Identifying Ports
Pin
4
Related Information
"Available Connections" on page 61
■
"Rear Panel Components (Installation)" on page 14
■
"SER MGT Port" on page 66
■
"10 Gigabit Ethernet Ports" on page 68
■
"USB Ports" on page 69
■
"Video Port" on page 70
■

10 Gigabit Ethernet Ports

The server has four RJ-45 10-Gigabit Ethernet (10GbE) network connectors, labeled NET 3,
NET 2, NET 1, and NET 0 (left to right) on the rear panel. Use these ports to connect the server
to the network.
The LEDs located above each NET port are Link/Activity (left) and Speed (right) indicators for
each port as described in this table:
Connection Type
Fast Ethernet
Gigabit Ethernet
10 Gigabit Ethernet
Note -
one of these Ethernet ports. Refer to the Oracle ILOM Administor's Guide for Configuration
and Maintenance For Release 3.2.x at
instructions.
68 Netra Server X5-2 Installation Guide • June 2016
Signal Description
No Connect
IEEE Terminology
100BASE-TX
1000BASE-T
10GBASE-T
The Oracle ILOM sideband management feature enables you to access the SP using
Pin Signal Description
8 No Connect
Speed LED Color
Off
Amber
Green
http://www.oracle.com/goto/ilom321/docs
Transfer Rate
100 Mbits/sec
1000 Mbits/sec
10000 Mbits/sec
for
