Available Connections

Use the information in this topic to plan for these connections. Then gather the required

network addresses and cables.

Caution -

Ethernet and power connections) must be made using shielded cables, and both ends of the

shield must be grounded.

Caution -

isolated from the exposed outside plant cabling. Using primary protectors does not eliminate

this restriction. Ensure that these connections do not connect metallically to interfaces that

connect to the outside plant or its wiring.

This figure and table describe available ports and lists what you need to use them.

No.

Port

Description

VGA

Provides a video connection to the SP.

Netra Server X5-2 Installation Guide • June 2016

To comply with NEBS lightning requirements, all I/O connections (except the

All data cable connections are restricted to intra-building interfaces and must be

Needed

VGA monitor and cable (not to exceed 6 meters).
