Connect the Chassis Ground Wire

Step
1.
2.
3.
Related Information
"DC Power Source, Power Connection, and Grounding Requirements" on page 21
■
"Power On the Host for the First Time" on page 83
■
Connect the Chassis Ground Wire
The server shipping kit contains a grounding lug for connecting a chassis grounding wire to the
rear of the server. You must supply the grounding wire.
Caution -
grounded with the power supply ground pins or with the chassis ground studs. It is acceptable to
have both grounds connected.
This procedure is optional for servers with AC input power. It is acceptable to ground the server
through the supplies and chassis ground wire.
1. Retrieve the grounding lug and two M5 nuts from the shipping kit.
2. Insert the grounding wire into the receptacle of the grounding lug, and use a
crimping tool to crimp the receptacle around the wire.
3. Go to the back of the server and locate the two grounding studs.
76 Netra Server X5-2 Installation Guide • June 2016
Description
Connect the chassis to earth ground.
Build the DC power cords.
Connect the DC power cords to the DC power
source and to the server.
The DC power source must be reliably grounded. The server chassis must be
Links
"Connect the Chassis Ground Wire" on page 76
"Assemble the DC Input Power Cord" on page 78
"Connect DC Power Cords" on page 81
