Installing the 19-Inch Sliding Rail Kit With the CMA

19-Inch Sliding Rail Kit With the CMA

No.
1
2
3
4
5
6
7
8
Related Information
"Install the Server (4-Post, 19-Inch Sliding Rails With CMA Rack Kit)" on page 39
■
"Tools Needed for Installation" on page 27
■
38 Netra Server X5-2 Installation Guide • June 2016
Description
Threaded screw plates (4)
Screw, nut, and U-clip packages
Cable management arm
Rear, long L-Brackets (2)
Front, short L-brackets (2)
Slide assemblies (2)
Glide assemblies (2)
Hardmount brackets (2) from standard rail kit
