4.5 Operating PTZ Control

Purpose:
In the live view interface, you can use the PTZ control buttons to control panning, tilting and
zooming.

4.5.1 PTZ Control Panel

On the live view page, click to show the PTZ control panel or click to hide it.
Click the direction buttons to control the pan/tilt movements. Click the
zoom/iris/focus buttons to realize lens control.
Figure 4-4 PTZ Control Panel
Button Description
Zoom in/out
Focus near/far
Iris +/-
Adjust speed of pan/tilt movements
Table 4-2 Descriptions of PTZ Control Panel

4.5.2 Setting / Calling a Preset

Purpose:
A preset is a predefined image position. For the defined preset, you can click the calling button
to quickly view the desired image position.
Setting a Preset:
Steps:
1. In the PTZ control panel, select a preset number from the preset list.
14
