No. Description
1 Top of connector
2 From -48V or -60V return
3 From chassis ground (green/yellow)
4 From -48V or -60V
If you need to remove a wire from the DC input plug, insert the cage clamp operating
Note -
lever or a small screwdriver and pull the wire from the DC input plug.
8. Release the lever or remove the tool to secure the wire into the connector.
9. Repeat the procedures for the other two wires to complete the assembly of the
DC input power cable.
10. Repeat this procedure to create as many DC input power cables as you need for
your unit.
Related Information
"Connect the Chassis Ground Wire" on page 76
■
"Assemble the DC Input Power Cord" on page 78
■
"Connect DC Power Cords" on page 81
■
"Power On the Host for the First Time" on page 83
■

Connect DC Power Cords

Prepare the power cords by routing them from the power source to the server.
1.
The server goes into Standby mode and the Oracle ILOM SP initializes as soon as a
Note -
power cable connects a power supply to an external power source. System messages might be
lost after 60 seconds if a terminal or terminal emulator is not connected to the SER MGT port
before power is applied.
Oracle ILOM will signal a fault if power is not applied to both supplies because, that is a
Note -
nonredundant condition.
2. Ensure that the input cables are de-energized with no DC power present.
