Install the Server (4-Post, 19-Inch Sliding Rails
With CMA Rack Kit)
You must install the server into a rack following these instructions for the 4-post,
Caution -
19-inch sliding rails with CMA kit. If you deviate from these instructions when installing the
server, your installation will not be supported.
Server racks can have either square or round mounting holes in the posts. These instructions can
be used for both types of racks.
Gather the required tools.
1.
See "Tools Needed for Installation" on page
2. Read the server cautions.
See "Handling Precautions" on page 26
Read the rack cautions and stabilize the rack.
3.
See "Rack Cautions" on page 30
4. If you are changing the rack kit on an existing server in your data center, perform
these steps:
Shut down the server, and remove the power and data cables.
a.
b. Remove the server from the rack, and place it on an antistatic mat.
c. Remove the existing mounting brackets from the server and rack, if
applicable.
5. Open the standard hardmount rail kit and the sliding rail kit with the CMA, and
confirm that all of the components are present.
For a description of the kit components, see
CMA" on page 38.
6. Remove the hardmount brackets and four M5 x 4.5 mm flathead Phillips screws
from the standard hardmount kit.
7. Attach the front, right and left hardmount brackets to the sides of the server.

Install the Server (4-Post, 19-Inch Sliding Rails With CMA Rack Kit)

27.
and "ESD Precautions" on page
and "Stabilize the Rack" on page
"19-Inch Sliding Rail Kit With the
27.
31.
Installing the Server 39
