Notes:
Out of the box, the camera will work on DHCP and get an IP address automatically from the DHCP
server. In case a "Restore to factory default" was done, the default IP address will change to
192.168.0.99. The default user name is admin and password is admin.
For accessing the network PTZ from different subnets, please set the gateway for the network
PTZ after you logged in. For detailed information, please refer to Section 6.3.1 Configuring TCP/IP
Settings.

2.2 Setting the IP PTZ Camera over the WAN

Purpose:
This section explains how to connect the network PTZ to the WAN with a static IP or a dynamic
IP.

2.2.1 Static IP Connection

Before you start:
Please apply a static IP from an ISP (Internet Service Provider). With the static IP address, you can
connect the network PTZ via a router or connect it to the WAN directly.
Connecting the network PTZ via a router
Steps:
1. Connect the network PTZ to the router.
2. Assign a LAN IP address, the subnet mask and the gateway. Refer to Section 2.1.2
Detecting and Changing the IP Address for detailed IP address configuration of the PTZ.
3. Save the static IP in the router.
4. Set port mapping, E.g., 80, 8000 and 554 ports. The steps for port mapping vary depending on
different routers. Please call the router manufacturer for assistance with port mapping.
Note: Refer to Appendix 2 for detailed information about port mapping.
5. Visit the network PTZ through a web browser or the client software over the internet.
Connecting the network PTZ with static IP directly
You can also save the static IP in the PTZ and directly connect it to the internet without using
a router. Refer to Section 2.1.2 Detecting and Changing the IP Address for detailed IP address configuration
of the PTZ.

2.2.2 Dynamic IP Connection

Before you start:
Please apply a dynamic IP from an ISP. With the dynamic IP address, you can connect the network
PTZ to a modem or a router.
7
