Component
Processor
Memory
Storage
Optical media
Service processor
Ethernet ports
PCIe slots
USB ports
Indicators and switches
Description
One or two socket Intel Haswell-EP, E5-2699v3 CPU, 18-core, dual-thread, 145W TDP max, non-
throttling.
The number of DIMM slots depends on the CPU configuration.
■ Single Processor – 12 DDR4, 2133 MHz, RDIMMs or LRDIMMs DIMM slots that support 16
GB RDIMM or 32 GB LRDIMM capacities.
■ Dual Processor – 24 DDR4, 2133 MHz, RDIMMs or LRDIMMs DIMM slots (12 DIMM slots per
CPU) that support 16 GB RDIMM or 32 GB LRDIMM capacities.
The quantity and capacity of installed memory varies based on what was ordered.
Note -
Depending on the model, one of the following configurations:
■ Six SFF slots with SAS HDDs or flash drives and a SATA-3 DVD-RW
■ Two SFF slots with SAS HDDs or flash drives and 4x SFF slots with NVMe HDDs and a SATA-3
DVD-RW
■ Eight SFF slots with SAS HDDs or flash drives and no SATA DVD-RW
■ Four SFF slots with SAS HDDs or flash drives and 4x SFF slots with NVMe HDD and no SATA-3
DVD-RW
The total number of drives and storage capacity varies based on what was ordered, with a
Note -
maximum capacity of either six or eight 600-GB drives.
Only available in the 6-drive model: One tray-loading, slimline SATA DVD drive, supporting CD-R/-
RW, CD+R/+RW, DVD-R/-RW, DVD+R/+RW (when used with supported media).
Internal Pilot3 BMC running Oracle ILOM service processor firmware with provisions for:
■ Oracle ILOM 3.2.4
■ 2D graphics (HD-15 VGA connector)
■ Serial management (RJ-45)
■ Network management (10/100/1000BASE-T Ethernet RJ-45)
■ Complete host remote management, including remote KVMS over Ethernet
■ Out-of-band host BIOS flash updates
Four 100/1000Mb/10Gb BASE-T Ethernet (RJ-45) with integrated link/speed LEDs.
The number of available PCIe slots depends on the CPU configuration.
■ Single Processor – One x8 PCIe Gen3 slot (slot 6) and one x16 PCIe Gen3 slot (slot 5). Both PCIe
expansion slots support PCIe 3.0 / Gen3 (PCIe3) signaling levels, and can support both Gen2 and
legacy Gen1 compliant option cards.
■ Dual Processor – Four x8 PCIe Gen3 slots and two x16 Gen3 slots. All PCIe expansion slots
support PCIe 3.0 / Gen3 (PCIe3) signaling levels, and can support both Gen2 and legacy Gen1
compliant option cards.
Six USB ports: two on front panel (USB 2.0), two on rear panel (USB 3.0), and two internal on
motherboard (USB 2.0).
Note - Internal USB port 0 is preinstalled with a USB drive containing OSA.
■ Power button switch
■ Locate button switch with integrated LED
■ System OK LED
■ System Fault LED
■ Alarm LEDs - Critical, Major, Minor, and User
■ SP LED
■ Rear PS fault LED
Server Overview
Understanding the Server 11
