4.5.3 Setting / Calling a Patrol

Purpose:
A patrol is a memorized series of preset function. It can be configured and called on the patrol
settings interface. There are up to 8 patrols for customizing. A patrol can be configured with 32
presets.
Before you start:
Please make sure that the presets you want to add into a patrol have been defined.
Setting a Patrol:
Steps:
1. In the PTZ control panel, click
2. Select a patrol number from
3. Click to enter the adding interface of preset as shown in Figure 4-8.
4. Configure the preset number, patrol duration and patrol speed.
Name
Patrol Duration
Patrol Speed
5. Click to save a preset into the patrol.
6. Repeat the steps from 3 to 5 to add more presets.
7. Click to save all the patrol settings.
to enter the patrol settings interface.
Figure 4-8 Adding Presets
Description
It is the duration staying on one patrol point. The PTZ
moves to another patrol point after the patrol time.
It is the speed of moving from one preset to another.
.
17
