Provision ISR Ultra-Z IP series User Manual page 70

ACTION: Set the alarm action:
NONE
PRESET
SCAN
SEQ
PATTERN
Move the cursor to ALARM OUT. Click IRIS + to enter and click up or
ALARM OUT:
down button to select alarm output channels among "OFF", "OUTPUT1", "ALL", which is
used to set linkage alarm to the output switch after receiving effective alarm input
signals.
Move the cursor to the ALARM OUT. Click IRIS + to enter and click up or
RESET DELAY:
down button to select reset delay among "10SEC" "30SEC" "1MIN" "5MIN"
"10MIN".Which means the time of the speed dome from detecting alarm signals
to alarm reset and return to normal. The setting is valid under AUTO ALARM MODE.
(default) No action
Dome goes to preset. (Default as Preset 1)
Dome starts auto scan (Default as Auto Scan 1)
Dome runs auto cruise (Default as Auto Cruise 1)
Dome runs pattern (Default as Pattern 1)
77
