Preset Menu - Provision ISR Ultra-Z IP series User Manual

Motion Menu:
to set up a preset.

Preset Menu:

PRESET NO.: Move the cursor here and click IRIS + to enter the setup of Preset Number. Click the
1)
up or down button to select a preset number (1-64 and 100-255) and click IRIS + to confirm.
TITLE: Move the cursor here and click IRIS + to enter the setup of Preset Title. Check the detailed
2)
above in DOME TITLE settings.
<SET>: Move the cursor here and click IRIS + to enter. Move the dome to a defined position as preset
3)
point and click IRIS + to save the preset position.
CALL: Move the cursor here and click IRIS + to call up the current preset.
4)
DELETE: Move the cursor here and click IRIS + to delete the current preset.
5)
SPEED: Move the cursor here and click IRIS + to set up the preset call up speed of LOW, MID and HIGH.
6)
Scan Menu:
The dome supports 8 groups of auto scan. Please check the following steps to set up
a scan.
SCAN NO.:
1)
Move the cursor here and click IRIS + to enter the setup of SCAN Number. Click the up or
down button to select a preset number (1-8) and click IRIS + to confirm.
TITLE: Move the cursor here and click IRIS + to enter the setup of SCAN Title. Check the detailed above
2)
in DOME TITLE settings.
<LEFT LIMIT>: Move the cursor here and click IRIS + to enter.
3)
Move the dome to a defined position as left limit and click IRIS + to save this left boundary.
The dome supports 220 presets. Please check the following steps
81
