No. Description
2 Screws
3 Side brackets (2)
Related Information
"Install the Server (2-Post, 19-Inch Hardmount Rack Kit)" on page 53
■
"Tools Needed for Installation" on page 27
■
"Handling Precautions" on page 26
■
"Rack Cautions" on page 30
■
Install the Server (2-Post, 19-Inch Hardmount Rack
Kit)
The 19-inch, 2-post rackmount kit supports rack web thicknesses (the width of the rack
Note -
post) of 3 in. (76.20 mm), 4 in. (101.6 mm), and 5 in. (127 mm).
You must install the server into a rack following these instructions for the 2-post,
Caution -
19-inch hardmount kit. If you deviate from these instructions when installing the server, your
installation will not be supported.
1. Gather the required tools.
See "Tools Needed for Installation" on page
2. Read the server cautions.
See "Handling Precautions" on page 26
3. Read the rack cautions and stabilize the rack.
See "Rack Cautions" on page 30
4. If you are changing the rack kit on an existing server in your data center, perform
these steps:
Shut down the server, and remove the power and data cables.
a.
b. Remove the server from the rack, and place it on an antistatic mat.
c. Remove the existing mounting brackets from the server and rack, if
applicable.

Install the Server (2-Post, 19-Inch Hardmount Rack Kit)

27.
and "ESD Precautions" on page
and "Stabilize the Rack" on page
27.
31.
Installing the Server 53
