Child directory: It is a sub-folder which can be created in the parent directory. The files
will be saved in a sub-folder in FTP server. The name of folder can be defined as shown in
following Figure 6-21.
Upload type: To enable uploading the captured picture to the FTP server.
3. Click to save the settings.
Note: If you want to upload the captured pictures to FTP server, you also have to enable t h e
c o n t i n u o u s
detailed information, please refer to the Section 7.3 Configuring Snapshot Settings.
6.3.9 Configuring UPnP™ Settings
Universal Plug and Play (UPnP™) is a networking architecture that provides compatibility among
networking equipment, software and other hardware devices. The UPnP protocol allows devices
to connect seamlessly and to simplify the implementation of networks in the house and corporate
environments.
With the function enabled, you don't need to configure the port mapping for each port, and the
camera is connected to the Wide Area Network via the router.
Steps:
1. Enter the UPnP™ settings interface.
Configuration >Advanced Configuration > Network > UPnP
2. Check the checkbox to enable the UPnP™ function.
You can edit the Friendly Name of the PTZ. This name can be detected by corresponding
device, such as a router.

6.3.10Configuring NAT (Network Address Translation) Settings

Steps:
1. Set the port mapping mode:
To port mapping with the default port numbers:
Choose
Figure 6-20 Parent Directory
Figure 6-21 Child Directory
snapshot or e v e n t -triggered s n a p s h o t in Snapshot interface. For
Figure 6-22 Configure UPnP Settings
