DC Power Source, Power Connection, and Grounding
Requirements
The server power source and connections must meet the following requirements.
Note -
to the intent of the U.S. NEC, a restricted-access location is an area intended for qualified or
trained personnel only and has access controlled by a locking mechanism, such as a key lock or
an access card system.
Caution -
grounded with the power supply ground pins or with the chassis ground studs. It is acceptable to
have both grounds connected.
Caution -
the possibility that transient energy will appear on the main input to the equipment. The DC
battery power source must be in the same premises as the server. The server cannot be in one
building with the power source in another building.
Suitable conductor material — use copper conductors only.
■
Power supply connections through the input connector — 12 AWG (between the server and
■
the source). There are three conductors:
■
■
■
Server chassis ground 12 AWG conductor (optional if power supply grounds are
■
connected).
Grounding cable insulation color — Green/yellow.
■
Cable insulation rating — Minimum of 167˚F (75˚C). Low smoke fume, flame retardant
■
insulation might be required in some installations.)
Use mating connectors, Wago part number 721-103/037-000, for proper connection to the
■
product DC inputs. Connectors are included in the server's shipping kit.
Branch circuit cable insulation color — According to applicable national electrical codes.
■
DC power source must meet TNV-2 requirements as defined by UL 60950-1 and IEC
■
60950-1.
Related Information
"Physical Specifications" on page 17
■
"Electrical Specifications" on page 18
■
The DC version of the server must be installed in a restricted-access location. According
The DC power source must be reliably grounded. The server chassis must be
You must restrict the connection of the server to the DC power source to minimize
-48V or -60V (negative terminal, might be marked with a minus (-) symbol).
Chassis ground connection (optional if chassis ground wire is connected).
-48V or -60V return (positive terminal, might be marked with a plus (+) symbol).

DC Power Source, Power Connection, and Grounding Requirements

Confirming Specifications 21
