2.4

Supply Voltage Power

• 12 – 24V DC ± 5 %
2.5

Power Consumption

The power consumption values were measured using the following test setup:
• Input voltage +12V
• conga-IC175 SBC
• conga-IC175 cooling solution
• Microsoft Windows 10 (64 bit)
Note
The CPU was stressed to its maximum workload with the Intel
The power consumption values were recorded during the following system states:
Table 9 Measurement Description
System State Description
S0: Minimum value Lowest frequency mode (LFM) with minimum core voltage during
desktop idle.
S0: Maximum value Highest frequency mode (HFM/Turbo Boost).
S0: Peak current Highest current spike during the measurement of "S0: Maximum
value". This state shows the peak value during runtime
S3 SBC is powered by 12V.
S5
SBC is powered by 12V.
Note
1. The fan and SATA drives were powered externally.
2. All other peripherals except the LCD monitor were disconnected before measurement.
Copyright © 2017 congatec AG
Thermal Analysis Tool.
®
Comment
The CPU was stressed to its maximum frequency.
The CPU was stressed to its maximum frequency.
Consider this value when designing the system's power supply, to
ensure sufficient power is supplied during worst case scenarios.
ICKLm02 16/59
