Connecting the network PTZ via a router
Steps:
1. Connect the network PTZ to the router.
2. In the PTZ, assign a LAN IP address, the subnet mask and the gateway. Refer to Section
2.1.2 Detecting and Changing the IP Address for detailed LAN configuration.
3. In the router, set the PPPoE user name, password and confirm the password.
4. Set port mapping. E.g. 80, 8000 and 554 ports. The steps for port mapping vary depending
on different routers. Please call the router manufacturer for assistance with port mapping.
Note: Refer to Appendix 2 for detailed information about port mapping.
5. Apply a domain name from a domain name provider.
6. Configure the DDNS settings in the setting interface of the router.
7. Visit the PTZ via the applied domain name.
Connecting the network PTZ via a modem
Purpose:
This PTZ supports the PPPoE auto dial-up function. The PTZ gets a public IP address by ADSL dial-
up after the PTZ is connected to a modem. You need to configure the PPPoE parameters of the
network PTZ. Refer to Section 6.3.3 Configuring PPPoE Settings for detailed configuration.
Note: The obtained IP address is dynamically assigned via PPPoE, so the IP address always changes
after rebooting the PTZ. To solve the inconvenience of the dynamic IP, you need to get a domain
name from the DDNS provider (E.g. DynDns.com). Please follow below steps for normal domain
name resolution and private domain name resolution to solve the problem.
Normal Domain Name Resolution
Steps:
1. Apply a domain name from a domain name provider.
2. Configure the DDNS settings in the DDNS Settings interface of the network PTZ. Refer to Section
6.3.4 Configuring DDNS Settings for detailed configuration.
3. Visit the PTZ via the applied domain name.
Private Domain Name Resolution
Steps:
1. Install and run the IP Server software in a computer with a static IP.
2. Access the network PTZ through the L AN with a web browser or the client software.
3. Enable DDNS and select IP Server as the protocol type. Refer to Section 6.3.4
Configuring DDNS Settings for detailed configuration.
