only, 802.11b-only, or mixed 802.11b/g operating mode using the radio-mode command. You should set the desired operating mode before configuring channel settings (the default is mixed 802.11b/g operation).
Page 124 System Configuration A summary of wireless security considerations is listed in the following table. Table 6-2. Wireless Security Considerations Security Client Support Implementation Considerations Mechanism Built-in support on all 802.11a • Provides only weak security and 802.11g devices • Requires manual key management WEP over 802.1X Requires 802.1X client support •...
Page 125 Radio Interface The access point can simultaneously support clients using various different security mechanisms. The configuration for these security combinations are outlined in the following table. Note that MAC address authentication can be configured independently to work with all security mechanisms and is indicated separately in the table.
Page 126 System Configuration Table 6-3. Security Combinations Client Security RADIUS Configuration Summary Combination Server Authentication Dynamic WEP and Interface Detail Settings: Local or Disabled Yes 802.1x WPA Authentication: WPA Encryption: Enable WPA Configuration: Supported Cipher Suite: WEP 802.1x: Required Set 802.1x key refresh and reauthentication rates Static and dynamic Enter 1 to 4 WEP keys Local or Disabled Yes...
Page 127 Radio Interface a. The configuration summary does not include the set up for MAC authentication (see page 4-15) or RADIUS server (see page 2-9). b. The configuration of RADIUS MAC authentication together with 802.1x WPA or WPA Pre-shared Key is not supported. c.
Page 128 System Configuration Enable – Enables radio communications on the VAP interface. (Default: Disabled) Note: You must first enable VAP interface 0 before you can enable other VAP interfaces. SSID – The name of the basic service set provided by a VAP interface. Clients that want to connect to the network through the access point must set their SSID to the same as that of an access point VAP interface.
Page 129 Radio Interface • Alphanumeric: Enter keys as 5 alphanumeric characters for 64 bit keys, 13 alphanumeric characters for 128 bit keys, or 16 alphanumeric characters for 152 bit keys (802.11a radio only). Key Number – Selects the key number to use for encryption for each VAP interface. If the clients have all four keys configured to the same values, you can change the encryption key to any of the eight settings without having to update the client keys.
Page 130 System Configuration Note: To use 802.1X on wireless clients requires a network card driver and 802.1X client software that supports the EAP authentication type that you want to use. Windows 2000 SP3 or later and Windows XP provide 802.1X client support. Windows XP also provides native WPA support.
Page 131 Enterprise AP(if-wireless g: VAP[0])#transmit-key 1 Enterprise AP(if-wireless g: VAP[0])#exit 7-109 Enterprise AP#show interface wireless g 0 Wireless Interface Information ======================================================================== ----------------Identification------------------------------------------ Description : SMC 802.11g Access Point SSID : SMC_G 0 Channel : 11 (AUTO) Status : DISABLED MAC Address : 00:12:cf:05:95:08 ----------------802.11 Parameters----------------------------------------...
Page 132 System Configuration ----------------Antenna------------------------------------------------- Antenna Control method : Diversity Antenna ID : 0x0000(Default Antenna) Antenna Location : Indoor ----------------Quality of Service--------------------------------------- WMM Mode : SUPPORTED WMM Acknowledge Policy AC0(Best Effort) : Acknowledge AC1(Background) : Acknowledge AC2(Video) : Acknowledge AC3(Voice) : Acknowledge WMM BSS Parameters AC0(Best Effort) : logCwMin:...
Page 133 Radio Interface to enable data encryption. To view the current security settings, use the show interface wireless a 0 or show interface wireless g 0 command (not shown in example). Enterprise AP(if-wireless g)#vap 0 7-64 Enterprise AP(if-wireless g: VAP[0])#802.1X required Enterprise AP(if-wireless g: VAP[0])#802.1X 7-65 broadcast-key-refresh-rate 5...
Page 134 System Configuration the access point and all wireless clients. The PSK mode uses the same TKIP packet encryption and key management as WPA in the enterprise, providing a robust and manageable alternative for small networks. Mixed WPA and WEP Client Support: WPA enables the access point to indicate its supported encryption and authentication mechanisms to clients using its beacon signal.
Page 135 Radio Interface information form a Security Association that the access point names and holds in a cache. • Preauthentication: Each time a client roams to another access point it has to be fully re-authenticated. This authentication process is time consuming and can disrupt applications running over the network.
Page 136 System Configuration The WPA configuration parameters are described below: Encryption – You must enable data encryption in order to enable all types of encryption (WEP, TKIP, or AES) in the access point. Pre-Authentication – When using WPA2 over 802.1X, pre-authentication can be enabled, which allows clients to roam to a new access point and be quickly associated without performing full 802.1X authentication.
Page 137 Radio Interface The configuration settings for WPA are summarized below: Table 6-4. WPA Configuration Settings WPA and WPA2 pre-shared key only WPA and WPA2 over 802.1X Encryption: Enabled Encryption: Enabled Authentication Setup: WPA-PSK, WPA2-PSK, or Authentication Setup: WPA, WPA2, WPA-WPA2-mixed WPA-WPA2-mixed Cipher Suite: WEP/TKIP/AES-CCMP Cipher Suite: WEP/TKIP/AES-CCMP...
Page 138 System Configuration CLI Commands for WPA Over 802.1X Security – From the VAP interface configuration mode, use the auth wpa required command to select WPA over 802.1X security. Then set the 802.1X key refresh rates. To view the current security settings, use the show interface wireless a 0 or show interface wireless g 0 command (not shown in example).
Page 139 Radio Interface Open the Security page, and click More for one of the VAP interfaces. You can enable 802.1X as optionally supported or as required to enhance the security of the wireless network. (Default: Disable) • Disable: The access point does not support 802.1X authentication for any wireless client.
Page 140: Status Information
System Configuration • 802.1X Reauthentication Refresh Rate: The time period after which a connected client must be re-authenticated. During the re-authentication process of verifying the client’s credentials on the RADIUS server, the client remains connected the network. Only if re-authentication fails is network access blocked. (Range: 0-65535 seconds;...
Page 141 Status Information AP System Configuration – The AP System Configuration table displays the basic system configuration settings: • System Up Time: Length of time the management agent has been up. • Ethernet MAC: The physical layer address for the Ethernet port. •...
Page 142 System Information ========================================================== Serial Number : A123456789 System Up time : 0 days, 4 hours, 33 minutes, 29 seconds System Name : SMC System Location System Contact System Country Code : US - UNITED STATES MAC Address : 00-30-F1-F0-9A-9C IP Address : 192.168.1.1...
Page 143: Access Point Status
Status Information Station Status The Station Status window shows the wireless clients currently associated with the access point. The Station Configuration page displays basic connection information for all associated stations as described below. Note that this page is automatically refreshed every five seconds. •...
Page 144 System Configuration shared-key approach uses Wired Equivalent Privacy (WEP) to verify client identity by distributing a shared key to stations before attempting authentication. • Associated: Shows if the station has been successfully associated with the access point. Once authentication is completed, stations can associate with the current access point, or reassociate with a new access point.
Page 145 Status Information CLI Commands for Displaying Station Status – To view status of clients currently associated with the access point, use the show station command from the Exec mode. 7-111 Enterprise AP#show station Station Table Information =========================================================== if-wireless A VAP [0] 802.11a Channel : Auto No 802.11a Channel Stations.
Page 146: Event Logs
System Configuration Event Logs The Event Logs window shows the log messages generated by the access point and stored in memory. The Event Logs table displays the following information: • Log Time: The time the log message was generated. • Event Level: The logging level associated with this message. For a description of the various levels, see “logging level”...
Page 147 Status Information CLI Commands for Displaying the Logging Status – From the global configuration mode, use the show logging command. 7-31 Enterprise AP#show loggging Logging Information ============================================ Syslog State : Enabled Logging Console State : Enabled Logging Level : Alert Logging Facility Type : 16 Servers...
Page 148: Stp Status
System Configuration STP Status The STP Status window shows the STP status for each port. • ID: Displays the port ID number. • Priority: The priority designated to the specified port. • Path Cost: Displays the path cost value for the specified port. •...
Page 149: Chapter 7: Command Line Interface
Chapter 7: Command Line Interface Using the Command Line Interface Accessing the CLI When accessing the management interface for the over a direct connection to the console port, or via a Telnet connection, the access point can be managed by entering command keywords and parameters at the prompt.
Page 150: Entering Commands
Command Line Interface If your corporate network is connected to another network outside your office or to the Internet, you need to apply for a registered IP address. However, if you are attached to an isolated network, then you can use any IP address that matches the network segment to which you are attached.
Page 151: Command Completion
Entering Commands Command Completion If you terminate input with a Tab key, the CLI will print the remaining characters of a partial keyword up to the point of ambiguity. In the “configure” example, typing con followed by a tab will result in printing the command up to “configure.” Getting Help on Commands You can display a brief description of the help system by entering the help command.
Page 152: Partial Keyword Lookup
Command Line Interface Partial Keyword Lookup If you terminate a partial keyword with a question mark, alternatives that match the initial letters are provided. (Remember not to leave a space between the command and question mark.) For example “s?” shows all the keywords starting with “s.” Enterprise AP#show s? snmp sntp...
Page 153: Exec Commands
Entering Commands Exec Commands When you open a new console session on an access point, the system enters Exec command mode. Only a limited number of the commands are available in this mode. You can access all other commands only from the configuration mode. To access Exec mode, open a new console session with the user name “admin.”...
Page 154: Command Line Processing
Command Line Interface Command Line Processing Commands are not case sensitive. You can abbreviate commands and parameters as long as they contain enough letters to differentiate them from any other currently available commands or parameters. You can use the Tab key to complete partial commands, or enter a partial command followed by the “?”...
Page 155: General Commands
General Commands Table 7-2. Command Groups Command Group Description Page SNMP Configures community access strings and trap managers 7-39 Flash/File Manages code image or access point configuration files 7-54 RADIUS Configures the RADIUS client used with 802.1X authentication 7-57 802.1X Authentication Configures 802.1X authentication 7-64 MAC Address Configures MAC address authentication...
Page 156: Configure
Command Line Interface configure This command activates Global Configuration mode. You must enter this mode to modify most of the settings on the access point. You must also enter Global Configuration mode prior to enabling the context modes for Interface Configuration. See “Using the Command Line Interface”...
Page 157: Ping
General Commands Example This example shows how to return to the Exec mode from the Interface Configuration mode, and then quit the CLI session: Enterprise AP(if-ethernet)#exit Enterprise AP#exit CLI session with the Access Point is now closed Username: ping This command sends ICMP echo request packets to another node on the network. Syntax ping <host_name | ip_address>...
Page 158: Reset
Command Line Interface reset This command restarts the system or restores the factory default settings. Syntax reset <board | configuration> • board - Reboots the system. • configuration - Resets the configuration settings to the factory defaults, and then reboots the system. Default Setting None Command Mode...
Page 159: Show Line
System Management Commands show line This command displays the console port’s configuration settings. Command Mode Exec Example The console port settings are fixed at the values shown below. Enterprise AP#show line Console Line Information ====================================================== databits parity : none speed : 9600 stop bits ======================================================...
Page 160: Country
Command Line Interface Table 7-4. System Management Commands Command Function Mode Page Web Server ip http port Specifies the port to be used by the web browser interface 7-17 ip http server Allows the access point to be monitored or configured from a 7-18 browser ip https port...
Page 161: Default Setting
System Management Commands Table 7-5. Country Codes Country Code Country Code Country Code Country Code Belgium Guatemala Mexico Taiwan Honduras Monaco Thailand Belize Hong Kong Morocco Trinidad & Tobago Bolivia Hungary Netherlands Tunisia Brazil Iceland New Zealand Turkey Brunei India Norway Ukraine Darussalam...
Page 162: Prompt
Command Line Interface • The available Country Code settings can be displayed by using the country ? command. Example Enterprise AP#country tw Enterprise AP# prompt This command customizes the CLI prompt. Use the no form to restore the default prompt. Syntax prompt <string>...
Page 163: Username
System Management Commands Command Mode Global Configuration Example Enterprise AP(config)#system name AP Enterprise AP(config)# username This command configures the user name for management access. Syntax username <name> name - The name of the user. (Length: 3-16 characters, case sensitive) Default Setting admin Command Mode Global Configuration...
Page 164: Ip Ssh-Server Enable
Command Line Interface ip ssh-server enable This command enables the Secure Shell server. Use the no form to disable the server. Syntax ip ssh-server enable no ip ssh-server Default Setting Interface enabled Command Mode Interface Configuration (Ethernet) Command Usage • The access point supports Secure Shell version 2.0 only. •...
Page 165: Ip Telnet-Server Enable
System Management Commands ip telnet-server enable This command enables the Telnet server. Use the no form to disable the server. Syntax ip telnet-server enable no ip telnet-server Default Setting Interface enabled Command Mode Interface Configuration (Ethernet) Example Enterprise AP(if-ethernet)#ip telnet-server enable Enterprise AP(if-ethernet)# ip http port This command specifies the TCP port number used by the web browser interface.
Page 166: Ip Http Server
Command Line Interface ip http server This command allows this device to be monitored or configured from a browser. Use the no form to disable this function. Syntax ip http server no ip http server Default Setting Enabled Command Mode Global Configuration Example Enterprise AP(config)#ip http server...
Page 167: Ip Https Server
System Management Commands Example Enterprise AP(config)#ip https port 1234 Enterprise AP(config)# ip https server Use this command to enable the secure hypertext transfer protocol (HTTPS) over the Secure Socket Layer (SSL), providing secure access (i.e., an encrypted connection) to the access point’s Web interface. Use the no form to disable this function.
Page 168: Apmgmtip
Command Line Interface APmgmtIP This command specifies the client IP addresses that are allowed management access to the access point through various protocols. Caution: Secure Web (HTTPS) connections are not affected by the UI Management or IP Management settings. Syntax APmgmtIP <multiple IP_address subnet_mask | single IP_address | any>...
Page 169: Apmgmtui
System Management Commands APmgmtUI This command enables and disables management access to the access point through SNMP, Telnet and web interfaces. Caution: Secure Web (HTTPS) connections are not affected by the UI Management or IP Management settings. Syntax APmgmtUI <[SNMP | Telnet | Web] enable | disable> •...
Page 170: Show System
System Information ========================================================== Serial Number : A123456789 System Up time : 0 days, 4 hours, 33 minutes, 29 seconds System Name : SMC System Location System Contact System Country Code : US - UNITED STATES MAC Address : 00-30-F1-F0-9A-9C IP Address : 192.168.1.1...
Page 171: Show Version
System Management Commands show version This command displays the software version for the system. Command Mode Exec Example Enterprise AP#show version Version Information ========================================= Version: v4.3.2.2 Date : Dec 20 2005, 18:38:12 ========================================= Enterprise AP# show config This command displays detailed configuration information for the system. Command Mode Exec Example...
Page 172 Admin status : Up Operational status : Up ======================================== Wireless Interface 802.11a Information =========================================================== ----------------Identification----------------------------- Description : SMC 802.11a Access Point SSID : SMC_A 0 Channel : 0 (AUTO) Status : Disable ----------------802.11 Parameters-------------------------- Transmit Power : 100% (5 dBm)
Page 173 System Management Commands Logging Information ===================================================== Syslog State : Disabled Logging Console State : Disabled Logging Level : Informational Logging Facility Type : 16 Servers 1: 0.0.0.0 , UDP Port: 514, State: Disabled 2: 0.0.0.0 , UDP Port: 514, State: Disabled 3: 0.0.0.0 , UDP Port: 514, State: Disabled...
Page 174 No 802.11g Channel Stations. System Information ============================================================== Serial Number System Up time : 0 days, 0 hours, 16 minutes, 51 seconds System Name : SMC System Location System Contact : Contact System Country Code : 99 - NO_COUNTRY_SET MAC Address...
Page 175: Show Hardware
System Logging Commands SSH Server : ENABLED SSH Server Port : 22 Telnet Server : ENABLED DHCP Relay : DISABLED ============================================================== Version Information ========================================= Version: v4.3.2.2 Date : Dec 20 2005, 18:38:12 ========================================= Enterprise AP# show hardware This command displays the hardware version of the system. Command Mode Exec Example...
Page 176: Logging On
Command Line Interface logging on This command controls logging of error messages; i.e., sending debug or error messages to memory. The no form disables the logging process. Syntax [no] logging on Default Setting Disabled Command Mode Global Configuration Command Usage The logging process controls error messages saved to memory.
Page 177: Logging Console
System Logging Commands Example Enterprise AP(config)#logging host 1 10.1.0.3 Enterprise AP(config)# logging console This command initiates logging of error messages to the console. Use the no form to disable logging to the console. Syntax logging console no logging console Default Setting Disabled Command Mode Global Configuration...
Page 178: Logging Facility-Type
Command Line Interface Command Usage Messages sent include the selected level down to Emergency level. Level Argument Description Emergency System unusable Alert Immediate action needed Critical Critical conditions (e.g., memory allocation, or free memory error - resource exhausted) Error Error conditions (e.g., invalid input, default used) Warning Warning conditions (e.g., return false, unexpected return) Notice...
Page 179: Logging Clear
System Logging Commands Command Usage The command specifies the facility type tag sent in syslog messages. (See RFC 3164.) This type has no effect on the kind of messages reported by the access point. However, it may be used by the syslog server to sort messages or to store messages in the corresponding database.
Page 180: Show Event-Log
Command Line Interface show event-log This command displays log messages stored in the access point’s memory. Syntax show event-log Command Mode Exec Example Enterprise AP#show event-log Mar 09 11:57:55 Information: 802.11g:11g Radio Interface Enabled Mar 09 11:57:55 Information: 802.11g:Radio channel updated to 8 Mar 09 11:57:34 Information: 802.11g:11g Radio Interface Enabled Mar 09 11:57:18...
Page 181: Sntp-Server Ip
System Clock Commands sntp-server ip This command sets the IP address of the servers to which SNTP time requests are issued. Use the this command with no arguments to clear all time servers from the current list. Syntax sntp-server ip <1 | 2> <ip> •...
Page 182: Sntp-Server Date-Time
Command Line Interface Command Mode Global Configuration Command Usage The time acquired from time servers is used to record accurate dates and times for log events. Without SNTP, the access point only records the time starting from the factory default set at the last bootup (i.e., 00:14:00, January 1, 1970).
Page 183: Sntp-Server Daylight-Saving
System Clock Commands sntp-server daylight-saving This command sets the start and end dates for daylight savings time. Use the no form to disable daylight savings time. Syntax sntp-server daylight-saving no sntp-server daylight-saving Default Setting Disabled Command Mode Global Configuration Command Usage The command sets the system clock back one hour during the specified period.
Page 184: Show Sntp
Command Line Interface Command Usage This command sets the local time zone relative to the Coordinated Universal Time (UTC, formerly Greenwich Mean Time or GMT), based on the earth’s prime meridian, zero degrees longitude. To display a time corresponding to your local time, you must indicate the number of hours and minutes your time zone is east (before) or west (after) of UTC.
Page 185: Dhcp Relay Commands
DHCP Relay Commands DHCP Relay Commands Dynamic Host Configuration Protocol (DHCP) can dynamically allocate an IP address and other configuration information to network clients that broadcast a request. To receive the broadcast request, the DHCP server would normally have to be on the same subnet as the client.
Page 186: Dhcp-Relay
Command Line Interface dhcp-relay This command configures the primary and secondary DHCP server addresses. Syntax dhcp-relay <primary | secondary> <ip_address> • primary - The primary DHCP server. • secondary - The secondary DHCP server. • ip_address - IP address of the server. Default Setting Primary and secondary: 0.0.0.0 Command Mode...
Page 187: Snmp Commands
SNMP Commands SNMP Commands Controls access to this access point from management stations using the Simple Network Management Protocol (SNMP), as well as the hosts that will receive trap messages. Table 7-9. SNMP Commands Command Function Mode Page snmp-server community Sets up the community access string to permit access 7-40 to SNMP commands...
Page 188: Snmp-Server Community
Command Line Interface snmp-server community This command defines the community access string for the Simple Network Management Protocol. Use the no form to remove the specified community string. Syntax snmp-server community string [ro | rw] no snmp-server community string • string - Community string that acts like a password and permits access to the SNMP protocol.
Page 189: Snmp-Server Location
SNMP Commands Command Mode Global Configuration Example Enterprise AP(config)#snmp-server contact Paul Enterprise AP(config)# Related Commands snmp-server location (7-41) snmp-server location This command sets the system location string. Use the no form to remove the location string. Syntax snmp-server location <text> no snmp-server location text - String that describes the system location.
Page 190: Snmp-Server Host
Command Line Interface Command Mode Global Configuration Command Usage • This command enables both authentication failure notifications and link-up-down notifications. • The snmp-server host command specifies the host device that will receive SNMP notifications. Example Enterprise AP(config)#snmp-server enable server Enterprise AP(config)# Related Commands snmp-server host (7-42) snmp-server host...
Page 191: Snmp-Server Trap
SNMP Commands Command Usage The snmp-server host command is used in conjunction with the snmp-server enable server command to enable SNMP notifications. Example Enterprise AP(config)#snmp-server host 1 10.1.19.23 batman Enterprise AP(config)# Related Commands snmp-server enable server (7-41) snmp-server trap This command enables the access point to send specific SNMP traps (i.e., notifications).
Page 192: Snmp-Server Engine-Id
Command Line Interface - iappStationRoamedTo - A client station has roamed to another access point (identified by its IP address). - localMacAddrAuthFail - A client station has failed authentication with the local MAC address database on the access point. - localMacAddrAuthSuccess - A client station has successfully authenticated its MAC address with the local database on the access point.
Page 193: Snmp-Server User
SNMP Commands Command Mode Global Configuration Command Usage • This command is used in conjunction with the command. snmp-server user • Entering this command invalidates all engine IDs that have been previously configured. • If the engineID is deleted or changed, all SNMP users will be cleared. You will need to reconfigure all existing users Example Enterprise AP(config)#snmp-server engine-id 1a:2b:3c:4d:00:ff...
Page 194 Command Line Interface - RWAuth - A read/write group using authentication, but no data encryption. Users in this group send SNMP messages that use an MD5 key/password for authentication, but not a DES key/password for encryption. - RWPriv - A read/write group using authentication and data encryption. Users in this group send SNMP messages that use an MD5 key/ password for authentication and a DES key/password for encryption.
Page 195: Snmp-Server Targets
SNMP Commands snmp-server targets This command configures SNMP v3 notification targets. Use the no form to delete an SNMP v3 target. Syntax snmp-server targets <target-id> <ip-addr> <sec-name> [version {3}] [udp-port {port-number}] [notification-type {TRAP}] no snmp-server targets <target-id> • target-id - A user-defined name that identifies a receiver of SNMP notifications.
Page 196: Snmp-Server Filter
Command Line Interface snmp-server filter This command configures SNMP v3 notification filters. Use the no form to delete an SNMP v3 filter or remove a subtree from a filter. Syntax snmp-server filter <filter-id> <include | exclude> <subtree> [mask {mask}] no snmp-server filter <filter-id> [subtree] •...
Page 197: Snmp-Server Filter-Assignments
SNMP Commands snmp-server filter-assignments This command assigns SNMP v3 notification filters to targets. Use the no form to remove an SNMP v3 filter assignment. Syntax snmp-server filter-assignments <target-id> <filter-id> no snmp-server filter-assignments <target-id> • target-id - A user-defined name that identifies a receiver of SNMP notifications.
Page 198: Show Snmp Users
Command Line Interface Example Enterprise AP#show snmp groups GroupName SecurityModel :USM SecurityLevel :NoAuthNoPriv GroupName :RWAuth SecurityModel :USM SecurityLevel :AuthNoPriv GroupName :RWPriv SecurityModel :USM SecurityLevel :AuthPriv Enterprise AP# show snmp users This command displays the SNMP v3 users and settings. Syntax show snmp users Command Mode Exec...
Page 199: Show Snmp Target
SNMP Commands Example Enterprise AP#show snmp group-assignments GroupName :RWPriv UserName :chris Enterprise AP# Enterprise AP# show snmp target This command displays the SNMP v3 notification target settings. Syntax show snmp target Command Mode Exec Example Enterprise AP#show snmp target Host ID : mytraps User : chris...
Page 200: Show Snmp Filter-Assignments
Command Line Interface show snmp filter-assignments This command displays the SNMP v3 notification filter assignments. Syntax show snmp filter-assignments Command Mode Exec Example Enterprise AP#show snmp filter-assignments HostID FilterID mytraps trapfilter Enterprise AP# 7-52...
Page 201: Show Snmp
SNMP Commands show snmp This command displays the SNMP configuration settings. Command Mode Exec Example Enterprise AP#show snmp SNMP Information ============================================== Service State : Enable Community (ro) : ***** Community (rw) : ***** Location : WC-19 Contact : Paul EngineId :80:00:07:e5:80:00:00:2e:62:00:00:00:18 EngineBoots:1 Trap Destinations:...
Page 202: Flash/File Commands
Command Line Interface Flash/File Commands These commands are used to manage the system code or configuration files. Table 7-10. Flash/File Commands Command Function Mode Page bootfile Specifies the file or image used to start up the system 7-54 copy Copies a code image or configuration between flash Exec 7-55 memory and a FTP/TFTP server...
Page 203: Copy
Flash/File Commands copy This command copies a boot file, code image, or configuration file between the access point’s flash memory and a FTP/TFTP server. When you save the configuration settings to a file on a FTP/TFTP server, that file can later be downloaded to the access point to restore system operation.
Page 204: Delete
Command Line Interface The following example shows how to download a configuration file: Enterprise AP#copy tftp file 1. Application image 2. Config file 3. Boot block image Select the type of download<1,2,3>: [1]:2 TFTP Source file name:syscfg TFTP Server IP:192.168.1.19 Enterprise AP# delete This command deletes a file or image.
Page 205: Dir
Flash/File Commands This command displays a list of files in flash memory. Command Mode Exec Command Usage File information is shown below: Column Heading Description File Name The name of the file. Type (2) Operation Code and (5) Configuration file File Size The length of the file in bytes.
Page 206: Radius Client
Command Line Interface RADIUS Client Remote Authentication Dial-in User Service (RADIUS) is a logon authentication protocol that uses software running on a central server to control access for RADIUS-aware devices to the network. An authentication server contains a database of credentials, such as users names and passwords, for each wireless client that requires access to the access point.
Page 207: Radius-Server Port
RADIUS Client Command Mode Global Configuration Example Enterprise AP(config)#radius-server address 192.168.1.25 Enterprise AP(config)# radius-server port This command sets the RADIUS server network port. Syntax radius-server [secondary] port <port_number> • secondary - Secondary server. • port_number - RADIUS server UDP port used for authentication messages. (Range: 1024-65535) Default Setting 1812...
Page 208: Radius-Server Retransmit
Command Line Interface radius-server retransmit This command sets the number of retries. Syntax radius-server [secondary] retransmit number_of_retries • secondary - Secondary server. • number_of_retries - Number of times the access point will try to authenticate logon access via the RADIUS server. (Range: 1 - 30) Default Setting Command Mode Global Configuration...
Page 209: Radius-Server Port-Accounting
RADIUS Client radius-server port-accounting This command sets the RADIUS Accounting server network port. Syntax radius-server [secondary] port-accounting <port_number> • secondary - Secondary server. If secondary is not specified, then the access point assumes you are configuring the primary RADIUS server. •...
Page 210: Radius-Server Radius-Mac-Format
Command Line Interface Example Enterprise AP(config)#radius-server timeout-interim 500 Enterprise AP(config)# radius-server radius-mac-format This command sets the format for specifying MAC addresses on the RADIUS server. Syntax radius-server radius-mac-format <multi-colon | multi-dash | no-delimiter | single-dash> • multi-colon - Enter MAC addresses in the form xx:xx:xx:xx:xx:xx. •...
Page 211: Show Radius
RADIUS Client show radius This command displays the current settings for the RADIUS server. Default Setting None Command Mode Exec Example Enterprise AP#show radius Radius Server Information ======================================== : 0.0.0.0 Port : 1812 : ***** Retransmit Timeout Radius MAC format : no-delimiter Radius VLAN format : HEX ========================================...
Page 212: 802.1X Authentication
Command Line Interface 802.1X Authentication The access point supports IEEE 802.1X access control for wireless clients. This control feature prevents unauthorized access to the network by requiring an 802.1X client application to submit user credentials for authentication. Client authentication is then verified by a RADIUS server using EAP (Extensible Authentication Protocol) before the access point grants client access to the network.
Page 213: 802.1X Broadcast-Key-Refresh-Rate
802.1X Authentication Command Mode Global Configuration Command Usage • When 802.1X is disabled, the access point does not support 802.1X authentication for any station. After successful 802.11 association, each client is allowed to access the network. • When 802.1X is supported, the access point supports 802.1X authentication only for clients initiating the 802.1X authentication process (i.e., the access point does NOT initiate 802.1X authentication).
Page 214: 802.1X Session-Key-Refresh-Rate
Command Line Interface command specifies the interval after which unicast session keys are changed. • Dynamic broadcast key rotation allows the access point to generate a random group key and periodically update all key-management capable wireless clients. Example Enterprise AP(config)#802.1X broadcast-key-refresh-rate 5 Enterprise AP(config)# 802.1x session-key-refresh-rate This command sets the interval at which unicast session keys are refreshed for...
Page 215: 802.1X-Supplicant Enable
802.1X Authentication Command Mode Global Configuration Example Enterprise AP(config)#802.1x session-timeout 300 Enterprise AP(config)# 802.1x-supplicant enable This command enables the access point to operate as an 802.1X supplicant for authentication. Use the no form to disable 802.1X authentication of the access point.
Page 216: Show Authentication
Command Line Interface Command Mode Global Configuration Command Usage The access point currently only supports EAP-MD5 CHAP for 802.1X supplicant authentication. Example Enterprise AP(config)#802.1x-supplicant user WA6102 dot1xpass Enterprise AP(config)# show authentication This command shows all 802.1X authentication settings, as well as the address filter table.
Page 217: Mac Address Authentication
MAC Address Authentication MAC Address Authentication Use these commands to define MAC authentication on the access point. For local MAC authentication, first define the default filtering policy using the address filter default command. Then enter the MAC addresses to be filtered, indicating if they are allowed or denied.
Page 218: Address Filter Entry
Command Line Interface Related Commands address filter entry (7-70) 802.1x-supplicant user (7-67) address filter entry This command enters a MAC address in the filter table. Syntax address filter entry <mac-address> <allowed | denied> • mac-address - Physical address of client. (Enter six pairs of hexadecimal digits separated by hyphens;...
Page 219: Mac-Authentication Server
MAC Address Authentication Command Mode Global Configuration Example Enterprise AP(config)#address filter delete 00-70-50-cc-99-1b Enterprise AP(config)# Related Commands 802.1x-supplicant user (7-67) mac-authentication server This command sets address filtering to be performed with local or remote options. Use the no form to disable MAC address authentication. Syntax mac-authentication server [local | remote] •...
Page 220: Filtering Commands
Command Line Interface Default 0 (disabled) Command Mode Global Configuration Example Enterprise AP(config)#mac-authentication session-timeout 1 Enterprise AP(config)# Filtering Commands The commands described in this section are used to filter communications between wireless clients, control access to the management interface from wireless clients, and filter traffic using specific Ethernet protocol types.
Page 221: Filter Local-Bridge
Filtering Commands filter local-bridge This command disables communication between wireless clients. Use the no form to disable this filtering. Syntax filter local-bridge <all-VAP | intra-VAP> no filter local-bridge all-VAP - When enabled, clients cannot establish wireless communications with any other client, either those associated to the same VAP interface or any other VAP interface.
Page 222: Filter Uplink Enable
Command Line Interface filter uplink enable This command enables filtering of MAC addresses from the Ethernet port. Syntax [no] filter uplink enable Default Disabled Command Mode Global Configuration Example Enterprise AP(config)#filter uplink enable Enterprise AP(config)# filter uplink This command adds or deletes MAC addresses from the uplink filtering table. Syntax filter uplink <add | delete>...
Page 223: Filter Ethernet-Type Protocol
Filtering Commands Global Configuration Command Usage This command is used in conjunction with the filter ethernet-type protocol command to determine which Ethernet protocol types are to be filtered. Example Enterprise AP(config)#filter ethernet-type enable Enterprise AP(config)# Related Commands filter ethernet-type protocol (7-75) filter ethernet-type protocol This command sets a filter for a specific Ethernet type.
Page 224: Show Filters
Command Line Interface show filters This command shows the filter options and protocol entries in the filter table. Command Mode Exec Example Enterprise AP#show filters Protocol Filter Information ======================================================================= Local Bridge :Traffic among all client STAs blocked AP Management :ENABLED Ethernet Type Filter :DISABLED UPlink Access Table -----------------------------------------------------------------------...
Page 225: Bridge Role (Wds)
WDS Bridge Commands bridge role (WDS) This command selects the bridge operation mode for the radio interface. Syntax bridge role <ap | repeater | bridge | root-bridge > • ap - Operates only as an access point for wireless clients. •...
Page 226: Bridge-Link Child
Command Line Interface Default Setting None Command Mode Interface Configuration (Wireless) Command Usage Every bridge (except the root bridge) in the wireless bridge network must specify the MAC address of the parent bridge that is linked to the root bridge, or the root bridge itself.
Page 227: Bridge Dynamic-Entry Age-Time
WDS Bridge Commands bridge dynamic-entry age-time This command sets the time for aging out dynamic entries in the WDS forwarding table. Syntax bridge dynamic-entry age-time <seconds> seconds - The time to age out an address entry. (Range: 10-10000 seconds). Default Setting 300 seconds Command Mode Global Configuration...
Page 228: Show Bridge Filter-Entry
Command Line Interface show bridge filter-entry This command displays current entries in the WDS forwarding table. Command Mode Exec Example Enterprise AP#show bridge filter-entry max entry numbers =512 current entry nums =13 ***************************************************************************** *********************** Bridge MAC Addr Table ******************************* ***************************************************************************** Port |Fwd_type| VlanID|origin life|remain Life| Type...
Page 229 WDS Bridge Commands Example Enterprise AP#show bridge link wireless a Interface Wireless A WDS Information ==================================== AP Role: Bridge Parent: 00-12-34-56-78-9a Child: Child 2: 00-08-12-34-56-de Child 3: 00-00-00-00-00-00 Child 4: 00-00-00-00-00-00 Child 5: 00-00-00-00-00-00 Child 6: 00-00-00-00-00-00 STAs: No WDS Stations. Enterprise AP# Enterprise AP#show bridge link wireless a 2 Port-No...
Page 230: Spanning Tree Commands
Command Line Interface Spanning Tree Commands The commands described in this section are used to set the MAC address table aging time and spanning tree parameters for both the Ethernet and wireless interfaces. Table 7-15. Bridge Commands Command Function Mode Page bridge stp enable Enables the Spanning Tree feature...
Page 231: Bridge Stp Forwarding-Delay
Spanning Tree Commands bridge stp forwarding-delay Use this command to configure the spanning tree bridge forward time globally for the wireless bridge. Use the no form to restore the default. Syntax bridge stp forwarding-delay <seconds> no bridge stp forwarding-delay seconds - Time in seconds. (Range: 4 - 30 seconds) The minimum value is the higher of 4 or [(max-age / 2) + 1].
Page 232: Bridge Stp Max-Age
Command Line Interface Example Enterprise AP(config)#bridge stp hello-time 5 Enterprise AP(config)# bridge stp max-age Use this command to configure the spanning tree bridge maximum age globally for the wireless bridge. Use the no form to restore the default. Syntax bridge stp max-age <seconds> no bridge stp max-age seconds - Time in seconds.
Page 233: Bridge-Link Path-Cost
Spanning Tree Commands Command Mode Global Configuration Command Usage Bridge priority is used in selecting the root device, root port, and designated port. The device with the highest priority becomes the STP root device. However, if all devices have the same priority, the device with the lowest MAC address will then become the root device.
Page 234: Show Bridge Stp
Command Line Interface Default Setting Command Mode Interface Configuration Command Usage • This command defines the priority for the use of a port in the Spanning Tree Protocol. If the path cost for all ports on a wireless bridge are the same, the port with the highest priority (that is, lowest value) will be configured as an active link in the spanning tree.
Page 235: Ethernet Interface Commands
Ethernet Interface Commands Ethernet Interface Commands The commands described in this section configure connection parameters for the Ethernet port and wireless interface. Table 7-16. Ethernet Interface Commands Command Function Mode Page interface ethernet Enters Ethernet interface configuration mode 7-87 dns primary- server Specifies the primary name server IC-E 7-88...
Page 236: Dns Server
Command Line Interface dns server This command specifies the address for the primary or secondary domain name server to be used for name-to-address resolution. Syntax dns primary-server <server-address> dns secondary-server <server-address> • primary-server - Primary server used for name resolution. •...
Page 237: Ip Dhcp
Ethernet Interface Commands Command Mode Interface Configuration (Ethernet) Command Usage • DHCP is enabled by default. To manually configure a new IP address, you must first disable the DHCP client with the no ip dhcp command. • You must assign an IP address to this device to gain management access over the network or to connect the access point to existing IP subnets.
Page 238: Speed-Duplex
Command Line Interface • When you use this command, the access point will begin broadcasting DHCP client requests. The current IP address (i.e., default or manually configured address) will continue to be effective until a DHCP reply is received. Requests will be broadcast periodically by this device in an effort to learn its IP address.
Page 239: Shutdown
Ethernet Interface Commands shutdown This command disables the Ethernet interface. To restart a disabled interface, use the no form. Syntax shutdown no shutdown Default Setting Interface enabled Command Mode Interface Configuration (Ethernet) Command Usage This command allows you to disable the Ethernet port due to abnormal behavior (e.g., excessive collisions), and reenable it after the problem has been resolved.
Page 240: Wireless Interface Commands
Command Line Interface Example Enterprise AP#show interface ethernet Ethernet Interface Information ======================================== IP Address : 192.168.2.2 Subnet Mask : 255.255.255.0 Default Gateway : 192.168.1.253 Primary DNS : 192.168.1.55 Secondary DNS : 10.1.0.55 Speed-duplex : 100Base-TX Half Duplex Admin status : Up Operational status : Up ========================================...
Page 241 Wireless Interface Commands Table 7-17. Wireless Interface Commands Command Function Mode Page beacon-interval Configures the rate at which beacon signals are IC-W 7-101 transmitted from the access point dtim-period Configures the rate at which stations in sleep mode IC-W 7-102 must wake up to receive broadcast/multicast transmissions fragmentation- length...
Page 242: Interface Wireless
Command Line Interface interface wireless This command enters wireless interface configuration mode. Syntax interface wireless <a | g> • a - 802.11a radio interface. • g - 802.11g radio interface. Default Setting None Command Mode Global Configuration Example To specify the 802.11a interface, enter the following command: Enterprise AP(config)#interface wireless a Enterprise AP(if-wireless a)# This command provides access to the VAP (Virtual Access Point) interface...
Page 243: Speed
Wireless Interface Commands speed This command configures the maximum data rate at which the access point transmits unicast packets. Syntax speed <speed> speed - Maximum access speed allowed for wireless clients. (Options for 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps) (Options for 802.11b/g: 1, 2, 5.5, 6, 9, 11, 12, 18, 24, 36, 48, 54 Mbps) Default Setting 54 Mbps...
Page 244: Multicast-Data-Rate
Command Line Interface Command Usage • The normal 802.11a wireless operation mode provides connections up to 54 Mbps. Turbo Mode is an enhanced mode (not regulated in IEEE 802.11a) that provides a higher data rate of up to 108 Mbps. Enabling Turbo Mode allows the access point to provide connections up to 108 Mbps.
Page 245: Channel
Wireless Interface Commands channel This command configures the radio channel through which the access point communicates with wireless clients. Syntax channel <channel | auto> • channel - Manually sets the radio channel used for communications with wireless clients. (Range for 802.11a: 36, 40, 44, 48, 52, 56, 60, 64, 149, 153, 157, 161, 165 for normal mode, and 42, 50, 58, 152, 160 for turbo mode;...
Page 246: Radio-Mode
Command Line Interface Default Setting full Command Mode Interface Configuration (Wireless) Command Usage • The “min” keyword indicates minimum power. • The longer the transmission distance, the higher the transmission power required. But to support the maximum number of users in an area, you must keep the power as low as possible.
Page 247: Preamble
Wireless Interface Commands Example Enterprise AP(if-wireless g)#radio-mode g Enterprise AP(if-wireless g)# preamble This command sets the length of the signal preamble that is used at the start of a 802.11b/g data transmission. Syntax preamble [long | short-or-long] • long - Sets the preamble to long (192 microseconds). •...
Page 248: Antenna Id
Command Line Interface • right - The radio only uses the antenna on the right side (the side closest to the access point LEDs). Select this method when using an optional external antenna that is connected to the right antenna connector. Default Setting Diversity Command Mode...
Page 249: Antenna Location
Wireless Interface Commands antenna location This command selects the antenna mounting location for the radio interface. Syntax antenna location <indoor | outdoor> • indoor - The antenna is mounted indoors. • outdoor - The antenna is mounted outdoors. Default Setting Indoor Command Mode Interface Configuration (Wireless)
Page 250: Dtim-Period
Command Line Interface Example Enterprise AP(if-wireless g)#beacon-interval 150 Enterprise AP(if-wireless g)# dtim-period This command configures the rate at which stations in sleep mode must wake up to receive broadcast/multicast transmissions. Syntax dtim-period <interval> interval - Interval between the beacon frames that transmit broadcast or multicast traffic.
Page 251: Fragmentation-Length
Wireless Interface Commands fragmentation-length This command configures the minimum packet size that can be fragmented when passing through the access point. Syntax fragmentation-length <length> length - Minimum packet size for which fragmentation is allowed. (Range: 256-2346 bytes) Default Setting 2346 Command Mode Interface Configuration (Wireless) Command Usage...
Page 252: Super-A
Command Line Interface Default Setting 2347 Command Mode Interface Configuration (Wireless) Command Usage • If the threshold is set to 0, the access point always sends RTS signals. If set to 2347, the access point never sends RTS signals. If set to any other value, and the packet size equals or exceeds the RTS threshold, the RTS/CTS (Request to Send / Clear to Send) mechanism will be enabled.
Page 253: Super-G
Wireless Interface Commands super-g This command enables Atheros proprietary Super G performance enhancements. Use the no form to disable this function. Syntax [no] super-g Default Setting Disabled Command Mode Interface Configuration (Wireless - 802.11g) Command Usage These enhancements include bursting, compression, fast frames and dynamic turbo.
Page 254: Ssid
Command Line Interface ssid This command configures the service set identifier (SSID). Syntax ssid <string> string - The name of a basic service set supported by the access point. (Range: 0 - 7 characters) Default Setting 802.11a Radio: VAP_TEST_11A (0 to 3) 802.11g Radio: VAP_TEST_11G (0 to 3) Command Mode Interface Configuration (Wireless-VAP)
Page 255: Max-Association
Wireless Interface Commands max-association This command configures the maximum number of clients that can be associated with the access point at the same time. Syntax max-association <count> count - Maximum number of associated stations. (Range: 0-64) Default Setting Command Mode Interface Configuration (Wireless-VAP) Example Enterprise AP(if-wireless g: VAP[0])#max-association 32...
Page 256: Shutdown
Command Line Interface Default Setting Command Mode Interface Configuration (Wireless-VAP) Example Enterprise AP(if-wireless g: VAP[0])#auth-timeout-value 40 Enterprise AP(if-wireless g: VAP[0])# shutdown This command disables the wireless interface. Use the no form to restart the interface. Syntax shutdown no shutdown Default Setting Interface enabled Command Mode Interface Configuration (Wireless-VAP)
Page 257: Show Interface Wireless
Wireless Interface Commands show interface wireless This command displays the status for the wireless interface. Syntax show interface wireless <a | g> vap-id • a - 802.11a radio interface. • g - 802.11g radio interface. • vap-id - The number that identifies the VAP interface. (Options: 0~7) Command Mode Exec Example...
Page 258 Command Line Interface ----------------802.1x--------------------------------------------------- 802.1x : DISABLED Broadcast Key Refresh Rate : 30 min Session Key Refresh Rate : 30 min 802.1x Session Timeout Value : 0 min ----------------Antenna-------------------------------------------------- Antenna Control method : Diversity Antenna ID : 0x0000(Default Antenna) Antenna Location : Indoor ----------------Quality of Service--------------------------------------- WMM Mode...
Page 259: Show Station
Wireless Interface Commands show station This command shows the wireless clients associated with the access point. Command Mode Exec Example Enterprise AP#show station Station Table Information ======================================================== if-wireless A VAP [0] 802.11a Channel : 60 No 802.11a Channel Stations. if-wireless G VAP [0] 802.11g Channel : 1 802.11g Channel Station Table Station Address...
Page 260: Rogue Ap Detection Commands
Command Line Interface Rogue AP Detection Commands A “rogue AP” is either an access point that is not authorized to participate in the wireless network, or an access point that does not have the correct security configuration. Rogue APs can potentially allow unauthorized users access to the network.
Page 261: Rogue-Ap Authenticate
Rogue AP Detection Commands • A “rogue AP” is either an access point that is not authorized to participate in the wireless network, or an access point that does not have the correct security configuration. Rogue access points can be identified by unknown BSSID (MAC address) or SSID configuration.
Page 262: Rogue-Ap Duration
Command Line Interface rogue-ap duration This command sets the scan duration for detecting access points. Syntax rogue-ap duration <milliseconds> milliseconds - The duration of the scan. (Range: 100-1000 milliseconds) Default Setting 350 milliseconds Command Mode Interface Configuration (Wireless) Command Usage •...
Page 263: Rogue-Ap Scan
Rogue AP Detection Commands Example Enterprise AP(if-wireless g)#rogue-ap interval 120 Enterprise AP(if-wireless g)# Related Commands rogue-ap duration (7-114) rogue-ap scan This command starts an immediate scan for access points on the radio interface. Default Setting Disabled Command Mode Interface Configuration (Wireless) Command Usage While the access point scans a channel for rogue APs, wireless clients will not be able to connect to the access point.
Page 264: Show Rogue-Ap
Command Line Interface show rogue-ap This command displays the current rogue AP database. Command Mode Exec Example Enterprise AP#show rogue-ap 802.11a Channel : Rogue AP Status AP Address(BSSID) SSID Channel(MHz) RSSI Type Privacy RSN ====================================================================== 802.11g Channel : Rogue AP Status AP Address(BSSID) SSID Channel(MHz) RSSI Type Privacy RSN...
Page 265: Auth
Wireless Security Commands Table 7-19. Wireless Security Commands Command Function Mode Page pmksa-lifetime Sets the lifetime PMK security associations IC-W-VAP 7-124 pre-authentication Enables WPA2 pre-authentication for fast roaming IC-W-VAP 7-125 auth This command configures authentication for the VAP interface. Syntax auth <open-system | shared-key | wpa | wpa-psk | wpa2 | wpa2-psk | wpa-wpa2-mixed | wpa-wpa2-psk-mixed | >...
Page 266 Command Line Interface • To use WEP shared-key authentication, set the authentication type to “shared-key” and define at least one static WEP key with the key command. Encryption is automatically enabled by the command. • To use WEP encryption only (no authentication), set the authentication type to “open-system.”...
Page 267: Encryption
Wireless Security Commands Example Enterprise AP(if-wireless g: VAP[0])#auth shared-key Enterprise AP(if-wireless g)# Related Commands encryption (7-119) key (7-120) encryption This command enables data encryption for wireless communications. Use the no form to disable data encryption. Syntax encryption no encryption Default Setting disabled Command Mode Interface Configuration (Wireless-VAP)
Page 268: Key
Command Line Interface This command sets the keys used for WEP encryption. Use the no form to delete a configured key. Syntax key <index> <size> <type> <value> no key index • index - Key index. (Range: 1-4) • size - Key size. (Options: 64, 128, or 152 bits) •...
Page 269: Transmit-Key
Wireless Security Commands transmit-key This command sets the index of the key to be used for encrypting data frames for broadcast or multicast traffic transmitted from the VAP to wireless clients. Syntax transmit-key <index> index - Key index. (Range: 1-4) Default Setting Command Mode Interface Configuration (Wireless-VAP)
Page 270: Cipher-Suite
Command Line Interface cipher-suite This command defines the cipher algorithm used to encrypt the global key for broadcast and multicast traffic when using Wi-Fi Protected Access (WPA) security. Syntax multicast-cipher <aes-ccmp | tkip | wep> • aes-ccmp - Use AES-CCMP encryption for the unicast and multicast cipher.
Page 271: Mic_Mode
Wireless Security Commands • AES-CCMP (Advanced Encryption Standard Counter-Mode/CBCMAC Protocol): WPA2 is backward compatible with WPA, including the same 802.1X and PSK modes of operation and support for TKIP encryption. The main enhancement is its use of AES Counter-Mode encryption with Cipher Block Chaining Message Authentication Code (CBC-MAC) for message integrity.
Page 272: Wpa-Pre-Shared-Key
Command Line Interface Example Enterprise AP(if-wireless a)#mic_mode hardware Enterprise AP(if-wireless g)# wpa-pre-shared-key This command defines a Wi-Fi Protected Access (WPA/WPA2) Pre-shared-key. Syntax wpa-pre-shared-key <hex | passphrase-key> <value> • hex - Specifies hexadecimal digits as the key input format. • passphrase-key - Specifies an ASCII pass-phrase string as the key input format.
Page 273: Pre-Authentication
Wireless Security Commands Command Mode Interface Configuration (Wireless-VAP) Command Usage • WPA2 provides fast roaming for authenticated clients by retaining keys and other security information in a cache, so that if a client roams away from an access point and then returns reauthentication is not required. •...
Page 274: Link Integrity Commands
Command Line Interface known to be already authenticated, so it proceeds directly to key exchange and association. • To support pre-authentication, both clients and access points in the network must be WPA2 enabled. • Pre-authentication requires all access points in the network to be on the same IP subnet.
Page 275: Link-Integrity Ping-Detect
Link Integrity Commands link-integrity ping-detect This command enables link integrity detection. Use the no form to disable link integrity detection. Syntax [no] link-integrity ping-detect Default Setting Disabled Command Mode Global Configuration Command Usage • When link integrity is enabled, the IP address of a host device in the wired network must be specified.
Page 276: Link-Integrity Ping-Interval
Command Line Interface link-integrity ping-interval This command configures the time between each Ping sent to the link host. Syntax link-integrity ping-interval <interval> interval - The time between Pings. (Range: 5 - 60 seconds) Default Setting 30 seconds Command Mode Global Configuration Example Enterprise AP(config)#link-integrity ping-interval 20 Enterprise AP(config)#...
Page 277: Show Link-Integrity
Link Integrity Commands Command Mode Global Configuration Example Enterprise AP(config)#link-integrity ethernet-detect Notification : Ethernet Link Detect SUCCESS - RADIO(S) ENABLED Enterprise AP(config)# show link-integrity This command displays the current link integrity configuration. Command Mode Exec Example Enterprise AP#show link-integrity Link Integrity Information =========================================================== Ethernet Detect : Enabled Ping Detect...
Page 278: Iapp Commands
Command Line Interface IAPP Commands The command described in this section enables the protocol signaling required to ensure the successful handover of wireless clients roaming between different 802.11f-compliant access points. In other words, the 802.11f protocol can ensure successful roaming between access points in a multi-vendor environment. iapp This command enables the protocol signaling required to hand over wireless clients roaming between different 802.11f-compliant access points.
Page 279: Vlan Commands
VLAN Commands VLAN Commands The access point can enable the support of VLAN-tagged traffic passing between wireless clients and the wired network. Up to 64 VLAN IDs can be mapped to specific wireless clients, allowing users to remain within the same VLAN as they move around a campus site.
Page 280: Management-Vlanid
Command Line Interface • Traffic entering the Ethernet port must be tagged with a VLAN ID that matches the access point’s native VLAN ID, or with a VLAN tag that matches one of the wireless clients currently associated with the access point.
Page 281: Wmm Commands
WMM Commands Default Setting Command Mode Interface Configuration (Wireless-VAP) Command Usage • To implement the default VLAN ID setting for VAP interface, the access point must enable VLAN support using the vlan command. • When VLANs are enabled, the access point tags frames received from wireless clients with the default VLAN ID for the VAP interface.
Page 282: Wmm
Command Line Interface This command sets the WMM operational mode on the access point. Use the no form to disable WMM. Syntax [no] wmm <supported | required> • supported - WMM will be used for any associated device that supports this feature.
Page 283: Wmmparam
WMM Commands interpretability with other wired network QoS policies. While the four ACs are specified for specific types of traffic, WMM allows the priority levels to be configured to match any network-wide QoS policy. WMM also specifies a protocol that access points can use to communicate the configured traffic priority levels to QoS-enabled wireless clients.
Page 284 Command Line Interface • admission_control - The admission control mode for the access category. When enabled, clients are blocked from using the access category. (Options: 0 to disable, 1 to enable) Default AP Parameters WMM Parameters AC0 (Best Effort) AC1 (Background) AC2 (Video) AC3 (Voice) LogCwMin LogCwMax...
Page 285: Appendix A: Troubleshooting
Appendix A: Troubleshooting Check the following items before you contact local Technical Support. If wireless clients cannot access the network, check the following: • Be sure the access point and the wireless clients are configured with the same Service Set ID (SSID). •...
Page 286 Troubleshooting If you cannot access the on-board configuration program via a serial port connection: • Be sure you have set the terminal emulator program to VT100 compatible, 8 data bits, 1 stop bit, no parity and 9600 bps. • Check that the null-modem serial cable conforms to the pin-out connections provided on page B-3.
Page 287: Appendix B: Cables And Pinouts
Appendix B: Cables and Pinouts Twisted-Pair Cable Assignments For 10/100BASE-TX connections, a twisted-pair cable must have two pairs of wires. Each wire pair is identified by two different colors. For example, one wire might be green and the other, green with white stripes. Also, an RJ-45 connector must be attached to both ends of the cable.
Page 288: Straight-Through Wiring
Cables and Pinouts Table B-1. 10/100BASE-TX MDI Port Pinouts MDI Signal Name Transmit Data plus (TD+) Transmit Data minus (TD-) Receive Data plus (RD+) GND (Positive Vport) GND (Positive Vport) Receive Data minus (RD-) -48V feeding power (Negative- Vport) -48V feeding power (Negative- Vport) Note: The “+”...
Page 289: Crossover Wiring
Console Port Pin Assignments Crossover Wiring Because the 10/100 Mbps port on the access point uses an MDI pin configuration, you must use “crossover” cable for network connections to PCs, servers or other end nodes that only have MDI ports. However, if the device to which you are connecting supports auto-MDIX operation, you can use either “straight-through”...
Page 290: Wiring Map For Serial Cable
Cables and Pinouts Wiring Map for Serial Cable Table B-2. Wiring Map for Serial Cable DB9 Male (AP Console) DB9 Male (PC DTE) Function Function GND (ground) GND (ground) Unused Unused RXD (receive data) TXD (transmit data) TXD (transmit data) RXD (receive data) Unused Unused...
Page 291: Appendix C: Specifications
Appendix C: Specifications General Specifications Maximum Channels 802.11a: US & Canada: 13 (normal mode), 5 (turbo mode) Japan: 4 (normal mode), 1 (turbo mode) ETSI: 11 channels (normal mode), 4 (turbo mode) Taiwan: 8 (normal mode), 3 (turbo mode) 802.11b/g: FCC/IC: 1-11 ETSI: 1-13 France: 10-13...
Page 292 Specifications Operating Frequency 802.11a: 5.15 ~ 5.25 GHz (lower band) US/Canada, Japan 5.25 ~ 5.35 GHz (middle band) US/Canada 5.725 ~ 5.825 GHz (upper band) US/Canada 5.50~ 5.70 GHz Europe 5.25 ~ 5.35 GHz (middle band) Taiwan 5.725 ~ 5.825 GHz (high band) Taiwan 802.11b: 2.4 ~ 2.4835 GHz (US, Canada, ETSI) 2.4 ~ 2.497 GHz (Japan)
Page 293 General Specifications Compliances FCC Class B (US) ICES-003 (Canada) RTTED 1999/5/EC VCCI (Japan) RCR STD-33A Radio Signal Certification FCC Part 15C 15.247, 15.207 (2.4 GHz) FCC part 15E 15.407 (5 GHz) RSS-210 (Canada) EN 301.893, EN 300.328, EN 301.489-1, EN 301.489-17 MPT RCR std.33 (D33 1~13 Channel, T66 Channel 14) Safety CSA 60950-1 / UL60950-1...
Page 294: Sensitivity
Specifications Sensitivity IEEE 802.11a Sensitivity (GHz - dBm) Modulation/Rates 5.15-5.250 5.25-5.350 5.50-5.700 5.725-5.825 BPSK (6 Mbps) BPSK (9 Mbps) QPSK (12 Mbps) QPSK (18 Mbps) 16 QAM (24 Mbps) 16 QAM (36 Mbps) 64 QAM (48 Mbps) 64QAM(54 Mbps) IEEE 802.11g Data Rate Sensitivity (dBm) 6 Mbps...
Page 295: Transmit Power
Transmit Power Transmit Power IEEE 802.11a Maximum Output Power (GHz - dBm) Data Rate 5.15-5.250 5.25-5.350 5.50-5.700 5.725-5.825 6 Mbps 9 Mbps 12 Mbps 8 Mbps 24 Mbps 36 Mbps 48 Mbps 54 Mbps IEEE 802.11g Maximum Output Power (GHz - dBm) Data Rate 2.412 2.417~2.467...
Page 296: Operating Range
Specifications Operating Range Important Notice Maximum distances posted below are actual tested distance thresholds. However, there are many variables such as barrier composition and construction and local environmental interference that may impact your actual distances and cause you to experience distance thresholds far lower than those posted below. Table C-1 802.11a Wireless Distance Table Speed and Distance Ranges Environment 108...
Page 297: Glossary
Glossary 10BASE-T IEEE 802.3 specification for 10 Mbps Ethernet over two pairs of Category 3 or better UTP cable. 100BASE-TX IEEE 802.3u specification for 100 Mbps Fast Ethernet over two pairs of Category 5 or better UTP cable. Access Point An internetworking device that seamlessly connects wired and wireless networks.
Page 298 Glossary Broadcast Key Broadcast keys are sent to stations using 802.1X dynamic keying. Dynamic broadcast key rotation is often used to allow the access point to generate a random group key and periodically update all key-management capable wireless clients. CSMA/CA Carrier Sense Multiple Access with Collision Avoidance.
Page 299 Glossary IEEE 802.11b A wireless standard that supports wireless communications in the 2.4 GHz band using Direct Sequence Spread Spectrum (DSSS). The standard provides for data rates of 1, 2, 5.5, and 11 Mbps. IEEE 802.11g A wireless standard that supports wireless communications in the 2.4 GHz band using using Orthogonal Frequency Division Multiplexing (OFDM).
Page 300 Glossary Power over Ethernet (PoE) A specification for providing both power and data to low-power network devices using a single Category 5 Ethernet cable. PoE provides greater flexibility in the locating of access point’s and network devices, and significantly decreased installation costs. RADIUS A logon authentication protocol that uses software running on a central server to control access to the network.
Page 301 Glossary Temporal Key Integrity Protocol (TKIP) A data encryption method designed as a replacement for WEP. TKIP avoids the problems of WEP static keys by dynamically changing data encryption keys. Trivial File Transfer Protocol (TFTP) A TCP/IP protocol commonly used for software downloads. Virtual Access Point (VAP) Virtual AP technology multiplies the number of Access Points present within the RF footprint of a single physical access device.
Page 302 Glossary Glossary-6...
Page 303: Index
Index Numerics console port 1-4 connecting 2-2 802.11g 7-94 pin assignments B-3 required settings 5-1 country code AES 6-80 configuring 5-3, 7-12 antennas, positioning 2-2 crossover cable B-3 authentication 6-12 CSMA/CA 1-1 cipher suite 6-82, 7-118 CTS 6-59, 7-104 closed system 7-106 configuring 6-12 MAC address 6-13, 7-69, 7-70 data rate...
Page 304 Index filter 6-17, 7-69 IP address address 6-12, 7-69 BOOTP/DHCP 7-88, 7-89 between wireless clients 7-73 configuring 5-2, 6-5, 7-88, 7-89 local bridge 7-73 local or remote 6-12, 7-71 LED indicators 1-3 management access 6-18, 7-73 location for the access point, protocol types 6-18, 7-74 considerations 3-1 VLANs 6-52, 7-131...
Page 305 Index PoE 1-5 SNTP 6-36, 7-33 specifications C-2 enabling client 6-36, 7-33 port priority server 6-36, 7-33 STA 7-85 software power connection 2-1 displaying version 6-30, 6-86, 7-23 Power over Ethernet See PoE downloading 6-32, 7-55 power supply, specifications C-2 specifications C-1 PSK 6-79 server Status 6-11...
Page 306 Index Wi-Fi Multimedia See WMM Wi-Fi Protected Access See WPA VLAN Wired Equivalent Protection See WEP configuration 6-52, 7-131 WPA 6-79 native ID 6-52 pre-shared key 6-82, 7-124 WPA, pre-shared key See PSK WEP 6-74 configuring 6-74 shared key 6-75, 7-120 Index-4...
Page 308 Informações sobre Suporte Técnico em www.smc.com SWEDISH Information om Teknisk Support finns tillgängligt på www.smc.com INTERNET E-mail address: techsupport@smc.com Driver updates http://www.smc.com/ index.cfm?action=tech_support_drivers_downloads World Wide Web http://www.smc.com/ SMC2555W-AG2 149100033500E R03 20 Mason • Irvine, CA 92618 • Phn: 949-679-8000 • www.smc.com...
