Provision ISR Ultra-Z IP series User Manual page 15

2. Use the PTZ control buttons to move the lens to the desired position.
• Pan the PTZ to the right or left.
• Tilt the PTZ up or down.
• Zoom in or out.
• Refocus the lens.
3. Click to finish the setting of the current preset.
4. You can click to delete the preset.
Note: You can configure up to 256 presets.
Calling a Preset:
In the PTZ control panel, select a defined preset from the list and click
For convenient preset selection, refer to the following steps to navigate to the preset you want.
Steps:
1. Select any preset from the list.
2. Click the preset number you need on the keyboard.
Figure 4-5 Setting a Preset
Figure 4-6 Calling a Preset
to call the preset.
15
