<RIGHT LIMIT>: Move the cursor here and click IRIS + to enter. Move the dome to a defined
4)
position as right limit and click IRIS + to save this right boundary.
START: Move the cursor here and click IRIS + to start the current scan.
5)
SCAN SPEED: Move the cursor here and click IRIS + to set up the scan speed ranging 1-30.
6)
Sequence Menu:
The dome supports 8 groups of auto cruise and each cruise supports 32 presets. .
Please check the following steps to set up cruise.
SEQ NO.: Move the cursor here and click IRIS + to enter the setup of Sequence Number. Click the
1)
up or down button to select a preset number (1-8) and click IRIS + to confirm.
TITLE: Move the cursor here and click IRIS + to enter the setup of Sequence Title. Check the detailed above
2)
in DOME TITLE Settings.
<SEQUENCE SET>: Move the cursor here and click IRIS + to enter. Move the cursor to EDIT and
3)
click IRIS + enter edit mode of sequence. Move the left and right button to select each item.
a)
When the < > is on the item NO., move the up or down button to select the Serial NO. of the preset in
a sequence. There are up to 32 presets in each sequence.
b)
When the < > is on the item PRESET, move the up or down button to select the preset NO. that the
user wants to add in the sequence.
c)
When the < > is on the INTERVAL, move the up or down button to select the interval time between
each preset.
d)
When the < > is on the last item, move the up or down button to select edition mode as "INS (insert)",
"ok" and "delete".
Click IRIS + when selecting INS to insert the settings into the position of current Serial No.
Click IRIS + when selecting OK to override the settings of Current Serial No.
Click IRIS + when selecting delete to delete the settings of the Current Serial No.
Click IRIS + to save all the setting and click IRIS CLOSE to exit.
DELETE/START: Move the cursor here and click IRIS + to delete/start the current sequence.
4)

Pattern Menu:

The dome supports 4 pattern tours and each pattern cover at most 10 Minutes of 500
commands. Please check the following steps to set up a pattern.
PATTERN NO.: Move the cursor here and click IRIS + to enter the setup of Pattern Number. Click the
1)
up or down button to select a pattern number (14) and click IRIS + to confirm.
