Front Panel Components (Installation)

Component
Power supplies
Cooling
Related Information
"Installation Task Overview" on page 9
■
"Front Panel Components (Installation)" on page 12
■
"Rear Panel Components (Installation)" on page 14
■
Netra Server X5-2 Service Manual
■
Front Panel Components (Installation)
The front panel for the 8-drive model is shown in the illustration.
No. Description
1 Indicators and switches, top to bottom:
Status indicators:
■ Locator LED and button
12 Netra Server X5-2 Installation Guide • June 2016
Description
Depending on the model, one of the following configurations:
■ 2 hot-swappable AC supplies (maximum 1200 W)
■ 2 hot-swappable DC supplies (maximum 1200 W)
Note - Mixing of AC and DC power supplies is not allowed.
Front-to-back forced air, with active fan speed control.
Links
"Interpreting Diagnostic LEDs" in Netra Server X5-2 Service
Manual
