2.3

Mechanical Dimensions

• 170mm x 170mm
• Maximum Height: 20mm
2.4

Supply Voltage Power

• 12V - 24V DC ± 10%
2.5

Power Consumption

The power consumption values were measured with the following setup:
• conga-IA5
• conga-IA5 cooling solution
• Microsoft ® Windows
Note
The CPU was stressed to its maximum workload with the Intel
Table 8 Measurement Description
The power consumption values were recorded during the following system states:
System State Description
S0: Minimum value Lowest frequency mode (LFM) with minimum core voltage during
desktop idle.
S0: Maximum value Highest frequency mode (HFM/Turbo Boost).
S0: Peak value
Highest current spike during the measurement of "S0: Maximum
value". This state shows the peak value during runtime.
S3 SBC is powered by VCC_5V_SBY.
S5 SBC is powered by VCC_5V_SBY.
Note
The fan and SATA drives were powered externally. All other peripherals, except the LCD monitor, were disconnected before measurement.
Copyright © 2017 congatec AG
® 10 (64-bit)
Thermal Analysis Tool
®
Comment
The CPU was stressed to its maximum frequency.
Consider this value when designing the system's power supply to
ensure that sufficient power is supplied during worst case scenarios.
IA50m01 15/59
