Configuring Live View Parameters - Provision ISR Ultra-Z IP series User Manual

Setting a Pattern:
Steps:
1. In the PTZ control panel, click
2. Select a pattern number from the list as shown in Figure 4-10.
Figure 4-10 Patterns Settings Interface
3. Click to enable recording the panning, tilting and zooming actions.
4. Click
to save all the pattern settings.
Buttons on the Patterns interface:
Buttons
Notes:
These 4 patterns can be operated separately and with no priority level.
When configuring and calling the pattern, proportional pan is valid; the limit stops and
auto flip will be invalid; and the 3D positioning operation is not supported.

4.6 Configuring Live View Parameters

Main stream/Sub-stream/Third stream:
You can select
is with a relatively high resolution and needs much bandwidth. The sub-stream is with a low
resolution and needs less bandwidth. The default setting of stream type is.
Note: Please refer to Section 6.4.1 Configuring V ideo Settings for more detailed parameter settings
of the main stream, sub-stream and third stream respectively.
Image Size:
You can scale up/down the live view image by clicking
can be 4:3, 16:9, original or auto.
to enter the pattern settings interface.
Description
Start to record a pattern.
Stop recording a pattern.
Call the current pattern.
Stop the current pattern.
Delete the current pattern.
or as the stream type of live viewing. The main stream
. The image size
