Power Consumption; Table 4 Measurement Description - Congatec COM Express conga-TC175 User Manual

2.5

Power Consumption

The power consumption values were measured with the following setup:
• conga-TC175 COM
• Modified congatec carrier board
• conga-TC175 cooling solution
• Microsoft Windows 10 (64 bit)
Note
The CPU was stressed to its maximum workload with the Intel
Table 4 Measurement Description
The power consumption values were recorded during the following system states:
System State
S0: Minimum value
S0: Maximum value
S0: Peak current
S3
S5
Note
1. The fan and SATA drives were powered externally.
2. All other peripherals except the LCD monitor were disconnected before measurement.
Copyright © 2017 congatec AG
Description
Lowest frequency mode (LFM) with minimum core voltage during desktop
idle.
Highest frequency mode (HFM/Turbo Boost).
Highest current spike during the measurement of "S0: Maximum value".
This state shows the peak value during runtime.
COM is powered by VCC_5V_SBY.
COM is powered by VCC_5V_SBY.
Thermal Analysis Tool
®
Comment
The CPU was stressed to its maximum frequency.
Consider this value when designing the system's power supply to
ensure that sufficient power is supplied during worst case scenarios.
