2. Configure the QoS settings, including video/audio DSCP, event/alarm DSCP and
Management DSCP.
The valid DSCP value ranges from 0 to 63. The DSCP value is bigger, the priority is higher.
3. Click
Notes:
Make sure that you enable the QoS function of your network device (such as a router).
It will ask for a reboot for the settings to take effect.

6.3.8 Configuring FTP Settings

Purpose:
You can set a FTP server and configure the following parameters for uploading captured
pictures.
Steps:
1. Enter the FTP Settings interface:
Configuration >Advanced Configuration > Network > FTP
2. Configure the FTP settings, including server address, port, user name, password, directory and
upload type.
Setting the directory in FTP server for saving files:
In the Directory Structure field, you can select the root directory, parent directory and
child directory.
Root directory: The files will be saved in the root of FTP server.
Parent directory: The files will be saved in a folder in FTP server. The name of folder
can be defined as shown in following Figure 6-20.
Figure 6-18 QoS Settings
to save the settings.
Figure 6-19 FTP Settings
31
