Oracle Netra X5-2 Installation Manual page 15

No. Description
1 Hot-swappable power supply (AC or DC), PS1
2 Hot-swappable power suppiy (AC or DC), PS0
3 The number of available PCIe slots depends on the CPU
configuration.
■ Single Processor – Two PCIe 3.0 low-profile card slots
(slot 5 and slot 6)
■ Dual Processor – Six PCIe 3.0 low-profile card slots
4 SP 15-pin VGA video port
5 SP NET MGT port
6 Two USB 3.0 ports
7 SP SER MGT port
8 Four 10 Gigabit Ethernet ports (left to right: NET 3, NET 2,
NET 1, NET 0)
9 Chassis ground posts
10 Chassis Status LEDs:
■ Locator LED and button
■ Service Required LED
■ Main Power OK LED
Related Information
"Installation Task Overview" on page 9
■
"Server Overview" on page 10
■
"Front Panel Components (Installation)" on page 12
■
Netra Server X5-2 Service Manual
■
Rear Panel Components (Installation)
Links
"Servicing Power Supplies" in Netra Server X5-2 Service
Manual
"Servicing Power Supplies" in Netra Server X5-2 Service
Manual
"Servicing PCIe Cards" in Netra Server X5-2 Service
Manual
"Video Port" on page 70
"NET MGT Port" on page 67
"USB Ports" on page 69
"SER MGT Port" on page 66
"10 Gigabit Ethernet Ports" on page 68
"Connect the Chassis Ground Wire" on page 76
"Servicing the LED Board" in Netra Server X5-2 Service
Manual
Understanding the Server 15
