Configuring Alarm Output - Provision ISR Ultra-Z IP series User Manual

6.6.5 Configuring Alarm Output

Steps:
1. Enter the Alarm Output Settings interface:
Configuration>Advanced Configuration> Events > Alarm Output
2. Select one alarm output channel in the Alarm Output drop-down list.
3. Set a name in
(optional).
4. The Delay time can be set to 5sec, 10sec, 30sec, 1min, 2min, 5min, 10min or
Manual. The delay time refers to the time duration that the alarm output remains in
effect after alarm occurs.
5. Click
the same as the settings of the arming schedule for motion detection. Refer to Step 2 Set the Arming
Schedule for Motion Detection in Section 6.6.1 Configuring Motion Detection.
6. You can copy the settings to other alarm outputs.
7. Click
Figure 6-47 Linkage Method
to enter the Edit Schedule Time interface. The time schedule configuration is
to save the settings.
for the alarm output
51
