4.1 Power-up Action

After the power is applied, the PTZ will perform self-test actions. It begins with lens actions and
then pan and tilt movement. After the power-up self-test actions, the information as shown in
Figure 4-1 will be displayed on screen for 40 seconds.
The System Information displayed on the screen includes the dome model, address, protocol,
version and other information. The COMMUNICATION refers to the baud rate, parity, data bit
and stop bit of the dome. e.g., 2400, N, 8, 1 indicates the dome is configured with the baud rate
of 2400, no parity, 8 data bits and 1 stop bit.

4.2 Live View Page

Purpose:
The live video page allows you to view live video, capture images, control the PTZ, set/call presets
and configure video parameters.
Log in the network speed dome to enter the live view page, or you can click
on the menu bar of the main page to enter the live view page.

Chapter 4 Live View

Model XX-2XXXXX-X ADDRESS
0
COMMUNICATION 0000,0,0,0
SOFTWARE VERSION
CAMERA VERSION
LANGUAGE ENGLISH
Figure 4-1 Power-up information
V000
V000
11
